Automatic Reverse Rotation - IKA KMO 3 basic User Manual

/// Automatic reverse rotation

To activate the "Reverse rotation" function, press the "Reverse rotation"
button (I). When the "Reverse rotation" function is switched on, a decimal
point appears on the LCD display
The running time (30, 60, 90 or 120 sec) is set by pressing the
"Reverse rotation" button (I) followed by the "+ / -"buttons (H)
After the preset running time, the drive is switched off and
restarted in the opposite direction
Note! ( )
The activation and deactivation of the „Reverse rotation" is only
possible if the drive is switched off
36 Start-up
Decimal point
/// Set-up plate illuminated
The illumination brightness can be adjusted by pressing the "Set-up plate
illuminated" button (D) After adjustment the brightness value will be shown
on the display for 2 seconds
› Factory setting: Off
Button Set-up plate
pressing time illuminated
1 × On
2 × On
3 × On
4 × Off
* Sequence 50 – 75 – 100 – 0 – 50 – 75 – 100 – 0 – 50 – etc
/// Lock
The "Lock" button (E) allows the user to lock or unlock the other control
buttons (including buttons D, G, H and I) of the device
› Press the "Lock" button (E) for 2 seconds to activate
or deactivate the "lock" function
› When the "Lock" function is activated, the green LED "Lock" (F) is on
› When the "Lock" function is deactivated, the green LED "Lock" (F) is off
The device keeps the status of "unlock" or "lock" when the power is switched
off and switched on again, which is important for operating mode "b"
Illumination
brightness value *
50 %
75 %
100 %
0 %
Start-up 37
