Device setup
/// KMO 3 basic
A
B
C
D
E
F
G
Explication of symbols
A "Power" button
B Standby LED
C Display
D "Set-up plate illuminated" button
E "Lock" button
F "Lock" LED
G "Start / Stop" button
26 Device setup
J
K
H
I
L M
H "+ / -" button
I "Reverse rotation" button
J Threaded hole for stand
K Set-up plate
L Power connection
M Interface USB
Safety instructions
/// About our warning symbols
Indicates an imminently hazardous situation, which,
if not avoided, will result in death, serious injury.
Indicates a potentially hazardous situation, which,
if not avoided, can result in death, serious injury.
Indicates a potentially hazardous situation, which,
if not avoided, can result in injury.
Indicates handling, which, if not avoided,
!
can result in equipment damage.
Attention!
Indicates the risks of magnetism
Safety instructions 27
