TEXAS MEMORY SYSTEMS, INC.
RamSan-300/320
User's Manual
Version 1.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RamSan-300/320 and is the answer not in the manual?

Questions and answers

Related Manuals for Texas Memory Systems RamSan-300/320

Summary of Contents for Texas Memory Systems RamSan-300/320

  • Page 1 TEXAS MEMORY SYSTEMS, INC. RamSan-300/320 User’s Manual Version 1.6...
  • Page 2 Any trademarks or registered trademarks used in this document belong to the companies that own them. Copyright © 2004, Texas Memory Systems, Inc. All rights are reserved. No part of this work may be reproduced or used in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without permission of the copyright owner.

  • Page 3: Table Of Contents

    Chapter 7 Fibre Channel Controller Configuration ..........70 Changing Fibre Channel topology and link speed ........70 Configuring high availability...............73 Chapter 8 – System Maintenance ..............76 Hot Swapping Power Supplies ............76 Hot Swapping Disk Drives ..............76 RamSan-300/320 User’s Manual - iii -...
  • Page 4 10.1 Physical Characteristics..............79 10.2 Operating Environment ..............79 10.3 Non-operating Environment...............79 Appendix A – RamSan-3xx Series Replacement Parts .........80 Appendix B – FCC/Safety Notices ..............83 Appendix C – Warranty, Maintenance, Field Service, and Repair Policy....84 RamSan-300/320 User’s Manual - iv -...

  • Page 5: Preface

    Preface Document Overview This document provides operating procedures for the RamSan-300/320. It covers installation, management, and troubleshooting issues. Conventions This document uses the following textual conventions: Select Front panel button descriptions Ethernet Setup Front panel text (menu items) lunconfig Management port (serial/Telnet) commands and text.

  • Page 6: Revision History

    Updated text management interface menu items Added LED configuration to Section 3.1.1 Added Section 5.1.2: Identifying a RamSan 12/08/2003 Updated Figures 3-2, 5-1, 5-2, 5-6, and 5-10 Updated Section 11.1 with voltage specs 01/07/2004 Updated Appendix B RamSan-300/320 User’s Manual - 2 -...

  • Page 7: Chapter 1 - Introduction

    This technology enables practically instantaneous data access, which results in dramatic application performance increases. Texas Memory Systems (TMS) designed the RamSan to be highly available and fault tolerant. The system has higher availability than RAID or JBOD systems because the primary storage media is SDRAM, which does not require moving parts.

  • Page 8: System Components

    TMS equips the RamSan-320 with an internal backup RAID. The backup RAID can operate at about 80 MB/sec during operation. In order to operate the drives after a power failure occurs, the RamSan-320 RamSan-300/320 User’s Manual - 4 -...

  • Page 9: Configurable Backup

    None (Volatile) mode This operational mode disables the backup functionality for the LUN making it completely volatile. In the case of system shutdown or failure, all data stored in the selected LUN will be lost intentionally. RamSan-300/320 User’s Manual - 5 -...

  • Page 10: Performance

    With up to eight Fibre Channel ports in a 3U package, the RamSan-3xx series delivers unparalleled bandwidth and I/O. The RamSan-3xx series is capable of 250,000 IOPS (I/O operations per second) and 3,000 MB/sec of read or write performance. RamSan-300/320 User’s Manual - 6 -...

  • Page 11: Chapter 2 - Installation

    3) Inspect the interface plate for any screws that might have loosened during shipping. 4) Inspect the front panel display for damage. 5) Report any meaningful damage to Texas Memory Systems. Figure 2-1 shows an overhead view of the layout of the RamSan-320 components.
  • Page 12 Front Panel Display Figure 2-1: RamSan-320 Layout RamSan-300/320 User’s Manual - 8 -...

  • Page 13: Rack Mounting

    Since the power supplies are redundant, you may remove line power from one without any interruption in system operation. If a RamSan-320 completely looses external power, it will shutdown after a defined amount of time. RamSan-300/320 User’s Manual - 9 -...
  • Page 14 Warning: A hard-shutdown will cause data loss and should only be used when the user is unable to perform a manual shutdown and all the data has been backed up to external storage. RamSan-300/320 User’s Manual - 10 -...

  • Page 15: Turning On The System

    TMS | | | | | ||||||() “Booting…” Memory Size: 64GB Booting ... Soon after that, you will see “Booting…” and then the system displays the IP address. IP Address Acquired: 000.000.000.000 RamSan-300/320 User’s Manual - 11 -...
  • Page 16 The top bars represent the port A and the bottom bars represent port B. The system is now ready for normal operation. RamSan-300/320 User’s Manual - 12 -...

  • Page 17: Chapter 3 - Management Tool Overview

    ↑ The “↑” button scrolls up through the menu. The “↑” button is also used cancel certain commands, as indicated on the display. If the menu is not selected, this button is disabled. RamSan-300/320 User’s Manual - 13 -...

  • Page 18: Text Management Interface

    To connect to the RamSan using a serial port connection, use a dumb terminal or a terminal emulation program such as Windows™ HyperTerminal. Set your baud rate to 9600 with 8 data bits, 1 stop bit, no parity, and no flow control. RamSan-300/320 User’s Manual - 14 -...
  • Page 19 [ENTER] key. For a detailed description of each menu item, arrow down to the item and press the [H] key to display help text. Figure 3-2: Text Management Interface RamSan-300/320 User’s Manual - 15 -...
  • Page 20 “Q” disregards any changes and returns to the previous menu. TMS designed some screens to display status information and display data as in Figure 3-4: Text Management Interface Status Screen: Figure 3-4: Text Management Interface Status Screen RamSan-300/320 User’s Manual - 16 -...

  • Page 21: Web Management Interface

    To access the web management interface, enter the RamSan’s IP address in a web browser. The web management interface is password protected. Enter your system login and password to access the web management interface. RamSan-300/320 User’s Manual - 17 -...
  • Page 22 3.3.1 General interface layout and instructions Texas Memory Systems designed the web management interface as a metaphor for the actual system components. For detailed information, the user simply clicks on the component. Clicking on the management port also displays additional information about the system’s actions.

  • Page 23: Chapter 4 - Administration Functions

    The default password for the “admin” account is “ssd” Logging in directly through the serial console automatically bypasses the password feature, which allows a system administrator access to the RamSan if the password is forgotten or lost. RamSan-300/320 User’s Manual - 19 -...
  • Page 24 • Enter your new password • Confirm the new password • Click the “Change” button The system immediately changes the administrator password. Figure 4-1: Password Change via Web Management Interface RamSan-300/320 User’s Manual - 20 -...
  • Page 25 The system allows the administrator to disable Telnet to prevent users from accessing the system through Telnet. Note: The RamSan does not allow you to disable access to the console. This provides a method to re-enable the Telnet, Web, and SNMP. RamSan-300/320 User’s Manual - 21 -...
  • Page 26 Click on the “Network” tab To enable Telnet, check the “Allow Telnet” checkbox and press the “Save” button. To disable Telnet, uncheck the “Allow Telnet” checkbox and press the “Save” button. Figure 4-3: Enable/Disable Telnet RamSan-300/320 User’s Manual - 22 -...
  • Page 27 Select “Save changes and exit” to save the changes. The menu displays the current Telnet status above the menu options, as shown in Figure 4-4: Telnet Setup. Users currently connected through Telnet remain connected until their session ends. Figure 4-4: Telnet Setup RamSan-300/320 User’s Manual - 23 -...
  • Page 28 Press the “ ” key or [ENTER] to toggle between the sections • Select “Save changes and exit” to save the changes. The menu displays the current SNMP Access status above the menu options. RamSan-300/320 User’s Manual - 24 -...

  • Page 29: Configuring Ethernet Settings

    Pressing the “Menu” button returns to the previous menu, and pressing the “Select” button exits the menu system. To continue setting up the Ethernet configuration, select “Set IP Config.” After selecting “Set IP Config,” you may use the arrow buttons to cycle through: RamSan-300/320 User’s Manual - 25 -...
  • Page 30 “↑” and “↓” button simultaneously. Repeat this procedure until you have entered the 4-byte address. Press the “Menu” button at any time to cancel the Static IP assignment. RamSan-300/320 User’s Manual - 26 -...
  • Page 31 If the network fails to start, check the Ethernet connection and contact your system administrator. If the system successfully saved the IP configuration, you may simply select the “Restart Network” option from the “Ethernet Setup” menu instead of re- selecting the same IP configuration. RamSan-300/320 User’s Manual - 27 -...
  • Page 32 If the administrator sets the IP assignment mode to ‘Static’, the ‘Change IP address’, ‘Change subnet mask’, and ‘Change gateway’ options appear, as shown in Figure 4-6: Static IP Settings: Figure 4-6: Static IP Settings RamSan-300/320 User’s Manual - 28 -...

  • Page 33: Power Down Settings

    “Power Off System.” To cancel the shutdown, use the “↑” button to return to the main menu. To proceed with the shutdown, use the “↓” button to confirm the system power off. RamSan-300/320 User’s Manual - 29 -...
  • Page 34 System. 4.3.2 Automatic shutdown In the event that the system senses a high system temperature, power out of specs, or AC power is lost, the system will automatically initiate the shutdown procedure. RamSan-300/320 User’s Manual - 30 -...

  • Page 35: Chapter 5 - Monitoring Functions

    If the system is rebuilding the disk array, the system displays “Array Rebuilding.” If the system is rebuilding a single disk, the front panel displays “Disk # Rebuild” indicating the disk number. RamSan-300/320 User’s Manual - 31 -...
  • Page 36 • More than one disk removed or failed. In the case of either system warnings or failures, the front panel display alternates between displaying status information and warning or failure messages every 10 seconds. RamSan-300/320 User’s Manual - 32 -...
  • Page 37 A and the bottom bars represent port B. The system stays in Active Monitor Mode for 10 minutes or until the user selects “Deactivate Monitor” from the front panel main menu. RamSan-300/320 User’s Manual - 33 -...
  • Page 38 IOPS, select “Display IOPS.” Once you select one of the above options, the display will ask you to “Enable Autoblink.” If you enable autoblink, the top LED will blink (even with constant bandwidth or IOPS). RamSan-300/320 User’s Manual - 34 -...
  • Page 39 Click on the “General Info” tab • Click the “Identify Device” button The RamSan front panel will begin to blink. To make the front panel stop blinking, click the “Identify Device” button again. Figure 5-1: Identify Device button RamSan-300/320 User’s Manual - 35 -...
  • Page 40 To view the system uptime via web interface: • Click on the “Management Control Processor” graphic • Click on the “General Info” tab The “General Info” screen displays the “Uptime” below “Firmware version.” Figure 5-2: System Uptime Status RamSan-300/320 User’s Manual - 36 -...
  • Page 41 The system displays the current system uptime in days, hours, minutes and seconds at the top of the “Health and Status” screen, as shown in Figure 5-3: Health and Status: Figure 5-3: Health and Status RamSan-300/320 User’s Manual - 37 -...
  • Page 42 The RamSan-300 does not display the disks or battery graphics. Disks (Not displayed for the RamSan-300) • Click on the “Disks” graphic • Click on the “General Info” tab Figure 5-4: Disk Status via Web interface RamSan-300/320 User’s Manual - 38 -...
  • Page 43 Batteries (Not displayed for the RamSan-300) • Click on the “Batteries” graphic • Click on the “General Info” tab Figure 5-5: Battery Status via Web interface RamSan-300/320 User’s Manual - 39 -...
  • Page 44 Management Control Processor To view the MCP status via web interface: • Click on the “Management Control Processor” graphic • Click on the “General Info” tab Figure 5-6: MCP General Info Tab for Status RamSan-300/320 User’s Manual - 40 -...
  • Page 45 Power supplies • Click on the “Power Supply” graphic • Click on the “General Info” tab Figure 5-7: Power Supply Status via Web Interface RamSan-300/320 User’s Manual - 41 -...
  • Page 46 Fans • Click on the “Fans” graphic • Click on the “General Info” tab Figure 5-8: Fans Status via Web interface RamSan-300/320 User’s Manual - 42 -...
  • Page 47 This states that everything is functioning under normal operating conditions. “Warn” This indicates a potential problem to look into, but the problem is not an immediate threat to system stability. “Error” This indicates that the component should be investigated immediately. RamSan-300/320 User’s Manual - 43 -...
  • Page 48 • Click on one of the “Fibre Channel” graphics • Click on the “General Info” tab Figure 5-10: Fibre Channel Controller Status via Web Interface RamSan-300/320 User’s Manual - 44 -...
  • Page 49 Via Text Management • From the Telnet Main Menu, select “Health and Status” • Select “View Controller Status” Figure 5-11: Fibre Channel Controller Status via Text Management Interface RamSan-300/320 User’s Manual - 45 -...

  • Page 50: Statistics

    IOPS, as well as a running average of each of these statistics. To decode the colors on the graphical display, view the legend below the check boxes. Figure 5-12: IOPS Performance Graph via Web Interface RamSan-300/320 User’s Manual - 46 -...
  • Page 51 Summary, shows the IO read (r), write (w), and totals (t) for each fibre channel controller in the system. It also displays a total across all of the FCs present. Figure 5-13: IO/sec Summary RamSan-300/320 User’s Manual - 47 -...
  • Page 52 To decode the colors on the graphical display, see the legend below the check boxes. Figure 5-14: Bandwidth Performance Graph via Web Interface RamSan-300/320 User’s Manual - 48 -...
  • Page 53 (r), write (w), and totals (t) for each fibre channel controller in the system. It also displays a total across all of the fibre channel controllers present. Figure 5-15: Bandwidth Performance via Text Management Interface RamSan-300/320 User’s Manual - 49 -...

  • Page 54: Logs

    Viewing the system event and support logs Via Web Interface To view the system event log or support log via the web interface: • Click the “Management Control Processor” graphic • Click the “System Log” or “Support Log” button. RamSan-300/320 User’s Manual - 50 -...
  • Page 55 Select “Clear the System Log” 5.3.3 Clearing logged ECC errors Via Text Management To clear the error log via Text Management Interface: • From the Telnet Main Menu, select “Health and status” • Select “Clear ECC Errors” RamSan-300/320 User’s Manual - 51 -...

  • Page 56: Chapter 6 - Lun Configuration

    You can change each Fibre Channel ports allocated space by using a simple configuration utility that TMS provides in the Text Management Interface and Web Interface. Important: LUN changes are not effective until the changes are saved. RamSan-300/320 User’s Manual - 52 -...

  • Page 57: A Example Lun Configuration

    Link each LUN to an Fibre Channel port (see Section 6.4 ) • Add access lists (see Section 6.7 ) • Set a backup mode for each LUN in a RamSan-320 (see Section 6.9 ) RamSan-300/320 User’s Manual - 53 -...

  • Page 58: Adding Luns

    Assign LUN masks (see Section 6.7 – Managing access lists) • Set backup mode (see Section 6.9 – Setting backup mode) • Click the “OK” button • The system adds the specified LUN. Figure 6-3: Adding LUNs via the Web Interface RamSan-300/320 User’s Manual - 54 -...
  • Page 59 Select “Add LUNs” The system adds the specified number of LUNs. If space was not available, the system displays an error message. When adding new LUNs, the configuration utility automatically makes the LUNs of equal size. RamSan-300/320 User’s Manual - 55 -...

  • Page 60: Viewing Lun Status / Lun Map

    To view the LUNs for the entire system: • Click on the “Management Control Processor” graphic. • Click on the “LUN Config” tab. • This screen displays the configuration of all LUNs. Figure 6-5: Viewing System LUNs via Web Interface RamSan-300/320 User’s Manual - 56 -...
  • Page 61 Click on the “Fibre Channel Controller” graphic. • Click on the “Available LUNs” tab. • This screen displays the available LUNs for the selected Fibre Channel Controller. Figure 6-6: Viewing LUNs Assigned to FC ports via Web Interface RamSan-300/320 User’s Manual - 57 -...

  • Page 62: Linking Luns To/From Fibre Channel Controllers

    Select the LUN to edit by clicking on the LUN graphic. • Click the “Modify LUN” button. • Select the links for the LUN by clicking the “Channel links” checkboxes. • Click the “OK” button. RamSan-300/320 User’s Manual - 58 -...
  • Page 63 • To save the changes once you have completed all LUN configuration, select “Save changes and exit” To ensure that your changes were successful, see Section 6.3 - Viewing LUN status / LUN map. RamSan-300/320 User’s Manual - 59 -...
  • Page 64 To unlink a LUN or all linked LUNs, select the LUN and press [ENTER]. • Select “Exit to the LUN configuration menu” • To save the changes once you have completed all LUN configuration, select “Save changes and exit” Figure 6-9: Unlink LUNs Option RamSan-300/320 User’s Manual - 60 -...

  • Page 65: Changing Lun Numbers

    To save the changes once you have completed all LUN configuration, select “Save changes and exit” You may number the LUNs between 0 and 63, minus those LUN numbers already assigned to devices. Figure 6-10: Assigning Different LUN Numbers RamSan-300/320 User’s Manual - 61 -...

  • Page 66: Resizing Luns

    “Save changes and exit” The system does not allow entering a LUN size greater than the remaining available space. If you attempt this, the system displays an error message and does not save your changes. RamSan-300/320 User’s Manual - 62 -...

  • Page 67: Managing Access Lists

    Select LUN (See instructions in Section 6.5 ) • Select “Print detailed WWN mask list for LUN” • The system displays the WWN mask list. • Press any key to return to the Modify LUN(s) menu. Figure 6-11: Current Access Lists RamSan-300/320 User’s Manual - 63 -...
  • Page 68 Masks” removes all masks. • Select “Exit to the LUN configuration menu” • To save the changes once you have completed all LUN configuration, select “Save changes and exit” Figure 6-12 Deleting Access Lists RamSan-300/320 User’s Manual - 64 -...
  • Page 69 Enter a unique device identifier from 1 to 255 and press [ENTER]. • Select “Exit to the LUN configuration menu” • To save the changes once you have completed all LUN configuration, select “Save changes and exit” Figure 6-13: Setting SCSI Device Identifier RamSan-300/320 User’s Manual - 65 -...

  • Page 70: Deleting Luns

    Click on the “Management Control Processor” graphic. • Click on the “LUN Config” tab. • Select to LUN to delete by clicking on the LUN graphic. • Click the “Delete LUN” button. Figure 6-14: Deleting LUNs via Web Interface RamSan-300/320 User’s Manual - 66 -...

  • Page 71: Setting Backup Mode

    “Save changes and exit” 6.9 Setting backup mode The RamSan-320 allows the administrator to set backup modes for each LUN individually. Warning: TMS does not recommend changing backup modes while the system is actively transferring data. RamSan-300/320 User’s Manual - 67 -...
  • Page 72 The system performs read operations from memory only. This mode allows read intensive applications to benefit from high speed reads while ensuring that any data written to the RamSan is simultaneously written to non-volatile storage. RamSan-300/320 User’s Manual - 68 -...
  • Page 73 Volatile mode (optional) This operational mode disables the backup functionality for the LUN making it completely volatile. In the case of system shutdown or failure, all data stored in the selected LUN will be lost intentionally. RamSan-300/320 User’s Manual - 69 -...

  • Page 74: Chapter 7 Fibre Channel Controller Configuration

    Click on the “Fibre Channel Controller” graphic. • Click on the “Controller Setup” tab. • Select from the “Topology” and “Link Speed” settings. • Click the “Save” button. Figure 7-1: Controller Setup via Web Interface RamSan-300/320 User’s Manual - 70 -...
  • Page 75 Select “Change link speed” • Choose the controller’s link speed from the sub-menu and press [ENTER] All modifications are visible at the top of the menu. To save any changes: • Select “Save changes and exit” RamSan-300/320 User’s Manual - 71 -...
  • Page 76 If you are having trouble with a direct attach connection in point- to-point mode, try changing the controller to arbitrated loop mode. Performance should not be noticeably impacted with this topology, and some HBAs may only support this mode. RamSan-300/320 User’s Manual - 72 -...

  • Page 77: Configuring High Availability

    FC controllers. The administrator can modify any controller setting from this state, and the effect will be local to this controller. This controller’s links are enabled and can be used to transmit and receive data. RamSan-300/320 User’s Manual - 73 -...
  • Page 78 The administrator cannot set this controller back to an active state directly. To re-activate this controller, either the secondary controller must fail, or the administrator must re- configure the secondary controller to “Primary (Active)” state. RamSan-300/320 User’s Manual - 74 -...
  • Page 79 “Primary (Active)” state result in errors because the drives appear to have been removed. TMS does not recommended configuring an active secondary controller as primary unless no transmissions are taking place. RamSan-300/320 User’s Manual - 75 -...

  • Page 80: Chapter 8 - System Maintenance

    8.1 Hot Swapping Power Supplies The RamSan-3xx series includes two power supplies. The system only requires one functioning power supply to run. Texas Memory Systems has taken special care to enclose the RamSan power supplies in a protective case to minimize the electrical risks for users; however, it is critical for...

  • Page 81: Batteries

    Gigabytes of capacity as the system synchronizes data on the disks. 8.4 Fans The system has one block of ten fans. The fan block is accessed from the top of the chassis. RamSan-300/320 User’s Manual - 77 -...

  • Page 82: Chapter 9 - Troubleshooting

    Systems, please have a copy of this log available. 9.2 Support Log The support log provides a snapshot of all current configuration settings. Before contacting Texas Memory Systems, please have a copy of this log available. 9.3 Still Having Problems…...

  • Page 83: Chapter 10 - Specifications

    90 ~ 264 VAC Ventilation: Front to back airflow 10.2 Operating Environment Temperature: 32-85 °F (0-30 °C) Max relative humidity: (non-condensing) Power consumption: 350 W 10.3 Non-operating Environment Temperature: 32-150 °F (0-65 °C) Relative Humidity: 10-90% (non-condensing) RamSan-300/320 User’s Manual - 79 -...

  • Page 84: Appendix A - Ramsan-3Xx Series Replacement Parts

    Appendix A – RamSan-3xx Series Replacement Parts Figure A-1 MCP-65 Management Control Processor Figure B-2 FC-65 Dual Channel 2-Gigabit Fibre Channel Controller RamSan-300/320 User’s Manual - 80 -...
  • Page 85 Figure B-3 Power Supply Module Figure A-5 16 Gigabyte Memory Blade RamSan-300/320 User’s Manual - 81 -...
  • Page 86 Figure A-6 120 Gigabyte Replacement Hard Drive RamSan-300/320 User’s Manual - 82 -...

  • Page 87: Appendix B - Fcc/Safety Notices

    3030113 Conforms to UL STD 60950 Certified to CAN/CSA STD C22.2 NO. 60950-00 Electrical Ratings: 100-240V~ 3.5A 50-60 Hz Made in U.S.A. RamSan-300/320 User’s Manual - 83 -...

  • Page 88: Appendix C - Warranty, Maintenance, Field Service, And Repair Policy

    Maintenance, Field Service, and Repair Policy BRONZE WARRANTY Equipment purchased from Texas Memory Systems, Inc. (TMS) is warranted for 1 year from the date of shipment. The warranty includes return-to-factory service for equipment that does not meet its published specification during normal operation.
  • Page 89 TMS within thirty (30) days, or else the RMA will be cancelled. SILVER WARRANTY - Advanced Parts Replacement Texas Memory Systems Silver Warranty may be purchased which provides all of the features of the Bronze plan. In addition, for one to three years (customer option),...
  • Page 90 Houston, Texas area, daily rates and normal travel expenses for field service personnel will be charged, including air fares, hotel accommodation, per- diem meal allowance and other out-of-pocket expenses related to travel or attendance at the customer site. RamSan-300/320 User’s Manual - 86 -...
