AUTOMATIC WATER SOFTENER VOLUMETRIC
Width [mm]:
Depth [mm]:
Height [mm]:
Weight [Kg]:
Cylinder capacity : [l]
Liters of resin [l]:
Nominal flow rate at 4 bar:..
Room temperature:
Feed water temperature
Pressure of feed water: ....0,2 ÷ 0,8 MPa (2 ÷ 8 bar)
Power supply: ........INPUT: 230V 50/60 Hz standard
Absorbed power:
Serie GIX
TECHNICAL FEATURES
GIX5V
GIX8V GIX12V
230
250
380
480
515
540
11
12
5
8
:
3.5
5.5
Min 4°C Max 35°C
Min 6°C Max 25°C
120V
60 Hz optional
285
425
650
15
12
9
1500 l/h
4W
Advertisement
Table of Contents
Related Manuals for DVA GIX Series
Summary of Contents for DVA GIX Series
- Page 1 AUTOMATIC WATER SOFTENER VOLUMETRIC Serie GIX TECHNICAL FEATURES GIX5V GIX8V GIX12V Width [mm]: Depth [mm]: Height [mm]: Weight [Kg]: Cylinder capacity : [l] Liters of resin [l]: Nominal flow rate at 4 bar:.. 1500 l/h Room temperature: Min 4°C Max 35°C Feed water temperature Min 6°C Max 25°C Pressure of feed water: ..0,2 ÷...
- Page 2 SETTINGS The GIX volumetric softener series features the Logix 760 valve. Thanks to their user-friendly approach, they can easily be set. They have 4 buttons that are used to set current time, regeneration time, the amount of salt to be used for a regeneration cycle and water hardness data.
- Page 3 CHOOSING THE PLACE OF INSTALLATION: Waste water resulting from the regeneration must be funneled into the floor sink by the flexible pipe. If the floor sink is placed higher than the water softener, the maximum height acceptable is 1.8 metres, provided that the pipe is not longer than 5 metres and the pressure of the water system is at least 2.8 bar.
- Page 4 RESIN STERILIZATION SALT ALARM (OPTIONAL) The GIX series volumetric softeners can be equipped, upon request, with an optional device for resin sterililzation. Such device is installed in the body of the valve and connected to the timer connector. Once installed, the timer will start it during a regeneration cycle.
- Page 5 Lack of maintenance can cause the water softener to malfunction. The filling of the brine (obstructed ejector) and the lack of suction of the brine (air infiltration in the rapid connections) are the problems that could occur due to lack of maintenance by the installer. FOR THE USER: Maintenance for the user only consists in refilling the brine periodically with sodium chloride (NaCl, common salt).
