Replacing the rechargeable battery pack
Headset – SDW 30 HS | SDW 60 HS
ASSY 190617
Disassembly/Assembly Instructions
JUNE 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDW 30 HS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sennheiser SDW 30 HS

Summary of Contents for Sennheiser SDW 30 HS

  • Page 1 Replacing the rechargeable battery pack Headset – SDW 30 HS | SDW 60 HS ASSY 190617 Disassembly/Assembly Instructions JUNE 2019...

  • Page 2: Table Of Contents

    SDW 30 HS | SDW 60 HS Contents Safety instructions General Safety instructions for rechargeable batteries Disassembly / Assembly Required material Disassembling the rechargeable battery pack 2.2.1 Opening the battery compartment 2.2.2 Removing the rechargeable battery Assembling the new battery pack...

  • Page 3: Safety Instructions

    SDW 30 HS | SDW 60 HS Safety instructions Safety instructions General Always check the safety and testing regulations that are currently valid for your country and abide by the following regulations: • Repair-related (e.g. in accordance with VDE 0701 in Germany).

  • Page 4: Safety Instructions For Rechargeable Batteries

    SDW 30 HS | SDW 60 HS Safety instructions 1.2 Safety instructions for rechargeable batteries WARNING! In extreme cases, abuse or misuse of Lithium-Polymer battery pack can lead to: explosion, fire, heat or smoke or gas. Do not crush, puncture, short circuit, disassemble, expose to moisture, heat or store above 70°C/158°F or dispose of in fire or...

  • Page 5: Disassembly / Assembly

    Disassembly / Assembly 2.1 Required material • new Battery pack for SDW 30 HS | SDW 60 HS – ID No. AHB732038TPCT • Tool such as a small plastic rod and paper clip for SDW 60 HS 2.2 Disassembling the rechargeable battery pack 2.2.1 Opening the battery compartment...

  • Page 6: Removing The Rechargeable Battery

    SDW 30 HS | SDW 60 HS Disassembly / Assembly 2.2.2 Removing the rechargeable battery Use a plastic tool (e.g. small plastic lifting rod) to lift the rechargeable battery. Please note, that the battery is attached with an adhesive. SDW 30 HS SDW 60 HS 2.

  • Page 7: Assembling The New Battery Pack

    SDW 30 HS | SDW 60 HS Disassembly / Assembly 2.3 Assembling the new battery pack Rotate the battery so that the marking signs are visible at the top. Insert the connector plug of the new rechargeable battery into the connection socket.
  • Page 8 6. SDW 60 HS: Close the battery compartment and turn the lid clockwise. You hear a click. SDW 30 HS: Start attaching the lower side (as shown) and then push the other side down. Finally, push the sides into place.

  • Page 9: Testing And Further Information

    SDW 30 HS | SDW 60 HS Testing and further information Testing and further information 3.1 Testing the battery and final adjustments Test the function of the headset: Press the Hook button to switch on the headset. The LED lights up blue.
