Tone select
1. Tone
Tone select
0 111111 Rising and falling 150 to 1000 to 150 Hz 10 s - 40 s - 10 s
1 011111 Alternating 800 & 970 Hz
2 101111 Rising 800 & 970 Hz
3 001111 Rising 800 & 970 Hz
4 110111 Constant tone 2850 Hz
5 010111 Rising 2400 to 2850 Hz
6 100111 Rising 2400 to 2850 Hz
7 000111 Rising 300 to 1200 Hz
8 111011 Falling 1200 to 500 Hz
9 011011 Alternating 2400 & 2850 Hz
10 101011 Interrupted 970 Hz
11 001011 Alternating 800 & 970 Hz
12 110011 Interrupted 2850 Hz
13 010011 Interrupted 970 Hz
14 100011 Constant tone 970 Hz
15 000011 Alternating 554 & 440 Hz
16 111101 Interrupted 660 Hz
17 011101 Interrupted 660 Hz
18 101101 Interrupted 660 Hz
19 001101 Constant tone 660 Hz
20 110101 Alternating 554 & 440 Hz
21 010101 Interrupted 660 Hz
22 100101 Interrupted 2850 Hz
23 000101 Ansteigend 800 to 970 Hz
24 111001 Ansteigend 2400 & 2850 Hz
25 011001 Interrupted 970 Hz
26 101001 Interrupted 2850 Hz
27 001001 Constant tone 4000 Hz
28 110001 Alternating 800 & 970 Hz
29 010001 Alternating 990 & 650 Hz
30 100001 Alternating 510 & 610 Hz
31 000001 Rising 300 to 1200 Hz
32 111110 Constant tone 4000 Hz
33 011110 Constant tone 990 Hz
34 101110 Interrupted 990 Hz
35 001110 Constant tone 510 Hz
36 110110 Interrupted 510 Hz
37 010110 Constant tone 850 Hz
38 100110 Constant tone 1650 Hz
PFEER Prevention of Fire Explosion and Emergency Response
BS British Standard
DIN Deutsche Industrie Norm
ISO International Organisation of Standardization
4 | AN307529759541en-000101
Tone description
2 Hz (250 ms - 250 ms)
7 Hz (7/s)
1 Hz (1/s)
Continuous
7 Hz (7/s)
1 Hz (1/s)
3s rising, 0.5s silence, then repeat
1 Hz
2 Hz (250 ms - 250 ms)
0.5 Hz (1s ON/ 1s OFF)
1 Hz (500 ms - 500 ms)
0.5 Hz (1s ON/ 1s OFF)
0.8 Hz (250 ms ON/1s OFF)
Continuous
100 ms - 400 ms
3.3 Hz (150 ms ON/150 ms OFF)
0.28 Hz (1.8 s ON/1.8 s OFF)
0.05 Hz (6.5 s ON/13 s OFF)
Continuous
0.5 Hz (1s ON/ 1s OFF)
1 Hz (500 ms - 500 ms)
4 Hz (150 ms ON/100 ms OFF)
50 Hz
50 Hz
3 x 500 ms Pulse followed by 1.5 s
silence, then repeat
3 x 500ms Pulse followed by 1.5 s
silence, then repeat
Continuous
2 Hz (250 ms - 250 ms)
2 Hz (250 ms - 250 ms)
2 Hz (250 ms - 250 ms)
1 Hz
Continuous
Continuous
1 Hz (500 ms ON/500 ms OFF)
Continuous
1 Hz (500 ms ON/500 ms OFF)
Continuous
Continuous
Application mA @
12VDC
Highest 27
BS Fire 20
BS Fire 20
BS Fire 20
18
18
17
Netherlands Fire (NEN 2575) 20
German Fire (DIN 33 404) 21
18
PFEER alert 17
BS Fire 20
17
17
PFEER toxic gas 20
French Fire (NFS32-001) 22
Swedish (Air Raid) 18
Swedish (local warning) 18
Swedish (Pre-mess) 18
Swedish (All Clear) 20
Swedish (Turn out) 22
Swedish common 20
Pelican crossing 18
BS Fire 21
20
ISO 8201 19
ISO 8201 19
ISO 8201 19
BS Fire 22
BS Fire 23
BS Fire 23
22
BS Fire 20
21
19
23
20
21
20
© Danfoss | DCS (vt) | 2019.06
dB(A) mA @ dB(A)
@1m, 24VDC @1m,
90°, 90°,
12VDC 24VDC
93 35 97
93,5 30 98
93 29 97
94 30 97
88 23 95
87 23 95
87 23 96
94 23 98
93 31 98
87 24 95
92 20 97
93 30 97
88 21 96
92 21 97
92 28 97
91 35 96
91 26 96
91 23 96
91 26 96
91 31 96
91 35 96
91 21 96
88 22 95
90 30 96
85 25 93
92 23 97
88 23 95
90 23 95
93 30 97
92 35 97
91 35 96
93 34 97
91 25 96
92 30 97
92 21 97
91 35 96
91 22 96
89 30 96
86 24 94
