Pentax ist D Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

TM
ENGLISH
PRODUCT No. 76180
PENTAX Corporation
Service Planning Section
03:04 H.Y.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ist D and is the answer not in the manual?

Questions and answers

Related Manuals for Pentax ist D

Summary of Contents for Pentax ist D

  • Page 1 ENGLISH PRODUCT No. 76180 PENTAX Corporation Service Planning Section 03:04 H.Y.

  • Page 2: Table Of Contents

    [TABLE OF CONTENTS] PREPARATION ..........................2 Preparation of Digital Adjustment....................2 DISASSEMBLY AND ASSEMBLY ....................3 Outline of Disassembly and Assembly..................3 1. Caution ..........................3 2. Chart for Assemble, Adjustment and Confirmation ............3 DISASSEMBLY AND ASSEMBLY PROCEDURES ..............6 I.

  • Page 3: Preparation

    PREPARATION The following preparations are required before disassembling and assembling the camera. 1. Prepare the Jigs, tools and testers. (Refer to the Table of Jigs, tools and testers.) 2. Make the preparation for the digital adjustment. (Refer to the Preparation of digital adj.) Preparation of Digital Adjustment [Required equipment] Programmed software 76180 (for Digital adjustment, contained 95901 P401-00B)

  • Page 4: Disassembly And Assembly

    DISASSEMBLY AND ASSEMBLY Outline of Disassembly and Assembly 1. Caution 1) Be sure to use the conductive mat and wrist strap to prevent static failure of circuits. 2) Do not stress to the connector terminals and flexible boards because they are very delicate parts.
  • Page 5 6. Around Pentaprism (2) ....................28 7. 0-Q200・0-T800 (Flash P.C. Board assy.・Power P.C. Board assy.) ......29 8. A49 (Remote Control Base Plate)................... 30 9. A5 (Right Shoulder Plate) ....................30 10. Around Pentaprism (1) ....................31 11. [CONF] Function Check Ⅰ..................31 11-1.
  • Page 6 28. [CONF] Final function check ..................49 28-1. Confirmation of the Metering function ..............49 28-2. Confirmation of the Exposure value (for reference) ..........49 28-3. Confirmation of White Balance ................49 28-4. Confirmation of the Battery Exhaustion Warning ..........51 28-5.

  • Page 7: Disassembly And Assembly Procedures

    DISASSEMBLY AND ASSEMBLY PROCEDURES I. Disassembly procedure of main body [Preparation] Remove the Hot shoe cover FK Eye cap FL and Battery from the main body. ① ③ ② 1. A401 (Bottom Cover) ① A431･･･Remove the cover by using a coin. ②...
  • Page 8 ⑧ Lift up the top cover, and then discharge the main capacitor at the following positions. -1. Between a brown lead wire and a blue lead wire. [NOTE] If the above position is not available for discharging proceed as follows. -2.
  • Page 9 ④ A62 x2 (Screw, 3.5mm) ⑤ A68 x2 (Screw (TY), 6mm) ⑥ A69 x2 (Screw (TY), 3.5mm) ④ ⑤ ⑥ ⑦ Lift up A201while opening the terminal cover. ⑧ Disconnect the flexible board of 0-O301from the connector terminal. ⑨ Disconnect the connector terminal of T905 from 0-O301by using the tweezers with care to prevent damage.
  • Page 10 ③ Disconnect the flexible board of T100 from the connector terminal of T700. ④ Unsolder 5 lead wires on T600. (Brown, Black (T800), Red, Gray (T700), Black (A433)) ⑤ CNL-D1.7x2.5 (4pcs.) ④ ⑤ ⑤ ⑥ 0-T700 ④ ③ ⑥ ④ ⑤...
  • Page 11 9. A5 (Right shoulder plate) ① CNL-D1.7x2.5 ② A338 ⑥ ③ CNL-D1.7x2.5 (3pcs.) ④ CNL-D1.7x3.5 ⑤ TY-CNL-D1.7x3.5 (PT 15x8) ⑧ ⑥ Unsolder a black wire. ･･･ for CE mark ⑦ ⑦ A5 ⑧ T62 ① ③ ⑦ ⑤ ④ ② 10.
  • Page 12 11. 0-Q200・0-T800 (Flash P.C. Board assy., Power P.C. Board assy.) ① Unsolder 2 lead wires. (Red, Black) ② Peel off BT (25x10) while holding 0-T100 with care to avoid breaking the flexible board. ③ Disconnect the flexible board of T100 from the connector terminal of 0-T800. ④...
  • Page 13 13. Around Pentaprism (2) ① Disconnect the flexible board of O100 from the connector terminal of 0-T100. ② Peel off the flexible board of T100 from DT. ③ Unsolder a black lead wire. (T900) ④ Unsolder 2 lead wires. (Orange, Gray S300) ⑤...
  • Page 14 15. T903 (TV/AV Dial) ① ① CNL-D1.7x2.5 ② TY-CNL-D1.7x9.0 (3pcs.) ③ Peel off the flexible board from the LCD frame. ④ ④ TY-CNL-D2.0x9.0 ･･･ Underneath the flexible board of 0-T100. ③ ⑤ Lift up the LCD frame of 0-T100. (If there is a lug-plate, remove it by loosening screw.) ②...
  • Page 15 ④ ④ A71 x2 (Shoulder screw) ⑤ TY-CNL-D1.7x2.5 ⑥ 0-E000 ⑦ A65 x4 (Screw) ⑧ A2 ⑧ ⑥ ⑦ ⑤ ④ 18. Battery Chamber and Related Parts ① ① Unsolder 7 lead wires. ② Unsolder 2 lands. ③ T907･･･DT ④ Unsolder 4 lands. ⑤...

  • Page 16: Assembly Procedures Of Front Housing Block

    II. Assembly procedures of Front Housing Block Disassemble the front housing block in reverse order of assembly procedures according to “Note of disassembly”. Assembly Procedures 1. Front Housing Block ① B65 x2, B41, M120, B58 x2, B59 ② 0-A41 (X- terminal)･･･ Brown lead wire 40mm ③...

  • Page 17: G100

    ⑤ [ADJ.] Pre-adjusting the Focus Screw-in 3 adjusting screws until they stops, and then screw back two turns. ⑥ Hook 0-M4. ⑦ Install M21 while positioning the boss. ⑧ TY-CNS1.7x3.5 ⑦ ⑧ ⑥ 4. 0-G100 ① B11 ② B20･･･ The spring (B20) should be set on the shaft of 0-B52. ③...

  • Page 18: Conf] Checking The Mirror Function

    ⑱ TY-CNL-D1.7x3.5 (4pcs.) ① ③ ② ⑱ [Note of Disassembly] Set the mirror seat at top end position before removing 0-G100. 1. Apply DC1~3V to 0-S250 (Red lead wire: Positive) and set the mirror seat at top end position. (Mirror seat ① and Sliding plate ③ must be top end position, Shutter charge lever must be bottom end position ②.) 2.

  • Page 19: A104

    6. A104 ① ② ① 0-A126 ⑧ ⑦ ② TY-CNL-D1.7x3.0 ③ A133 ④ 0-A121 ⑥ ③ ⑤ TY-CNL-F1.4x4.0 ⑥ A105 ⑨ ⑦ 0-A108 ④ ⑤ ⑧ A110 ⑩ ⑪ ⑨ A104 ⑩ TY-CNS2.0x4.5Ni (5pcs.) ･･･ Tighten 5 screws in the numerical order as shown in the figure above.

  • Page 20: J201・A163

    Scale NG: 0.8(Y) or over NG: 0.6(X) or over 1mm hole (Standard) Center of standard : Tolerance of 1mm hole : (X-axis = ±0.6, Y-axis = ±0.8) Tolerance･･･ X-axis : ±0.3mm Y-axis : ±0.1mm ③ After adjustment is done, apply the super-glue to both B58. ②...

  • Page 21: M301

    ② 10. M301 ① M301 (L5, L7, M302, 0-M307) ② TY-CNM1.7x4.5 (2pcs.) ① 11. [ADJ] Viewfinder Focus・Parallax [Required equipment] Collimator, Focus master lens, Lens for checking (e.g. FA50mmF1.4) [Preparation] Adjust the diopter by the diopter adjustment lever. 11-1. Parallax [CAUTION] Confirm that the Pentaprism must be installed securely. ①...

  • Page 22: J100

    12. 0-J100 ① M7 [Note of Disassembly] ② M5 Set the diopter adjustment lever at the ③ TY-CNL-B1.4x2.5･･･ Left side left end to remove 0-J100. ④ W29 (t=0.5) ⑤ 0-T970･･･ White, Yellow lead wire 55mm ⑥ TY-CNL-B1.4x3.5 ⑦ 0-J100 TY-CNL-B 1.4x2.5 ⑧...

  • Page 23: O100

    : SI-LED AF frame ③ ③ Loosen 2 screws, and then adjust the position of 0-O170. ④ Tighten 2 screws, and then confirm the position again. ⑤ After adjustment is done, apply the screw-lock agent to both screws and remove the lead wires from 0-O170.

  • Page 24: Adj/Conf] Af Joint Stroke

    18. [ADJ/CONF] AF Joint stroke [Required equipment] Vernier calipers ① If AF mode SW (0-I331) is installed, set the AF mode SW to AF.S. ② [CONF] AF coupler must be projected from the mount surface by 1.2 mm or more. ③...

  • Page 25: Adjustment

    20-2. Adjustment ① Connect the DC cord to the camera. Confirm that the camera must be turned ON without a short circuit or leakage 5 seconds after the DC cord is connected to the camera. (Main SW/ON: Light metering OFF: Ave. 240mA, Light metering ON: Ave. 420mA) ②...
  • Page 26 ⑪ Solder 8 lands.･･･ T71, 0-T100 ⑫ Solder 2 lands.･･･ G100 ⑫ [Note of disassembly] When peel off BT (⑩), hold the flexible board of S300 to avoid breaking it. ⑪ 76180 EM -25/73-...

  • Page 27: Ⅲ Assembly Procedure Of Main Body

    Ⅲ . Assembly procedure of main body 1. Battery Chamber and Related Parts ① A13 (A14 (4pcs.), A15 (2pcs.)) ② 0-T900 ③ TY-CNL-D1.7x4.0 ④ Solder 4 lands. ⑤ Fold down T907 as instructed in the figure (2 places) and stick it on A13 by using DT (8x18). ⑥...

  • Page 28: Front Housing Block

    3. Front Housing Block ① Confirm the 0-E000 is in charge. ② Confirm the front housing block is in mirror down condition. ③ Put the main plate on the front housing block with care to avoid pinching lead wares or flexible boards.

  • Page 29: A3 (Bottom Plate Assy.)

    5. 0-A3 (Bottom Plate assy.) ① Arrange the flexible boards as shown in the figure. ② 0-A3 ③ TY-CNL-D1.7x4.0 (2pcs.) ④ CSM1.7x2.5 ⑤ CNL-D1.7x2.5 (2pcs.) ⑥ TY-CSM1.7x4.0 (2pcs.) ⑦ ⑦ A423 ⑧ A422 ③ ⑨ CNL-D1.7x2.0 (2pcs.) ⑩ Stick T301 on the bottom plate by using DT (5x5). (T81: for CE marking) ⑪...

  • Page 30: Q200・0-T800 (Flash P.c. Board Assy.・Power P.c. Board Assy.)

    ⑫ Arrange the lead wires for CE marking as shown in the figure below. 7. 0-Q200・0-T800 (Flash P.C. Board assy.・Power P.C. Board assy.) ① Pass T905 (Power supply cable) through between the main plate and bottom plate. ② 0-T800 ③ CNL-D1.7x2.5 (2pcs.) ④...

  • Page 31: A49 (Remote Control Base Plate)

    8. A49 (Remote Control Base Plate) ① CNL-D1.4x4.0･･･ Cable release socket ② Connect the flexible board of T301 to the connector terminal of 0-T100. ③ Solder two lead wires. (Yellow, Black) ④ A49 (If there is a black wire for CE marking, arrange it inside A49.) ⑤...

  • Page 32: Around Pentaprism (1)

    10. Around Pentaprism (1) ① Solder a blue lead wire. ･･･ 0-T800 ② Solder 7 lands.･･･ 0-J100 ③ Stick T64 (20x50) on 0-T100 as shown in the figure below. ④ Stick 0-T100 by DT (5x5) as shown in the figure below. ⑤...

  • Page 33: Function Check

    11-2. Function Check [Caution] Do not touch the shutter blades while checking the function. 11-2-1. Power・Main SW ① Connect the DC cord to the DC power supply and set the voltage to DC6.5V (3A). ② Turn the main SW to OFF and connect the DC cord to the camera. At this time, there must be neither short nor Leakage.

  • Page 34: Adj.] Shutter Speed (1/4000Sec.)

    11-5. AF ① Set the mode dial to Green Program AE Mode and set the AF_SW to AF.S (down position). ② The distance ring of the lens must turn between infinity (∞) and shortest distance end when the shutter button is depressed halfway while covering the front of lens with the palm. ③...

  • Page 35: Adjustment

    12-2. Adjustment ① Connect the camera to the PC, and adjust the shutter speed by the programmed software. [The flow of adjustment is as follows.] ↓Product select menu (Select *istD) ↓76180 test program（Select １ even when you replace 0-T100.） ↓Main menu (Select 7 ) ↓Shutter speed adjustment ②...

  • Page 36: T700 (Cf P.c. Board Assy.)

    ⑤ Install 0-T600 to the main body while matching it to two positioning studs so that there is no space between them. ⑥ CNL-D1.7x2.5 (3pcs.)･･･0-T600 ⑦ A60 x3 (Shoulder screw) ⑧ Short the land of 0-T750 by solder as shown in the figure below. ⑨...

  • Page 37: Conf] Function Check Ii

    ④ Connect the flexible board of T100 to the connector terminal of T700. ⑤ Connect the flexible board of T100 to the connector terminal of T600. ④ ⑤ 16. [CONF] Function Check II [Required equipment] CF card for the firmware (FW), Color video monitor, Video cable (I-VC2), Battery adaptor (Jig: Battery grip D-BG1), Regulated DC power supply (8V・3A), DC cord (Jig), AC Adapter (D-AC10) [Preparation] Connect the video cable to the color video monitor.

  • Page 38: Writing Fw

    [CAUTION] Do not turn OFF the camera while loading firmware. ⑥ Disconnect the video cable and the AC adapter DETECTED BOTH F/W FILE from the camera when POWER OFF is displayed. NOW LOADING PENTAX *IST D UPDATING DSP FIRMWARE DETECTED FIRMWARE FILE SECTOR** >> PROGRAM COMPLETE LOADING...

  • Page 39: A153 (Front Cover, Left)

    18. A153 (Front Cover, Left) ① A153･･･ Install the cover at MF position. ② CNL-D1.7x2.5 (2pcs.) ② ② ① 19. A201 (Back Cover) ① Apply G151 to land on 0-T700. ② Connect the connector of T905 to 0-O301as shown in the figure below. ③...

  • Page 40: Adj] Positioning 0-J100

    20. [ADJ] Positioning 0-J100 [Required equipment] Penlight or equivalent ① Confirm that the mirror seat is downed condition. ② Remove 0-T970 ･･･ There is a washers underneath 0-T970. Removing the lead wire is not necessary. ② ③ Cover the eyepiece with a black tape. Pen-light ④...

  • Page 41: Conf] Function Check Ⅲ

    ⑥ ⑦ Solder 4 lead wires (Blue, Black, Brown, Green)･･･Q100 [NOTE] Stick PT (10x20) on Q200 for CE marking. ⑧ A64 x2 (Screw, 11mm) ⑨ A69 (Screw (TY), 3.5mm) ⑦ ⑩ A63 (Screw, 4.2mm) ⑪ A62 (Screw, 3.5mm) ⑫ A61 (Screw, 2.5mm) *PT(10x20) ⑧...

  • Page 42: Conf] Static Current

    22-2 [CONF] Static Current ① Connect the DC cord to the camera and then the camera will be turned ON. At this time, there must be neither short nor Leakage. Static current: Main SW/OFF ･･･ Ave.10mA Main SW/ON (Light metering OFF)･･･ Ave.240mA Main SW/ON (Light metering ON)･･･...

  • Page 43: Conf] Af・Si (Superimpose) Function

    t. MWB Manual Balance Change MANUAL u. CFDOOR CF door Change AF continuous AF single －← 0 →＋ z. TVDIAL Tv dial ACDET －← 0 →＋ 1. AVDIAL Av dial GRIP MAIN 22-5. [CONF] AF・SI (Superimpose) Function ① Attach the lens to the camera and set the focus mode lever to AF.S. ②...

  • Page 44: Conf] Cf Card Cover Sw

    ② The aperture of lens must change similarly when the aperture value (Av) is set in opening, the middle, and the minimum with the Av dial. ③ Detach the lens from camera, and depress the release button, and make the camera long exposure condition.

  • Page 45: Adj.] Adjustment With Programmed Software (Digital Operation)

    [NOTE] 1. When adjusting “CCD POSITION ADJUSTMENT”, remove the bottom cover, A422 and A423 to free T301. And, turn the adjustment screws of 0-M100 according to the instructed on the screen. 2. Adjust the battery level accordance to the instructed on the screen when 0-T100 is replaced. 3.

  • Page 46: Procedure Of Adjustment

    24-3. Procedure of adjustment ① Connect the AC adaptor to the camera. ② Connect the camera to the computer by the USB cable (I-USB2). ③ Attach the Master lens to camera while confirming the aperture of Master lens is set to F8. ④...
  • Page 47 ⑩ After adjustment is done, double-click the Hot Plug icon on the status bar at the bottom right of the desktop to stop a hardware device. And, turn OFF the camera and then disconnect the camera from the computer. [Error Message] When the mode dial is not set to M, the following window will be displayed.
  • Page 48 24-4. Procedure of WDC adjustment [NOTE] CCD white pixel defect compensation item only can be adjustable by this procedure. ① Connect the AC adaptor to the camera. ② Connect the camera to the computer by the USB cable (I-USB2). ③ Turn the main switch ON, and then confirm that the camera is recognized as a [Removable Disk] under [My Computer] ④...

  • Page 49: Arranging The Lead Wires For Ce Marking

    25. Arranging the lead wires for CE marking 26. A401 (Bottom Cover) ③ ① A424 ② CNL-B1.4x1.6 ①② ③ Solder two lands. ④ A434 ⑤ Stick A425 x3 (10x20) ⑥ Stick A426 (8x14) ⑦ Stick A427 x2 (8x10) ⑧ Solder a blue lead wire to A432 (A401). ⑦...

  • Page 50: Conf] Final Function Check

    28. [CONF] Final function check 28-1. Confirmation of the Metering function [Required equipment] Light source (Shutter tester), FA50mm F1.4 ① Attach the lens (FA50mm) to the camera and set the aperture to the A position. ② Set the camera as follows. Capture mode: AV (Aperture-priority) mode, Aperture value: Av8 (FNo.8), Sensitivity: ISO200, Focus mode SW: Manual focus, Exposure setting step: 1/2 (Default setting of custom function) ③...
  • Page 51 Correlation table of EV with Y: －1.0 －0.5 ±0 ＋0.5 ＋1.0 [NOTE] The standard is applied only when the camera is set to the condition as mentioned above. 28-3. Confirmation of White Balance [Required equipment] Computer (for Digital adjustment), AC adaptor (D-AC10), USB cable (I-USB2), CF card (for taking picture), FA50mm F1.4, A light (2856 K°), Color checker (Macbeth Chart or equivalent), Fluorescent lamp (White 4244K°), Fluorescent lamp (Neutral...

  • Page 52: Confirmation Of The Battery Exhaustion Warning

    28-4. Confirmation of the Battery Exhaustion Warning [Required equipment] Battery adaptor (Jig: Battery grip D-BG1), Regulated DC power supply ① Connect the battery adaptor to the DC power supply, and set the voltage to DC4.6V (3A). ② Attach the battery adaptor to the camera. ③...
  • Page 53 7) Change the display on the LCD panel from “PF1-1” to “PF1-2” by pressing four-way control key. 8) Turn OFF the main switch once. Focus point and AF sensor You can select the desired focus sensor by changing the metering mode as follows. Multi-Segment Metering →...

  • Page 54: Cleaning The Ccd

    ⑧ The same manner with above. Turn the distance ring of the lens to minimum focus distance and repeat above (7) for confirming vertical sensor, set the camera at vertical position. ⑨ Display the images on the computer with image viewing software. ⑩...
  • Page 55 ② Set the camera as follows. Capture mode: AV (Aperture-priority) mode and Set AV 22 (FNo.22), ISO speed: 200, Focus mode SW: MF, Exposure compensation:+1/2EV, Recorded pixels: L (Default setting), Quality Level: Best. ③ Turn the distance ring of the lens to infinity (∞). ④...

  • Page 56: Default Setting

    28-8. Default setting *This setting is initialized camera as condition of product shipment. The initialized item is as follows. Menu, Custom function, Language, Date / Time, ISO, WB, Recorded image, Recorded Pixels, Quality Level [Required equipment] CF card (for Default setting), AC adaptor (D-AC10) ①...

  • Page 57: Fw Firmwar

    FW FIRMWAR 1. Checking Firmware Version 1. Checking FW version for customer ① Turn the main switch to ON while pressing MENU button. The firmware version for customer VER:＊.＊＊ will be displayed on the LCD monitor for 5 seconds. 2. Checking FW version for Service [Required equipment] CF card x2 (FW version check for [ON] and [OFF]) ①...

  • Page 58: Updating Firmware Version (2)

    ⑦ Turn the main switch to OFF when the following message [POWER OFF] is appeared. (Updating is completed) ⑧ Insert the CF card into the camera again then PENTAX *IST D turn on the power condition with opening CF UPDATING DSP FIRMWARE card cover.

  • Page 59: Technical Information

    TECHNICAL INFORMATION Battery consumption current Condition: CF card [HAGIWARA SYS-COM 64/128/256MB Micro-drive [IBM (Hitachi GST) 1GB] Lens [FA lens, A position], each mode and setting is default setting. Meaning of table: Lens --- O: With attaching lens X: Without lens -: No relation with lens Memory Card --- CF:CF card M: Micro-drive X: Not insert -: No relation with Memory card *Column of Battery DC5.5V - The value is measured between battery contacts in camera.

  • Page 60: Block Diagram

    Block diagram 76180 EM -59/73-...

  • Page 61: Circuit Diagram

    Circuit diagram Refer with block diagram for terminal mark and connection mark. (J, CN) CN1’→CF_card CN2’ CN3’ CN2→I-LCD DGND CR2016 3.3V PGND EEMG ESMG2 ESMG1 SCOM S250- PGND T_Vin CN1” LEDK CN4” LEDA 3.3V S350+ CN3” XSYNC Q_Vin PGND PGND TTLK TTLA SCOM...

  • Page 62: Table Of Error Code (Digital Adjustment)

    Table of Error Code (Digital adjustment) The error code is displayed as “aa-xx-xx-yy-zz” (example: 03-07-01-07-00) to explain the detailed error. aa : Adjustment item when error is happened xx : Not use in service yy : Type of error zz : Contents of error (aa) (bb) (xx)

  • Page 63: Ae Program Line And Apex Chart

    AE Program line (normal) and APEX chart (ISO200) FAJ 18-35mmF4-5.6: Solid line FA50mmF1.4: Dotted lie 76180 EM -62/73-...

  • Page 64: 76180 Program Software Flow Chart

    76180 PROGRAM SOFTWARE FLOW CHART ***** 76180 TEST PROGRAM ***** TURN MAIN SW OF BODY ON. TURN SW OF I/O IF BOX ON. AFTER CONFIRMING ABOVE, PRESS KEY [ 1 ]. AFTER REPLACING MAIN PC BOARD, PRESS KEY [ 2 ]. [ 2 ] [ 1 ] BATTERY LEVEL ADJUSTMENT ( --->...
  • Page 65 ***** MAIN MENU ***** [ 2 ] EXPOSURE ADJUSTMENTS ***** SELECT AE TYPE ***** TYPE 1 ( LV6,8,10,12,16 ) ---- [ 1 ] TYPE 2 ( LV6,9,12,15 ---- [ 2 ] ***** 76180 < A GROUP > ***** BV ADJUSTMENTS --->...
  • Page 66 ***** MAIN MENU ***** [ 3 ] AF AND RELATED ADJUSTMENTS ***** AF ADJUSTMENT MAIN MENU ***** CCD POSITION ADJUSTMENT ---> [ 1 ] AGC LEVEL ADJUSTMENTS ---> [ 2 ] MONITOR OFFSET ADJUSTMENT ---> [ 3 ] UNIFORMITY ADJUSTMENT --->...
  • Page 67 ***** MAIN MENU ***** ***** < B GROUP > ***** ***** CCD POSITION ***** [ 3 ] CCD POSITION CHECK [ 4 ] CCD FOCUS ADJUSTMENT ***** CCD POSITION ADJUSTMENT ***** ***** CCD POSITION ADJUSTMENT ***** ** POSITION CHECK ** ** CCD FOCUS ADJUSTMENT ** MOUNT F ZOOM LENS 35-80 ONTO CAMERA.
  • Page 68 ***** MAIN MENU ***** ***** < B GROUP > ***** [ 2 ] AGC LEVEL ADJUSTMENTS [ 3 ] MONITOR OFFSET ADJUSTMENT [ 4 ] UNIFORMITY ADJUSTMENT [ 5 ] ***** AGC LEVEL ADJUSTMENT ***** SATURATED OUTPUT MOUNT FOCUS MASTER LENS ONTO CAMERA. AND TEMP ADJUSTMENT SET LIGHT SOURCE TO LV 12.
  • Page 69 ***** MAIN MENU ***** ***** < B GROUP > ***** [ 6 ] FOCUS ADJUSTMENT ***** FOCUS ADJUSTMENT ***** AF CHART NO1 HORIZONTAL POSITION AND ADJUSTMENT --- [ 1 ] HORIZONTAL ADJUSTMENT --- [ 2 ] VERTICAL POSITION AND ADJUSTMENT --- [ 3 ] VERTICAL ADJUSTMENT --- [ 4 ]...
  • Page 70 ***** MAIN MENU ***** [ 4 ]NUMBER OF REPAIRS [ 6 ]BATTERY LEVEL [ 7 ] SHUTTER SPEED ADJUSTMENT [ 8 ] ADJUSTMENT FOCUS INDICATION CHECKING ***** NUMBER OF REPAIRS ***** ***** SHUTTER SPEED ADJUSTMENT ***** * SET DRIVE MODE SW OF CAMERA TO CONSECUTIVE-FRAME MODE.

  • Page 71: Information For Prepation

    INFORMATION FOR PREPATION Table of Jigs, Tools and Testers for *istD Exclusive use for 76180 Order No. Programmed software for 76180 (for SLR operation) 95901-P401-00A Programmed software for 76180 (for Digital operation) 95901-P401-00B 76180 Shutter attachment (for shutter tester) 95901-J138 Master lens for 76180 (must order with P401-00B) 95901-D20 DC cord for 76180...
  • Page 72 Others (2) [Common in use for other 35mm AF SLR] Order No. Personal computer (PC/AT) Provide locally Camera multi adapter II (or Multi adapter A) 95901-X100 I/F buffer cable for 27250 95901- X003 Hexagonal driver 1.5mm (HD-M1.5) 95901-K072 Shutter tester (measurable 1/4000ms) Collimator chart with 3 lines 95901-M021 AE master lens (ML-245)

  • Page 73: Method For Marking Power Adapter

    Method for marking power adapter Preparation: Battery grip D-BG1 (Prod.No.79082) and lead wire for powers supply (x2) 1. Remove Y78 x4 2. Remove Y79 x3 and Y80 x2 3. Solder (+) read wire for Y12 4. Solder (-) read wire for Y10 6.

  • Page 74: Af Confirmation Chart And Scale

    AF confirmation chart and scale These charts are for “confirmation of AF focus by ◎ ◎ ◎ ◎ Ｌ ◎ ◎ ＣE taking picture” on page 52. ◎ ◎ ◎ ◎ Ｋ ◎ ◎ ＢE Scale for focus confirmation ◎ ◎ ◎ ◎ Ｊ ◎ ◎ ＡE AF chart for confirmation ◎...
