Parts and features

CONTROL PANEL

DW60M6050F*/DW60M6051F*/DW60M6040F*
DW60M6050U*/DW60M6051U*/DW60M6040U*
DW60M6050S*/DW60M6051S*/DW60M6040S*
2
1
4
3
2
1
4
1 Power
2 Program
3 Half load
4 Control lock
5 Display window
6 Start
7 Delay start
8 Hygiene
9 Multi tab
14_ Part and features
DW5500M-02437D-00_EN.indd 14 DW5500M-02437D-0 _EN.indd 14 1
5
Press this button to turn on your dishwasher: the screen lights up.
To select washing program press this button.
For small amount of loading items, use either the upper or lower basket
only to save energy.
Press the Half load button to select the upper or lower basket.
This option allows you to lock the buttons on the control panel so children
cannot accidentally start the dishwasher by pressing the buttons on the
panel.
To lock and unlock the buttons on the control panel, hold down both the
Control lock buttons for three (3) seconds.
Running indicator, delay time, error codes and etc.
To start a cycle, press the Start button before closing the door.
*Reset : To cancel a currently running cycle and drain the dishwasher,
press and hold the Start button for three (3) seconds.
Once the dishwasher is reset, select a cycle and option, and then press Start
to restart the dishwasher.
Press this button to set the delayed hours for washing. You can delay the
start of washing up to 24 hours. One press on this button delays the start
of washing by one hours.
Push the Hygiene button for the best possible hygiene in your
dishwasher. At the final rinse it heat up to 67 °C and hold this temperature
for a several minutes. This function is available with all program except
Quick Wash and Pre Wash.
To select Multi tap option which needs salt and rinse aid but a Multi tab
tablet. This option can be selected on Intensive, Auto or ECO program
only.
7
DW60M6050
6
DW60M6051
9
8
7
6
DW60M6040
9
