Accuracy
Accuracy is given at 18 o C to 28 o C (65 o F to 83 o F), less than 70 % RH
DC Voltage (Auto-ranging)
Range Resolution
400.0mV 0.1mV
4.000V 1mV
40.00V 10mV
400.0V 100mV
1000V 1V
Input Impedance: 10MΩ.
Maximum Input: 1000V dc or 1000V ac rms.
AC Voltage (Auto-ranging)
Range Resolution
400.0mV 0.1mV
4.000V 1mV
40.00V 10mV
400.0V 100mV
1000V 1V
All AC voltage ranges are specified from 5% of range to 100% of range
Input Impedance: 10MΩ.
AC Response: 50 Hz to 400Hz
Maximum Input: 1000V dc or 1000V ac rms.
DC Current (Auto-ranging)
Range Resolution
400.0uA 0.1uA
4000uA 1uA
40.00mA 10uA
400.0mA 100uA
10A 10mA
Overload Protection: FF500mA / 1000V and F10A / 1000V Fuse.
Maximum Input: 400uA dc on uA range
400mA dc on mA range
10A dc on 10A range.
AC Current (Auto-ranging)
Range Resolution
400.0uA 0.1uA
©Copyright Abacanto Digital SA.
AD-9962
+0.8% of rdg + 2 digits
+1.0% of rdg + 2 digits
AD-9962
+1.0%of rdg + 3 digits
+1.2%of rdg + 5 digits
AD-9962
+1.2% of rdg + 5 digits
+1.5% of rdg + 5 digits
AD-9962
+1.5% of rdg + 5 digits
