- Page 1 TDR s auto-clean USER MANUAL TDR 5 s AC TDR 7 s AC / TDR 7+7 s AC TDR 8 s AC / TDR 8+8 s AC WARNING Read the instructions before using the machine. EN (Original Instruction) 9124464 / 1909...
- Page 2 TDR s auto-clean KEEP THIS USER MANUAL FOR FUTURE USE © 2019 Fri-Jado B.V., Oud Gastel, The Netherlands. We advise you to contact your supplier for the guarantee period and conditions. Further we refer to our General Terms and Conditions for Sales and Delivery that are available upon request.
-
Page 3: Table Of Contents
TDR s auto-clean CONTENTS INTRODUCTION ......................5 General ..........................5 Identification of the unit ..................... 5 Pictograms and symbols ....................5 Safety instructions ......................6 1.4.1 General ........................6 1.4.2 Moving ......................... 7 Hygiene ..........................7 Service and technical support ................... 7 Storage .......................... - Page 4 TDR s auto-clean Adding extra time to the active program ................19 Interrupt a program ......................20 Reset alarm signal ......................20 Power down ........................20 SETTINGS ........................21 General ........................... 21 Overview main parameters ..................... 21 Service Menu ........................21 PROGRAM ........................
-
Page 5: Introduction
TDR s auto-clean INTRODUCTION General This manual is intended for the user of the TDR s AC (Turbo Deli Rotisserie with cleaning feature). The features and controls are being described, along with directions for the safest and most efficient use, in order to guarantee a long life of the unit. All pictograms, symbols and drawings in this manual apply to all TDR s AC models. -
Page 6: Safety Instructions
TDR s auto-clean Safety instructions WARNING The outside of the unit can be very hot. WARNING The maximum load on top of the unit may never exceed 50 kg (110 lbs.). WARNING Risk of slippery floor: Spills may cause slippery surfaces, clean-up promptly. WARNING Always use the brakes on both front wheels: 1.4.1... -
Page 7: Moving
TDR s auto-clean 1.4.2 Moving When moving the unit: • Before moving the unit, first switch off the mains voltage by pulling the plug from the wall socket and empty the fat collecting container. After that, cool-down the unit for at least ten minutes. -
Page 8: Description Of The Unit
Communication through USB / WIFI (optional) enables easy read-out, re-work and creating of programs via a PC. For this, special software is available at Fri-Jado. The unit has an automated cleaning program that cleanses the unit. -
Page 9: Installation And First Use
TDR s auto-clean INSTALLATION AND FIRST USE All packing materials used for this unit are suited for recycling. After unpacking, check the state of the unit. In case of damage, store the packing material, and contact the transporter within fifteen working days after receiving the goods. Unpacking the unit (Single unit shown) 1. -
Page 10: Installation And Positioning
TDR s auto-clean Installation and positioning WARNING Position the unit indoor on a flat and horizontal surface. A temporally inclined plane of maximum 5° is allowed. Positioning: • The user must have sufficient freedom of movement to properly operate the unit. •... -
Page 11: First Use
TDR s auto-clean First use When using the unit for the first time, clean the interior thoroughly with soap suds and heat up the unit, see section 3.3.1. After commissioning discoloration of the cooking/grilling area can occur. ➊ ➋ ➌ ➍... -
Page 12: Operation And Use
TDR s auto-clean OPERATION AND USE Control Panel Main Functions: ON / OFF Recipes Whip/clean touch screen (during count down) Clean Rotisserie Home screen Language Help function Tap or swipe to select function or activate additional screen Step Back (when shown at upper left corner) 12 / 32... -
Page 13: Switching-On The Unit
Whole uncut chickens should always be grilled using the meat forks. This way their natural fat will baste each other, giving a perfectly slender cooking result. Refer to the You-Tube movie: “Fri-Jado instruction for binding and loading chicken”. For preparing chicken or any other poultry, you can work as follows. -
Page 14: Loading The Rotisserie Using V-Shape Spits (Accessory)
TDR s auto-clean 3. Put the meat forks onto the rotor disks in such a way that during grilling the chicken breasts face the operator. 4. Put the points of the meat forks through the appropriate holes in the rotor disks. 5. -
Page 15: Loading The Rotisserie Using Meat Baskets (Accessory)
TDR s auto-clean 4.3.3 Loading the rotisserie using meat baskets (accessory) If you are using meat baskets, act as follows: • With the TDR 5 you must stick the ends of the meat baskets through the appropriate holes of the rotor disks. •... -
Page 16: Grilling Time
3. Take the meat fork at its other end and take it out of the unit. 4. Remove the products from the meat fork. Refer to the You-Tube movie: “Fri-Jado instruction for unloading chicken from a rotisserie”. 4.5.2 Taking out the V-shape spit (accessory) For taking out the V-shape spit you can use the same principle as described in section 4.5.1. -
Page 17: Taking Out The Meat Basket (Accessory)
TDR s auto-clean 4.5.3 Taking out the meat basket (accessory) When taking out the meat basket from the TDR it is best to act as follows: Slightly lift both ends of the meat basket. Move the basket towards either the left or right hand side of the unit. This action unlocks one end of the basket. -
Page 18: Operate
TDR s auto-clean OPERATE Starting a program 1. Press 2. Select the required program. The total duration of the program is shown in minutes next to the program name. 3. Press Pre-heating When the pre-heat function is activated (at manager menu), the unit will start this function after selecting a program. -
Page 19: While Cooking
TDR s auto-clean While cooking WARNING Opening the door during a grilling program or a cleaning program causes the unit to stop and a warning is shown. The unit will continue when the door is closed and pressed. During the cooking process, the display shows a graph with the: •... -
Page 20: Interrupt A Program
TDR s auto-clean Interrupt a program Interrupt temporarily: 1. Press 2. Press to resume the program. Interrupt definitely: Press and then Reset alarm signal When an alarm signal has been set, a message will occur. Press to return to the main menu. Power down If no program is active and no key is touched within the next 60 minutes the unit will switch-off automatically. -
Page 21: Settings
TDR s auto-clean SETTINGS General The settings of the unit can be changed by using the control panel. There are three kinds of settings: • Information • Manager • Service Select to enter the setting menu. The Manager and Service section are password protected. Press to go one level back. -
Page 22: Program
TDR s auto-clean PROGRAM General Enter the recipe menu Adding programs 1. Select 2. Enter the program name. 3. Enter the preheat step (or left blank). 4. Add cooking steps (swipe additional step at the bottom of the screen upwards). 5. -
Page 23: Deleting Programs
TDR s auto-clean Deleting programs Deleting of a program cannot be undone. 1. Select recipe to delete. 2. Select 3. Select 4. Select Yes. 23 / 32... -
Page 24: Cleaning And Maintenance
TDR s auto-clean CLEANING AND MAINTENANCE WARNING Appliance must be disconnected from the power supply during manual cleaning or maintenance and when replacing parts. Do not use aggressive or abrasive materials. These will damage the surface which will make it more difficult to remove dirt. Clean the inside, the removable parts and the accessories thoroughly with cleanser and water before putting the unit into use. -
Page 25: Preparing The Tablet Dispenser
7. Inspect the Rotisserie and clean it manually if necessary. 8. Place the bottom filter and deflector plate. The unit is now ready for use. Contact your supplier for the appropriate Fri-Jado Rotisserie Cleaning Tablets. 25 / 32... -
Page 26: Deep Cleaning
TDR s auto-clean Deep Cleaning WARNING Opening the door during a cleaning program causes the unit to stop and go to fault state. The program will continue when the door is closed. Depending the temperatures you are operating on, pollution will be build up in time due of burning in the fat particles on the walls of the Rotisserie. -
Page 27: Malfunctions And Service
TDR s auto-clean MALFUNCTIONS AND SERVICE Before you contact your supplier/dealer in case of a malfunction, there are some items you can check yourself: • Is the power supply working properly? Check fuses and differential switch. • Has the timer clock been properly set? Item Malfunction Possible action... -
Page 28: Technical Specifications
TDR s auto-clean TECHNICAL SPECIFICATIONS WARNING Consult the identification plate to get the proper specifications of the unit. The electrical data may vary from country to country. European Models Model TDR 5 AC TDR 8 AC TDR 8+8 AC Dimensions Width 885 mm 1050 mm... - Page 29 TDR s auto-clean Notes. 29 / 32...
- Page 30 TDR s auto-clean Notes. 30 / 32...
- Page 31 TDR s auto-clean Notes. 31 / 32...
- Page 32 TDR s auto-clean Fri-Jado B.V. Fri-Jado Inc. Blauwhekken 2 1401 Davey Road, Suite 100 4751 XD Oud Gastel Woodridge IL 60517 The Netherlands Tel: +31 (0) 76 50 85 400 Tel: +1-630-633-7950 www.frijado.com 32 / 32...
