Summary of Contents for Adaptec ACS-100
- Page 1 USB Enclosure ACS-100 User’s Guide...
- Page 2 Copyright ©2004 Adaptec, Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
- Page 3 Limited 1-Year Hardware Warranty 1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from defects in material and workmanship for a period of one (1) year from the date of purchase. If the product should become defective within the warranty period, Adaptec, at its option, will repair or replace the product, or refund the purchaser’s purchase price for the product,...
- Page 4 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Adaptec, Inc. FOR HOME OR OFFICE USE European Union Compliance Statement...
-
Page 5: Table Of Contents
System Requirements Getting Started Checklist Installing the Device Driver–Windows 98SE Only Installing a Disk Drive Connecting and Powering On Next Steps Disconnecting Your USB Enclosure Troubleshooting This User’s Guide explains how to install and connect your ® Adaptec ACS-100 USB Enclosure. -
Page 6: System Requirements
One high-quality USB cable One bag of screws CD, including device drivers and documentation A disk drive is not included in the kit. The Adaptec ACS-100 USB Enclosure supports 3.5-inch IDE hard disk drives. System Requirements To successfully install and use your Adaptec ACS-100 USB Enclosure, your computer must meet these requirements: ®... -
Page 7: Installing The Device Driver–Windows 98Se Only
Getting Started Checklist Complete these steps to install and begin using your Adaptec ACS-100 USB Enclosure: Install the device driver—Windows 98SE only (see below). Install a disk drive (see Connect the enclosure and power it on (see Prepare the disk drive for use (see Installing the Device Driver–Windows 98SE Only... -
Page 8: Installing A Disk Drive
Installing a Disk Drive Before you begin, ensure that you are installing the proper disk drive. The Adaptec ACS-100 USB Enclosure supports 3.5-inch IDE hard disk drives only. Note: You need a Phillips screwdriver to complete this task. To install a disk drive into your USB Enclosure: 1 Use a screwdriver to remove the two screws on the back of the enclosure. - Page 9 4 Place the disk drive into the disk drive tray and secure it, using the four screws included in the kit. 5 Slide the disk drive tray into the enclosure and replace the back panel, then secure it with the screws you removed in page Step 1 on...
-
Page 10: Connecting And Powering On
I position. The LED on the front of the enclosure illuminates. Note: The LED flashes when there’s activity on the disk drive. You have successfully installed and connected your Adaptec ACS-100 USB Enclosure. Next Steps... -
Page 11: Disconnecting Your Usb Enclosure
Disconnecting Your USB Enclosure To disconnect your USB Enclosure from your computer, follow the instructions for your operating system. Windows You must use the Unplug or Eject Hardware Wizard to properly disconnect the USB Enclosure from your computer. To disconnect the enclosure: 1 Click the Unplug or Eject Hardware Wizard icon (shown at right) on your system tray, which is in the bottom right corner of your screen. -
Page 12: Troubleshooting
Troubleshooting If you have problems installing or using your Adaptec ACS-100 USB Enclosure, work through this list of suggestions: Ensure that the disk drive has been properly installed. Try connecting the enclosure to your computer through a different USB port. - Page 13 Adaptec, Inc. 691 South Milpitas Boulevard Milpitas, CA 95035 USA ©2004 Adaptec, Inc. All rights reserved. Adaptec and the Adaptec logo are trademarks of Adaptec, Inc. which may be registered in some jurisdictions. Stock Number: CDP-00042-01-A, Rev. A, LB 12/04...
