  • Page 1 PNOZ mmc7p CC Configurable Control System PNOZmulti Operating Manual­1003066­EN­02...
  • Page 2 Preface This document is the original document. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for internal purposes. Suggestions and comments for improving this documentation will be gratefully received. Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS p®, SafetyEYE®, SafetyNET p®, the spirit of safety® are registered and protected trademarks of Pilz GmbH & Co. KG in some countries.  SD means Secure Digital...
  • Page 3: Table Of Contents

    Content Section 1 Introduction Validity of documentation Using the documentation Definition of symbols Section 2 Overview Scope of supply Unit features Front view Section 3 Safety Intended use System requirements Safety regulations 3.3.1 Use of qualified personnel 3.3.2 Warranty and liability 3.3.3 Disposal 3.3.4 For your safety Section 4 Function description Operation Input and output data Block diagram Section 5 Installation General installation guidelines Connect the base unit and expansion modules Dimensions Section 6 Commissioning General wiring guidelines Connecting the supply voltage Interface assignment Download modified project to the PNOZmulti safety system Connection example Section 7 Operation...
  • Page 4: Operating Manual Pnoz Mmc7P Cc

    Introduction Introduction Validity of documentation This documentation is valid for the product PNOZ mmc7p CC. It is valid until new docu­ mentation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. Using the documentation This document is intended for instruction. Only install and commission the product if you have read and understood this document. The document should be retained for future ref­ erence. Definition of symbols Information that is particularly important is identified as follows: DANGER! This warning must be heeded! It warns of a hazardous situation that poses an immediate threat of serious injury and death and indicates preventive measures that can be taken. WARNING! This warning must be heeded! It warns of a hazardous situation that could lead to serious injury and death and indicates preventive measures that can be taken. CAUTION! This refers to a hazard that can lead to a less serious or minor injury plus material damage, and also provides information on preventive measures that can be taken. NOTICE This describes a situation in which the product or devices could be dam­ aged and also provides information on preventive measures that can be taken. It also highlights areas within the text that are of particular import­ ance. Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 5 Introduction INFORMATION This gives advice on applications and provides information on special fea­ tures. Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 6: Overview

    Overview Overview Scope of supply Unit features Using the product PNOZ mmc7p CC: Expansion module for connection to a base unit from the configurable control system PNOZmulti Mini . The product has the following features: Can be configured in the PNOZmulti Configurator Connection for CC­Link Station addresses from 1 ... 63, selected via rotary switch Station type: Remote Device Occupied stations: 2 24 virtual inputs and outputs on the control system PNOZmulti can be defined in the PNOZmulti Configurator for communication with the fieldbus CC­Link . The number of inputs and outputs can be extended to 128. Please note that when the extended inputs and outputs 24 ­ 127 are used they have different properties (see document entitled "Communication Interfaces"). Max. 1 PNOZ mmc7p CC can be connected to the base unit Plug­in connection terminals: either spring­loaded terminal or screw terminal available as an accessory (see order reference) Please refer to the document "PNOZmulti System Expansion" for the PNOZmulti base units that can be connected. Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 7: Front View

    Overview Front view Legend: X1: CC­Link interface 0 V, 24 V: Supply connections LEDs: – Power – – L Err Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 8: Safety

    Safety Safety Intended use The fieldbus module PNOZ mmc7p CC is an expansion module of the configurable control system PNOZmulti. It is used for communication between the configurable control system PNOZmulti and the CC­Link . CC­Link is designed for fast data exchange at field level. The expansion module CC­Link is a passive subscriber (Slave) in CC­Link. The basic communication functions with CC­Link conform to CC­Link V1.10. The central controller (master) reads input information from the slaves and writes output information to the slaves as part of each cycle. As well as the cyc­ lical transfer of usable data, the expansion module PNOZ mmc7p CC also has diagnostic and commissioning functions. Data traffic is monitored on the Master/Slave side. The expansion module may only be connected to a base unit from the configurable control system PNOZmulti (please refer to the document "PNOZmulti System Expansion" for de­ tails of the base units that can be connected) The configurable control system PNOZmulti is used for the safety­related interruption of safety circuits and is designed for use in: E­STOP equipment Safety circuits in accordance with VDE 0113 Part 1 and EN 60204­1 The expansion module may not be used for safety­related functions. The following is deemed improper use in particular: Any component, technical or electrical modification to the product Use of the product outside the areas described in this manual Use of the product outside the technical details (see chapter entitled "Technical De­ tails"). NOTICE EMC­compliant electrical installation The product is designed for use in an industrial environment. The product may cause interference if installed in other environments. If installed in other environments, measures should be taken to comply with the applicable standards and directives for the respective installation site with regard to in­ terference. System requirements Please refer to the "Product Modifications" document in the "Version overview" section for details of which versions of the base unit and PNOZmulti Configurator can be used for this product. Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 9: Safety Regulations

    Safety Safety regulations 3.3.1 Use of qualified personnel The products may only be assembled, installed, programmed, commissioned, operated, maintained and decommissioned by competent persons. A competent person is someone who, because of their training, experience and current pro­ fessional activity, has the specialist knowledge required to test, assess and operate the work equipment, devices, systems, plant and machinery in accordance with the general standards and guidelines for safety technology. It is the company’s responsibility only to employ personnel who: Are familiar with the basic regulations concerning health and safety / accident preven­ tion Have read and understood the information provided in this description under "Safety" And have a good knowledge of the generic and specialist standards applicable to the specific application. 3.3.2 Warranty and liability All claims to warranty and liability will be rendered invalid if The product was used contrary to the purpose for which it is intended Damage can be attributed to not having followed the guidelines in the manual Operating personnel are not suitably qualified Any type of modification has been made (e.g. exchanging components on the PCB boards, soldering work etc.). 3.3.3 Disposal When decommissioning, please comply with local regulations regarding the disposal of electronic devices (e.g. Electrical and Electronic Equipment Act). 3.3.4 For your safety The unit meets all the necessary conditions for safe operation. However, you should always ensure that the following safety requirements are met: This operating manual only describes the basic functions of the unit. The expanded functions are described in the PNOZmulti Configurator's online help. Only use these functions once you have read and understood the documentations. Do not open the housing or make any unauthorised modifications. Please make sure you shut down the supply voltage when performing maintenance work (e.g. exchanging contactors). Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 10: Function Description

    Function description Function description Operation The virtual inputs and outputs that are to be transferred via the fieldbus CC­Link are selec­ ted and configured in the PNOZmulti Configurator. The base unit and the fieldbus module PNOZ mmc7p CC are connected via a jumper. After the supply voltage is switched on or the PNOZmulti control system is reset, the fieldbus module PNOZ mmc7p CC is configured and started automatically. LEDs indicate the status of the fieldbus module CC­Link. The configuration is described in detail in the PNOZmulti Configurator's online help. Input and output data The data is structured as follows: Input area – Inputs on PNOZmulti Configurator: i00 … i23 – Input data CC­Link: RYn, RY1n with n = 0 … F Example: i23 ­> RY17 RY0n i15 i14 i13 i12 i11 i10 i09 i08 i07 i06 i05 i04 i03 i02 i01 i00 RY1n ­ ­ ­ ­ ­...
  • Page 11: Block Diagram

    Function description Block diagram 24 V 0 V 24 V 0 V Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 12: Installation

    Installation Installation General installation guidelines The unit should be installed in a control cabinet with a protection type of at least IP54. Fit the safety system to a horizontal mounting rail. The venting slots must face upwards and downwards. Other mounting positions could destroy the safety system. Use the notch on the rear of the unit to attach it to a mounting rail. In environments exposed to heavy vibration, the unit should be secured using a fixing element (e.g. retaining bracket or end angle). Push the unit upwards or downwards before lifting it from the mounting rail. To comply with EMC requirements, the mounting rail must have a low impedance con­ nection to the control cabinet housing. The ambient temperature of the PNOZmulti units in the control cabinet must not exceed the figure stated in the technical details, otherwise air conditioning will be required. CAUTION! Damage due to electrostatic discharge! Electrostatic discharge can damage components. Ensure against discharge before touching the product, e.g. by touching an earthed, conductive sur­ face or by wearing an earthed armband. Connect the base unit and expansion modules Connect the base unit and the expansion module as described in the operating instructions for the base units. Connect the black/yellow terminator to the expansion module. Install the expansion module in the position in which it is configured in the PNOZmulti Configurator. Dimensions Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 13: Commissioning

    Commissioning Commissioning General wiring guidelines The wiring is defined in the circuit diagram of the PNOZmulti Configurator. Please note: Information given in the "Technical details" must be followed. Use copper wiring with a temperature stability of 75°C. Always connect the mounting rail to the protective earth via an earthing terminal. This will be used to dissipate hazardous voltages in the case of a fault. The power supply must meet the regulations for extra low voltages with protective sep­ aration. CAUTION! Only connect and disconnect the expansion module when the supply voltage is switched off. NOTICE When installing, you must refer to the guidelines of the CANopenUser Group. Connecting the supply voltage Connect the supply voltage to the fieldbus module: Terminal 24 V: + 24 V DC Terminal 0 V: 0 V Interface assignment It is possible to define which outputs on the safety system will communicate with CC­Link. The connection to CC­Link is made via a 5­pin screw connector. FG/PE DB DG SLD 1: DA (Channel A) 2: DB (Channel B) 3: DG (Earth) Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 14: Download Modified Project To The Pnozmulti Safety System

    Commissioning 4: SLD (Cable shield) 5: FG/PE (Functional earth) Download modified project to the PNOZmulti safety system As soon as an additional expansion module has been connected to the system, the project must be amended using the PNOZmulti Configurator. Proceed as described in the operat­ ing instructions for the base unit. NOTICE For the commissioning and after every program change, you must check whether the safety devices are functioning correctly. Connection example PNOZ mmc7p CC Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 15: Operation

    Operation Operation When the supply voltage is switched on, the PNOZmulti safety system copies the configur­ ation from the chip card. The LEDs “POWER”, “DIAG”, “FAULT”, “IFAULT” and “OFAULT” will light up on the base unit. The expansion module PNOZ mmc7p CC is configured and started automatically. Messages Legend: LED on LED flashes LED off Meaning Power green Supply voltage is present Supply voltage is not present Green Bus connection available Bus connection is not available Status: timeout No supply voltage at the fieldbus module PNOZ mmc7p CC L Err Fault detected: Wrong station address or transmission rate Flashes evenly: setting has been changed during operation and PNOZ mmc7p CC has not been restarted Flashes unevenly: faulty connection, e.g. terminating resistor is missing Bus connection available No supply voltage at the fieldbus module PNOZ mmc7p CC Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 16: Technical Details

    Technical Details Technical Details General Approvals CCC, CE, GOST Electrical data Supply voltage Module supply Voltage 24 V Kind Voltage tolerance ­20 %/+25 % Output of external power supply (DC) 1,5 W Status indicator Fieldbus interface Fieldbus interface CC­Link V1.10 Unit type Slave Station address 1 ... 63d Transmission rates 10 MBit/s, 156 kbit/s, 2,5 MBit/s, 5 MBit/s, 625 kbit/ Connection 5­pin Combicon plug­in connector Assigned stations Galvanic isolation Test voltage 500 V AC Times Supply interruption before de­energisation 20 ms Environmental data Ambient temperature In accordance with the standard EN 60068­2­14 Temperature range 0 ­ 60 °C Forced convection in control cabinet off 55 °C Storage temperature...
  • Page 17 Technical Details Environmental data Airgap creepage In accordance with the standard EN 61131­2 Overvoltage category Pollution degree Rated insulation voltage 30 V Protection type In accordance with the standard EN 60529 Mounting area (e.g. control cabinet) IP54 Housing IP20 Terminals IP20 Potential isolation Potential isolation between Fieldbus and module voltage Type of potential isolation Functional insulation Rated surge voltage 500 V Mechanical data Mounting position Horizontal on top hat rail DIN rail Top hat rail 35 x 7,5 EN 50022 Recess width 27 mm Material Bottom Front Conductor cross section with screw terminals 1 core flexible 0,25 ­ 2,50 mm², 24 ­ 12 AWG 2 core with the same cross section, flexible with crimp connectors, no plastic sleeve 0,20 ­ 1,50 mm², 24 ­ 16 AWG 2 core with the same cross section, flexible without...
  • Page 18: Order Reference

    Order reference Order reference Product Product type Features Order no. PNOZ mmc7p CC Fieldbus module, CC­Link 772035 Accessories Connection terminals Product type Features Order no. Spring terminals Spring­loaded terminals, 1 pieces 783 542 PNOZ mmcxp 1 pc. Spring terminals Spring­loaded terminals, 10 pieces 783 543 PNOZ mmcxp 10 pcs. Screw terminals Screw terminals, 1 piece 793 542 PNOZ mmcxp 1 pc. Screw terminals Screw terminals, 10 pieces 793 543 PNOZ mmcxp 10 pcs. Terminator, jumper Product type Features Order no. PNOZ mm0.xp connector Jumper yellow/black to connect the modules, 1 piece 779 260 left Operating Manual PNOZ mmc7p CC 1003066­EN­02...
  • Page 19 Back cover Support Technical support is available from Pilz round the clock. Americas Australia Scandinavia Brazil +61 3 95446300 +45 74436332 +55 11 97569-2804 Spain Canada Europe +34 938497433 Switzerland +1 888-315-PILZ (315-7459) Austria +43 1 7986263-0 +41 62 88979-30 Mexico...
