- Page 1 DSP 9612 Flash Poll Modem User’s Guide Complements of ARC Electronics 800-926-0226 arc@arcelect.com www.arcelect.com 0049−0117−100 Rev. A...
-
Page 2: Table Of Contents
CHAPTER 1 INTRODUCTION... 5 ... 6 EATURES ... 7 PPLICATIONS CHAPTER 2 INSTALLATION ... 9 NPACKING ARDWARE DDITIONAL TEMS ARDWARE VERVIEW Back View ... 10 Front View ... 11 NSTALLATION UMMARY INDING A UITABLE ONFIGURING THE ODEM SW1 DIP Switch Settings... 14 SW2 DIP Switch Settings... - Page 3 Contents OTES Page iv...
-
Page 4: Chapter 1 Introduction
The Telenetics DSP9612 (Flash Poll) modem is a 9600/4800/0- 1800 bps modem designed for 4-wire, full-duplex or 2-wire, half- duplex operation over a voice-band leased line or private line. The modem is designed utilizing the latest digital-signal processing (DSP) technology to achieve high performance. -
Page 5: Features
Introduction Features The DSP9612 modem is specifically designed for harsh environments found in utility substations and industrial facilities. Though functionally similar to commercial modems, the DSP9612 provides the following unique features that make it well suited for utility and industrial applications. Packaged in a rugged, compact enclosure for industrial applications. -
Page 6: Applications
Applications The DSP9612 modem is designed for point-to-point and multipoint data communications. Figure 1-1 shows a typical multipoint configuration. Figure 1-1. Network of Multipoint Configuration There are a number of factors that can affect the network’s and modem’s operation and performance. These include: Operating speed 2-wire or 4-wire configuration Transmission line characteristics, noise, and line impairments... - Page 7 Introduction OTES Page 8...
-
Page 8: Additional Item You Need
his chapter describes how to install the modem. Unpacking Your Hardware Your package should include: At least one of the following DSP9612 modems: − Model DSP9612FP for 85 to 265 VAC − Model DSP9612-LV for 10 to 53 VDC A leased-line cable A shielded DC power cable (model DSP9612-LV modem only) This User’s Guide If your package contents are damaged or missing, please contact your... -
Page 9: Hardware Overview
Installation A power supply that provides either: − 85 to 265 Volts AC, 50 to 60 Hz, single phase or 85 to 400 VDC (if you have the model DSP9612FP modem), or − 10 to 53 Volts DC (if you have the model DSP9612-LV modem) Hardware Overview Back View... -
Page 10: Front View
Figure 2-2. Back View of Model DSP9612-LV Modem Front View The Model DSP9612FP and Model 9612-LV modems have identical front panels. Figure 2-3 shows the front view of the modem. Starting from the left side, this view shows: A set of nine LEDs. See page 29. A loopback test switch. -
Page 11: Installation Summary
The location you select should provide easy access to the back panel communications interface(s) and front panel power interface. It should also let you view all the LEDs on the front panel. Telenetics also offers a rack-mount version of this modem Note: (Model DSP9612RM) as a plug-in module for the Telenetics/UDS RM16M Central Site Modem Rack. -
Page 12: Configuring The Modem
Configuring the Modem You configure the modem using the three sets of DIP switches on the bottom of the modem. It is important to follow the three steps described below, in the order shown, to ensure that you configure IMPORTANT your modem properly using the modem DIP switches: 1. -
Page 13: Sw1 Dip Switch Settings
Installation SW1 DIP Switch Settings SW1 is an 8-position DIP switch. Table 2-1 shows the modem switch settings for DIP switch SW1. A description of the SW1 switch settings follows the table. SW1 settings apply for both high-speed fast-poll and low- Note: speed (FSK) modes Table 2-1. - Page 14 SW1-1 through SW1-4 − Transmit Level Switches SW1-1 through SW1-4 adjust the modem’s transmit level. Table 2-2 shows the transmit levels you can select using these switches. Table 2-2. Transmit Levels Transmit Level 0 dBm −1 dBm −2 dBm −3 dBm −4 dBm −5 dBm −6 dBm...
- Page 15 Installation SW1-5 − Receiver Dynamic Range 10 to −43 dBm SW1-5 − ON = OFF = +3 to −30 dBm For a low receive signal level, set SW1-5 to ON (−43 dBm ). For short distances or to select a strong receive signal, set SW1-5 to OFF. SW1-6 and SW1-7 −...
-
Page 16: Sw2 Dip Switch Settings
SW2 DIP Switch Settings SW2 is an 8-position DIP switch. Table 2-3 shows the modem switch settings for DIP switch SW2. A description of the SW2 switch settings follows the table. Table 2-3. Modem Switch Settings for DIP Switch SW2 Switches SW2-1: FSK Mode (page 18) SW2-2: Receiver Squelch (page 18) - Page 17 Installation SW2-1 FSK Mode SW2-1 ON = ITU-T V.23 mode OFF = Bell 202 mode The modem has two FSK modes: Bell 202, which supports data rates from 0 to 1800 bps ITU-T V.23, which supports data rates from 0 to 1200 bps SW2-1 configures the modem for either of these FSK modes.
- Page 18 wire, half-duplex mode (SW3-7 ON), the modem squelches the receiver after RTS is turned off to prevent far-end echoes from causing data errors. The duration that the modem squelches the receiver is either: 8 milliseconds if the modem is configured for Bell 202 mode (SW2-1 OFF) 150 milliseconds if the modem is configured for ITU-T V.23 mode (SW2-1 ON)
- Page 19 Installation When the modem is configured for V.23 operation (SW2-1 ON), the RTS-CTS delay is fixed at 33 ms. SW2-6 FSK CD Delay (Bell 202 Mode Only) SW2-6 ON = 23ms OFF = 6ms SW2-6 selects the FSK CD delay and is valid when Bell 202 mode is active (SW2-1 OFF).
-
Page 20: Sw3 Dip Switch Settings
SW3 DIP Switch Settings SW3 is a 10-position DIP switch. Table 2-5 shows the modem switch settings for DIP switch SW3. A description of the SW3 switch settings follows the table. Table 2-5. Modem Switch Settings for DIP Switch SW3 Switches SW3-1: Fast Poll/FSK (page 22) SW3-2: Data Rate (page 23) - Page 21 Installation SW3-1 − Fast Poll Auto Rate/FSK SW3-1 ON = Low-Speed Mode (FSK) OFF = High-Speed Mode (Fast Poll) The modem has two operating modes: FSK mode, which supports data rates from 0 to 1800 bps. Fast-poll mode, which supports data rates of 4800 and 9600 bps. SW3-1, along with the Data Rate Selector (DRS) pin on the modem’s RS-232 connector, configures the modem for either FSK or fast-poll mode.
- Page 22 SW3-2 − Data Rate (Fast-Poll Mode Only) SW3-2 ON = 4800 bps OFF = 9600 bps SW3-2 configures the modem speed. When the modem is in high- speed fast-poll mode (SW3-1 OFF), setting SW3-2 ON selects 4800 bps, while setting SW3-2 OFF selects 9600 bps. SW3-3 −...
- Page 23 Installation SW3-5 − Transmitter Termination SW3-5 ON = Switched by RTS OFF = 600 Ω SW3-5 is used for multi-point configuration networks. When multiple modems are connected on the same metallic circuit: The transmitter termination should be of high impedance if the modem is not transmitting.
- Page 24 SW3-8 − Carrier Control SW3-8 ON = Constant OFF = Switched SW3-8 selects either constant or switched carrier. Constant carrier allows DTEs, such as asynchronous dumb terminals or RTUs, to operate with modems, without the input RTS signal. When constant carrier mode is enabled (SW3-8 set to ON), the modem forces the transmit carrier active and the RTS-CTS delay is minimum (<0.5 ms.).
-
Page 25: Connecting To A Transmission Line
Installation Connecting to a Transmission Line The modem has a transmission line interface that can be configured for 2- or 4-wire, analog connection, where one pair is used to transmit data (Tx and Tx) and one pair is used to receive data (Rx and Rx). Table 2-7 shows the pin numbers and corresponding signals for the modem. -
Page 26: Connecting To A Voltage Source
Figure 2-4. Transmission Line Interface Connecting to a Voltage Source The back panel of the modem provides the power interface. For convenience, the modems can be powered from the following power sources: Model DSP9612FP (AC version): 85 to 265 Volts AC, 50 to 60 Hz, single phase or 85 to 400 VDC Model DSP9612-LV (DC version): 10 to 53 Volts DC. -
Page 27: Connecting An Rs-232 Device
Installation Before you connect a voltage source, observe the following power supply voltage guidelines. WARNING Otherwise, you will void your warranty if the wrong voltage is applied. Be sure the voltage source is within the permitted ranges shown above. Otherwise, your modem and any attached devices may be damaged. -
Page 28: Leds
LEDs The front panel of the modem provides the LEDs shown in Table 2-8. * When the modem is in remote loopback, both the ALB and DLB LEDs go ON. Table 2-8. Modem LEDs Color Green Yellow Yellow Yellow Yellow Yellow Yellow Red*... -
Page 29: Loopback Control Switch
Installation Loopback Control Switch The front panel of the modem has a push button for initiating the following loopback diagnostic tests: Local analog loopback started by pressing the button one time. Local digital loopback started by pressing the button two times. Remote digital loopback ... -
Page 30: Appendix A Troubleshooting
Telenetics modem, refer to the troubleshooting information in this appendix. If you encounter a problem with your modem, be sure the switches on the bottom of the modem are set to the IMPORTANT appropriate positions. - Page 31 Troubleshooting Table A-1. Troubleshooting Suggestions If… The RTS, CTS, and TxD LEDs do not blink. Perform These Procedures… problem. The attached terminal or DTE may not be sending data to the modem. Verify that data is being transmitted. If data is being transmitted, make sure the RS- 232 cable is sound and securely connected to the modem and terminal...
-
Page 32: Appendix Bdip Switch Summary
DIP Switch Summary Switches SW1-1 − 1-4: Transmit Level (page 15) SW1-5: Receiver Dynamic Range (page 16) SW1-6: TX Cable Equalizer (page 16) SW1-7: RX Cable Equalizer (page 16) SW1-8: Anti-streaming (page 16) SW2-1: FSK Mode (page 18) SW2-2: Receiver Squelch (page 18) (valid for FSK mode, 2-wire half-duplex operation only) SW2-3: FSK Soft Carrier (page 19) - Page 33 DIP Switch Summary Switches SW3-1: Fast Poll/FSK (page 22) SW3-2: Data Rate (page 23) SW3-3: Async Character (page 23) SW3-4: Auto RTS (page 23) SW3-5: Transmitter Termination (page SW3-6: Reserved (Test Only) (page 24) Test SW3-7: 2- or 4-wire (page 24) SW3-8: Carrier Control (page 25) SW3-9: Rx Termination (page25) SW3-10: Signal Ground and Earth...
-
Page 34: Appendix C Specifications
AWG) without cable equalizer. Up to 15.0 miles (24 AWG) with TX and RX cable equalizer 2-wire half-duplex or 4-wire full-duplex High-speed fast poll – Telenetics proprietary FSK, Bell 202T or V.23 compatible • Mark = 1200 Hz (1300 Hz, V.23) •... -
Page 35: Mechanical Specifications
Specifications Receiver dynamic range: Operating temperature: Power supply: Surge protection: Carrier control: Carrier loss recovery: Throughput delay: Less than 10 milliseconds for fast polling. Auto RTS: Anti-Streaming: Mechanical Specifications Enclosure: Dimensions: Weight: Interface connectors Leased line: Data Terminal Equipment: 0 to –30 dBm or –10 to –43 dBm -40°C to +85°C Wide range switching power supply: •... -
Page 36: Interface Connector Pin Assignments
Interface Connector Pin Assignments Leased Line Terminal Block Pin Assignments This Pin Number… Back-to-Back Connection to a Second Modem Interface Connector Pin Assignments Corresponds to This Signal… Page 37... -
Page 37: Rs-232 (Dte) Interface
Specifications RS-232 (DTE) Interface Signal Name Modem Input/Output Earth GND Environmental Specifications Operating temperature: -40 to + 85 Storage temperature: Operating humidity: Line Isolation: Surge protection: DB25 Pin Input Output Input Output Output Output Input -40 to +125 5 to 95 %, non-condensing. -
Page 38: Compliances
Compliances The modem is designed to meet the following agency requirements: EMI/RFI: FCC part 15 for Class A computing device Industry Canada. (Emissions) Page 39 Compliances... - Page 39 Specifications OTES Page 40...
-
Page 40: Appendix D Compliances
This device complies with Part 15A of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15A of the FCC Rules. - Page 41 Compliances Department of Canada Statement This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numerique de la classe A respecte toutes les exigences du Reglement sur le materiel brouilleur du Canada. Page 42...
-
Page 42: Appendix E Limited Product Warranty
Lake Forest, California (or, at Telenetics' option refunding the purchase price of such products). In no case are Products to be returned without first obtaining permission and a customer return order number from Telenetics. In no event shall Telenetics be liable for any consequential or incidental damages. -
Page 43: Appendix Frma Procedure
Lake Forest, CA 92630 The RMA number must be legibly displayed on the shipping carton. No RMA’s will be issued without a product review, Telenetics will not be responsible for any product returned without an RMA number. In the near future the RMA form will be available on our Web site Telenetics.com/support/rma. - Page 44 RMA Procedure Page 45...
