Telenetics Sunrise Series Modular Nest Installating And Operation Manual

Modem cards, backplanes, and modular nest 9 and 21 enclosures
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
In This Notice
Modem Cards, Backplanes, and Modular Nest 9 and 21 Enclosures
Topic
Introduction ...............................................................................................
For More Details on the 326X Modem's... ...........................................
Safety Information.........................................................................................
Warning Description .................................................................................
Connecting Port Warning ..........................................................................
Installation Warning ..................................................................................
Pre-Installation Information and Activities ...................................................
326X Series Modem Cards and Backplanes .............................................
326X Series Modem Cards ...................................................................
326X Series Modem Card Backplanes .................................................
A/B Switching and the A/B LED .........................................................
ALM LED.............................................................................................
Telephone Company Compliance-U.S.A. Models .................................
Backplane Jumpers for the Busy Out Feature...........................................
Hong Kong and the United Kingdom ...................................................
Countries That Support Busy Out.........................................................
How and When is Make Busy Activated? ............................................
Setting the Modem Card DIP Switch........................................................
Setting Control Across Groups .............................................................
Example ................................................................................................
Removing a 326X Backplane....................................................................
Installing or Replacing a 326X Backplane................................................
Part No. TEL-09949, Rev A
326X SERIES MODEM
June 2001
Page 1 of 34
See Page
2
2
2
3
3
3
4
5
5
5
5
6
6
6
7
7
7
8
8
12
14
16
16
18
22
22
23
24
26
26
27
28
30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sunrise Series Modular Nest and is the answer not in the manual?

Questions and answers

Related Manuals for Telenetics Sunrise Series Modular Nest

Summary of Contents for Telenetics Sunrise Series Modular Nest

  • Page 1: Table Of Contents

    In This Notice Topic Introduction ... About the 326X Series Modem Documentation Set... For More Details on the 326X Modem’s..Safety Information... Warning Description ... Connecting Port Warning ... Installation Warning ... Pre-Installation Information and Activities ... 326X Series Modem Cards and Backplanes ... 326X Series Modem Cards ...

  • Page 2: June

    • NetView’s LPDA-2 dialing commands • Diagnostic tests ...refer to the 326X Series Modem Reference Guide, which you can order through your Telenetics sales representative or local distributor. operating 326X Series Modem card(s) in the Modular Nest 9 and 21 Enclosure Nest 9 or 21 enclosure Part No.

  • Page 3: Safety Information

    Safety Information Safety Information This section explains how Warning Notices are used in Telenetics’ documentation, and it provides such notices for users of the 326X Series Modem. Warning Description The following notice emphasizes certain information. In documentation, it is displayed in the format shown: Warning Warning is the most serious notice, indicating that you can be physically hurt.

  • Page 4: Installation Warning

    Safety Information Installation Warning Warning All Telenetics devices should be used in environments designed for computers and electronic equipment. In areas susceptible to lightning, take precautions to prevent damage to electronic equipment. Contact your telephone company, or an electronic accessories vendor, for information on lightning protection equipment. Customers...

  • Page 5: Pre-Installation Information And Activities

    Pre-Installation Information and Activities Pre-Installation Information and Activities This section provides information about 326X Series Modem card models 3262, 3263, 3267 and 3268. It describes activities you must complete before installing and operating 326X Series Modem card(s) in a Modular Nest enclosure. 326X Series Modem Cards and Backplanes This section describes 326X Series Modem cards and backplanes, and items shipped with them.

  • Page 6: Stand-Alone Modems And Enclosure Cards: Differences

    Pre-Installation Information and Activities Stand-alone Modems and Enclosure Cards: Differences The 326X Series Modem card front panel differs from that of the stand-alone 326X Series Modem. As shown in Figure 1, the 3262, 3263, 3267, and 3268 Modem cards have eight front-panel LEDs. Stand-alone 326X Series Modems do not have two of these: •...

  • Page 7: Telephone Company Compliance-U.s.a. Models

    Pre-Installation Information and Activities Telephone Company Compliance—U.S.A. Models The Telenetics 326X Series Modem complies with Part 68 of the FCC rules. The modem card includes a label with the FCC registration number for this equipment. If requested by the telephone company, you must provide this information. Generally, the ringer equivalence number (REN) is also requested for telephone equipment.

  • Page 8: Countries That Support Busy Out

    Pre-Installation Information and Activities Countries That Support Busy Out Some backplanes have a Busy Out feature and are intended for use with dial modems (models 3262 and 3267). In some countries, leased modems (models 3263 and 3268) use Busy Out for dial restoral. The following table shows which countries use the Busy Out feature.
  • Page 9 Removal by unqualified personnel could result in personal injury or equipment damage, which could jeopardize your warranty and maintenance agreement. Users who are not qualified to perform this action themselves should contact Telenetics or an authorized distributor regarding available upgrade services. Function U.
  • Page 10 Werden diese Komponenten von unqual- ifiziertem Personal entfernt, kann dies Verlet- zungen von Personen oder Geräteschäden zur Folge haben und Ihre Garantie- und Wartungsv- ereinbarung gefährden. Anwender, die keine Berechtigung zum Durchführen dieses Vorgangs besitzen, sollten Upgradedienste von Telenetics oder einem autorisierten Händler anfordern.
  • Page 11 Pre-Installation Information and Activities Refer to Figure 2, which shows pin locations on Modular Nest 21 backplanes. Modular Nest 9s have a similar layout. Jumpers on Left Pin Pairs Figure 2. Modular Nest Backplane Pin Locations (Modular Nest 21 Shown) Caution If you use a 3263 or 3268 (leased line with dial restoral) modem card with a Busy Out backplane, remove jumpers from all four pins, or the modem in that slot will not...

  • Page 12: Setting The Modem Card Dip Switch

    Part No. TEL–09949, Rev A June 2001 Pre-Installation Information and Activities Page 12 of 34 Setting the Modem Card DIP Switch An 8-position DIP (Dual Inline Package) switch on the modem card functions the same as the rear panel DIP switch on stand-alone modems. The switches are numbered from left to right on the card (Figure 3).
  • Page 13 Pre-Installation Information and Activities Table 3. Modem Rear Panel DIP Switch Functions Switch Number 1 (Modem A only) 7 (Modem B only) 2 (Modem A only) 8 (Modem B only) 3 (Modems A and B) Off 4 (Modems A and B) Off 5 (Modems A and B) Off 6 (Modems A and B) Off Setting...

  • Page 14: Cabling The 3262 And The 3267 (Dual Dial) Modem Cards

    Pre-Installation Information and Activities Cabling the 3262 and the 3267 (Dual Dial) Modem Cards Refer to Figure 4 for cabling of 3262 and 3267 (dual dial) Modem cards. Interface and cabling pin-outs vary by country. Refer to the 326X Series Modem User’s Guide, Appendix C, Country-Specific Information, for interface and cable pin-outs.

  • Page 15: Cabling The 3263 And The 3268 (Leased Line, Dial Restoral) Modem Cards

    Pre-Installation Information and Activities Cabling the 3263 and the 3268 (Leased Line, Dial Restoral) Modem Cards Refer to Figure 5 for cabling of 3263 and 3268 (leased line with dial restoral) Modem cards. Interface and cabling pin-outs vary by country. Refer to the 326X Series Modem User’s Guide, Appendix C, Country-Specific Information, for interface and cable pin-outs.

  • Page 16: Attaching Ferrite Beads (U.s.a., Canada, And Japan Only)

    Pre-Installation Information and Activities Attaching Ferrite Beads (U.S.A., Canada, and Japan Only) A cable with an attached ferrite is included in the accessory kit for U.S.A., Canada, and Japan 326X Series Modem cards. In order to meet FCC Class A and CISPR requirements, the ferrite side of the dial and leased line cables must be attached as close to the backplane as possible (Figure 6).
  • Page 17 Pre-Installation Information and Activities To release the connector: 1) Insert a small screwdriver beneath the clip on the bottom of the connector (Figure 7). 2) Press down on the screwdriver to release the clip and gently pull to remove the connector from its receptacle on the backplane. Part No.

  • Page 18: 326X Series Modem-Cabling To A Network Manager

    Pre-Installation Information and Activities 326X Series Modem—Cabling to a Network Manager This section describes how to set the 326X Series Modem backplane NMS Bus DIP switches for network management. It also describes the proper sequence for connecting to a Network Management System (NMS). When cabling 326X Series Modem enclosure cards to a network manager: •...
  • Page 19 Pre-Installation Information and Activities Figure 8 shows a single NC command flow path. In the figure, the local masters receive network control from a single network manager source. Modular Nest 9 or 21 Enclosure Network Backplane Manager In-Connector from Backplane. For Any Daisy-Chained Device.
  • Page 20 Pre-Installation Information and Activities A group’s network management signaling is passed along a multi-drop bus in the backplane to each NC port. One slot of each group is the Bus Master slot (NC 1 for group 1, NC 2 for group 2, etc.). The group number is identified by the Bus Master slot number (e.g., Group 1 uses Bus 1 Master slot).
  • Page 21 Pre-Installation Information and Activities NC Port and Bus Master Slots Are within Shaded Areas NC BUS MSTR MSTR +5V +12V -12V COMM Network Control Group 4 Network Control Group 3 Figure 10. NC Port Locations, Bus Master Locations, and Groups (21-Card Backplane) NC BUS MSTR...

  • Page 22: Setting Control Across Groups

    Pre-Installation Information and Activities Setting Control Across Groups You can use cables to daisy-chain NC ports on 326X Series Modem cards, as you can with stand-alone modems. With 9- and 21-card backplanes, you can also set NMS Bus DIP switches on the backplane so that all NC signaling is bussed to one NC Port. To bus two or more groups’...

  • Page 23: Cautions And Limitations For Network Management Cabling

    Pre-Installation Information and Activities DIAL LINE A 2W LEASE DIAL LINE B 2W/4W LEASE SLOT9 MSTR Figure 11. Combining NC Ports With Backplane NMS Bus DIP Switches Cautions and Limitations for Network Management Cabling The enclosure daisy-chain (leased line) interface and the multi-drop (dial line) bus features do not support certain NC cabling applications.

  • Page 24: Daisy-Chaining Nc Ports: Card Modems To Stand-Alone Modems

    Part No. TEL–09949, Rev A June 2001 Pre-Installation Information and Activities Page 24 of 34 If the application requires more NC slaves than the larger backplanes have groups, connect multiple backplanes in the enclosure using the 1-card backplane. When combining backplanes in an enclosure, one modem card slot is lost for each type of backplane that is used.
  • Page 25 Pre-Installation Information and Activities There are two ways to determine your modem’s software revision number. From the modem front panel: 1) Press the appropriate front panel control key (from your location in the 2) Press 3) Press 4) Press The rightmost two digits indicate the software revision level. Ensure that they are Using an AT Command: Enter AT&IO from the control terminal.

  • Page 26: Preparing The 9110 Dms For 326X Series Card Modems

    Pre-Installation Information and Activities Preparing the 9110 DMS for 326X Series Card Modems When managing 326X Series Modems in an enclosure using the 9110 Dial Management System (DMS), set the Use option (in the 9110 Comm Port Definition screen) to Complete. This configures the 9110 to poll all modems (see “Polling” in Chapter 1 of the 9110 DMS User's Guide) even if one modem is not responding.

  • Page 27: Removing And Installing A Backplane In Modular Nest 9 Or 21 Enclosure

    Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure This section explains how to remove and install a 326X backplane attached to a Modular Nest 9 and 21 enclosure. Use this information with the Modular Nest 9 and 21 Installation and Operation Guide (Part No.

  • Page 28: Removing A 326X Backplane

    Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure Removing a 326X Backplane Caution Power down the unit before you begin. To remove a backplane from a Modular Nest 9 or 21 enclosure (Figure 14): 1) Ensure that the enclosure is powered down. 2) Remove all cards from the front of the enclosure.
  • Page 29 Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure Push and Turn in Direction of Arrow Avoid Bending These Male Pins Figure 14. Removing a 326X Backplane Part No. TEL–09949, Rev A June 2001 Page 29 of 34...

  • Page 30: Installing Or Replacing A 326X Backplane

    Remove the backplane (using the procedure above), and carefully straighten any bent or broken pins. Reinsert the backplane (using this procedure). If you cannot resolve a problem, call the Telenetics Customer Support Center. 7)Re-install the cards and power supplies that were removed when you removed the backplane.
  • Page 31 Part No. TEL–09949, Rev A June 2001 Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure Page 31 of 34 Push and Turn in Direction of Arrow Figure 15. Installing or Replacing a 326X Backplane...
  • Page 32 Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure Numerics 3262 5, 8, 12, 14, 3263 5, 8, 11, 3267 5, 8, 12, 14, 3268 5, 8, 11, 9110 DMS and the 326X Series Modem A/B LED A/B switching ALM LED audio cables...
  • Page 33 Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure EN60950 FCC Part 68 ferrite 5, 14, 15, ferrite cable attaching to card models front panel Hong Kong 7, installation warning interface 14, Ireland jack Japan 5, jumper 7, leased line LEDs ALM LED...
  • Page 34 Removing and Installing a Backplane in Modular Nest 9 or 21 Enclosure ringer equivalence number (REN) safety information safety standard SELV slot stand-alone modem surge Sweden Switzerland TBTS test mode U.S.A. 5, 8, United Kingdom 7, Universal International USOC Warning Warnung 3, Part No.
