Before initial Operation

⇒
Mount print mechanics.
⇒
Connect all cables between print mechanics and control unit.
⇒
Protect cables against unintentional unscrewing.
⇒
Connect compressed air line.
⇒
Connect control unit and PC by printer interface.
⇒
Connect control unit and packaging machine by inputs and outputs.
⇒
Connect power cable of control unit.

Print control

Because of the fact that the print module is always in control mode it is only possible to transmit and not to start print orders by
the available interfaces (serial, USB or Ethernet). The print is started by a start signal to the 'print start-control input'. It is
necessary for the control unit to recognise the moment of setting the start signal and therefore it is possible and also necessary
to observe the print status by the outputs.

Initiation

Once all connections have been made:
⇒
Switch control unit on with the power switch.
⇒
Insert ribbon cassette.
After loading the transfer ribbon cassette the measuring of transfer ribbon begins and the printhead is moved to the print
position.
