Brightness Sensor KNX L
Technical specifications and installation instructions
EN
Elsner Elektronik GmbH Control and Automation Engineering
Herdweg 7
D – 75391 Gechingen Phone +49 (0) 70 56 / 93 97-0
Germany
Fax
+49 (0) 70 56 / 93 97-20 www.elsner-elektronik.de
info@elsner-elektronik.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KNX L and is the answer not in the manual?

Questions and answers

Summary of Contents for Elsner KNX L

  • Page 1 Brightness Sensor KNX L Technical specifications and installation instructions Elsner Elektronik GmbH Control and Automation Engineering Herdweg 7 D – 75391 Gechingen Phone +49 (0) 70 56 / 93 97-0 info@elsner-elektronik.de Germany +49 (0) 70 56 / 93 97-20 www.elsner-elektronik.de...
  • Page 2: Technical Specifications

    KNX +/- bus terminal plug BCU type Own micro controller PEI type Group addresses max. 254 Allocations max. 255 Communication objects Measurement range 0...150.000 lux brightness KNX L brightness sensor • Date of issue: 05.11.2010 • Technical changes reserved. Errors reserved.
  • Page 3 The device must only be operated as stationary system, i.e. only in a fitted state and after completion of all installation and start-up works, and only in the environment in- tended for this purpose. KNX L brightness sensor • Date of issue: 05.11.2010 • Technical changes reserved. Errors reserved.
  • Page 4 2.3.1. Attaching the mount The sensor comes with a combination wall/pole mount. The mount comes adhered by adhesive strips to the rear side of the housing. KNX L brightness sensor • Date of issue: 05.11.2010 • Technical changes reserved. Errors reserved.
  • Page 5 Fig. 4 Example uses of the hinge arm mounting: With the hinge arm mounting, the sensor peeps out from beneath the roof overhang. KNX L brightness sensor • Date of issue: 05.11.2010 • Technical changes reserved. Errors reserved.
  • Page 6 Fig. 6 a+b Drill hole plan Dimensions of rear side of housing with bracket. Sub- ject to change for technical enhancement. Langloch 7,5 x 5 mm KNX L brightness sensor • Date of issue: 05.11.2010 • Technical changes reserved. Errors reserved.
  • Page 7 Close the housing by putting the cover back over the bottom part. The cover must snap in on the left and right with a definite “click”. KNX L brightness sensor • Date of issue: 05.11.2010 • Technical changes reserved. Errors reserved.
  • Page 8 As a precaution, the device should always be separated from bus current for maintenance works. KNX L brightness sensor • Date of issue: 05.11.2010 • Technical changes reserved. Errors reserved.
