- Page 1 MICROWAVE CONVECTION/GRILL OVEN KOC-9N8V7S OWNER’S MANUAL To avoid exposure to dangerous high voltage, DO NOT REMOVE THE SPLATTER SHIELD inside the oven cavity. Before operating this oven, please read these manual completely.
- Page 2 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
-
Page 3: Table Of Contents
TABLE OF CONTENTS • INSTALLATION AND EARTHING INSTRUCTIONS ..........3 • IMPORTANT SAFETY INSTRUCTONS ..............4 • WHICH UTENSIL CAN BE USED IN THE OVEN? ..........6 • ZERO STAND-BY - HOW IT WORKS ...............7 • CONTROL PANEL ....................8 • ACCESSORIES ......................9 • BEFORE OPERATION ....................10 •... -
Page 4: Installation And Earthing Instructions
INSTALLATION AND EARTHING INSTRUCTIONS How to examine your microwave oven after unpacking. Electrical Connection Unpack oven, remove all packing material, and examine the WARNING-THIS APPLIANCE MUST BE EARTHED. oven for any damage such as dents, broken door, latches or REFER TO RATING PLATE FOR VOLTAGE AND CHECK cracks in the door. -
Page 5: Important Safety Instructons
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1. - Page 6 13. The contents of feeding bottles and To reduce the risk of injury to baby food jars shall be stirred or persons: a) Do not overheat the liquid. shaken and the temperature b) Stir the liquid both before and checked before consumption, in order to avoid burns.
-
Page 7: Which Utensil Can Be Used In The Oven
TO AVOID EXPLOSION AND SUDDEN BOILIING 1. Eggs WARNING Never cook eggs in their shells. Steam will build up inside the shell during cooking and the egg will explode. Liquids, such as water, coffee, or tea are able to be If you want to cook or reheat eggs which have not been overheated beyond the boiling point without appearing to be broken up by scrambling or mixing, you must always... -
Page 8: Zero Stand-By - How It Works
ZERO STAND-BY - HOW IT WORKS What is Stand-by Power ... This oven has a special feature that can reduce stand-by power consumption by not unplugging or totally switching off. So the oven will get turned off automatically when not in use for 10 minutes after finishing working. Although the oven is always plugged in, the oven does not consume energy in power save mode at all. -
Page 9: Control Panel
CONTROL PANEL 1 Display : Cooking time, power level are displayed. MW : When blinking, the oven is operating in MICROWAVE COOK. Grill : When blinking, the oven is operating in GRILL. Convection Combi : When blinking, the oven is operating in Convection COMBI. -
Page 10: Accessories
ACCESSORIES This oven comes with several accessories. ■ Turntable tray or turntable They can be used in various ways to facilitate cooking. This metal tray fits over the rotating base and locks into place. ■ Rotating base This is to be used in the oven for all cooking. It rotates Rotating base fits over the shaft in the center of the oven’s clockwise or counterclockwise during cooking. -
Page 11: Before Operation
BEFORE OPERATION Stand by power "0" mode : This function is used for saving energy. To set Stand by power "0" mode 1. Push the STOP/CLEAR button. “ :0” appears in the display. 2. Press and hold the STOP/CLEAR button until display is turned off. 3. -
Page 12: Operation
OPERATION Tips : Please read this OPERATION section for the proper safety information and the operating instruction before use of oven. Prior to setting the controls, place one cup of water in the oven, on a heat-proof glass measuring cup, for testing purposes. Note : When the cooking time has elapsed the oven beeps three times, "End"... -
Page 13: Grill Cooking
GRILL COOKING Kitchen Kitchen The Grill enables you to heat and make food to turn brown quickly without using microwave. Timer Timer Kitchen Timer 1. Turn the top dial knob to set GRILL. GRILL indicator lights. 2. Turn the bottom dial knob button to set the grilling time. For a grilling time of 11 minutes, turn the bottom dial knob button to the right to set 11:00.( up to 60 minutes ) “11:00”... -
Page 14: Kitchen Timer
KITCHEN TIMER Timer operates as a minute timer. Timer operates without microwave energy. Kitchen Timer Kitchen Timer 1. Press Kitchen Timer button. The "tr " is displayed. Kitchen Kitchen Timer Timer 2. Turn the bottom dial knob button to set the amount of time you want to count down. -
Page 15: Convection Cooking (With Pre-Heat)
CONVECTION COOKING (with pre-heat) For convection cooking, it is recommended that you preheat the oven to the appropriate temperature before placing the food in the oven.(except for 40°C convection mode) The maximum preheating time is 30 minutes. If the cooking is not started immediately after preheating, the convection indicator will continue to Kitchen flash and the preheated oven temperature will be displayed. -
Page 16: Convection Cooking (Traditional Cooking)
CONVECTION COOKING (traditional cooking) The convection mode enables you to cook food in the same way as in a traditional oven. Microwaves are not used. Kitchen Kitchen Timer Always use oven gloves when touching the recipients in the oven, as they will be very hot. Timer Kitchen Timer... -
Page 17: Convection Combi Cooking
CONVECTION COMBI COOKING ( Microwave + Convection + Upper Grill ) This function allows you to combine convection operation with microwave to produce traditional baked or roasted results in less time. Always use microwave-safe and oven-proof cookware. Glass or ceramic dishes are ideal as they allow the microwaves to penetrate the food evenly. -
Page 18: Grill Combi Cook
GRILL COMBI COOK This oven offers you a variety of methods for cooking all the cuts of meat available. Popular joints of meat can be roasted automatically on the grill combi. Kitchen Timer Kitchen Timer Kitchen Timer 1. Turn the top dial knob to set GRILL COMBI. GRILL COMBI indicator lights. 2. -
Page 19: Weight Defrost
WEIGHT DEFROST Weight Defrost automatically sets the defrosting times and power levels to give even defrosting results for frozen food. During the defrosting process the oven will beep to remind you to check the food. The oven will beep, open the door, turn the frozen food Kitchen Timer over and close the door, press the START/SPEEDY COOK button. -
Page 20: Express Hot Air
EXPRESS HOT AIR This function is to preheat the oven quickly to the appropriate temperature before placing the food in the oven. The maximum time of express hot air is 12 minutes. When it reaches to appropriate temperature(around 200°C), maintains for 5 minutes, then switches off automatically. 1. -
Page 21: Auto Cook
AUTO COOK This function allows you to simply and automatically cook a range of popular foods. Kitchen Timer Always use oven gloves when touching the recipients in the oven. Kitchen Timer 1. Press Auto Cook button once. Auto Cook indicator lights. "AC-1 "... -
Page 22: Instant Cook
INSTANT COOK Kitchen This function allows you to simply and automatically cook a range of instant foods. Timer Always use oven gloves when touching the recipients in the oven. Kitchen Timer 1. Press Instant Cook button once. "IC-1 " will show in the display. 2. -
Page 23: Speedy Cook
SPEEDY COOK The Speedy Cook function allow oven to cook immediately on full power. The Speedy Cook button has been pre-programmed to increase in increments of 30 seconds up to the maximum time of 5 minutes. 1. Press START/SPEEDY COOK button. The oven will display as “:30”, MW indicator lights, and the oven will start immediately. -
Page 24: General Guide Lines
GENERAL GUIDE LINES Covering food helps: Since microwave cooking to some extent is different from traditional cooking, the following general guidelines should be • To reduce spattering considered whenever you use your microwave oven • To shorten cooking times • To retain food moisture If the food is undercooked All covering, which will allow microwaves to pass through are Check if:... -
Page 25: Keep The Oven Clean
KEEP THE OVEN CLEAN If steam or condensation appears around this area, wipe with a cloth. This may occur when the oven is operating under high humidity and with foods containing lots of moisture. This is a normal part of microwave cooking. Note: •... -
Page 26: Before Calling For Service
BEFORE CALLING FOR SERVICE You can often correct operating problems yourself. Note: If your microwave/grill oven fails to work properly, It is quite normal for steam to be emitted around the door locate the operating problem in the chart below and during the cooking cycle. -
Page 27: Questions And Answers
QUESTIONS AND ANSWERS * Q : I accidentally ran my microwave oven without any * Q : What does “standing time” mean? food in it. Is it damaged? A : “Standing time” means that food should be removed A : Running the oven empty for a short time will not damage from the oven and covered for additional time to allow it the oven. -
Page 28: Specifications
SPECIFICATIONS Power supply 230V~, 50Hz Power consumption 1450 W Microwave Output power 900 W (IEC 705) Frequency 2,450 MHz Grill power consumption 850 W Convection power consumption 2250 W Combination heating power consumption 2950 W Outside Dimension(WXDXH) 542(21.3)X515.1(20.3)X329(13.0)mm (inch) Cavity Dimensions(WXDXH) 350(13.8)X355(14.0)X230(9.1)mm (inch) Net Weight Approx.
