KOC-985TB-English 99.11.24 4:47 PM Page b
T h i n g s
y o u
SHOULD KNOW!
Defrost
M/W
Grill
Combi
Weight Time
Program
Pie
Temp
kg
cook
cook
M/W
Defrost
Pie
Grill
Combi
Temp
Program Cook
1. Roast Beef
2. Roast Pork
3. Roast Chicken
4. Fish Fillet
5. Vegetable
Speedy Cook
Stop/Clear
Start/Clock
WARNING
When heating liquids, e.g.
soups, sauces and beverages in
your microwave oven,
overheating the liquid beyond
boiling point can occur without
evidence of bubbling.
This could result in a sudden
boil over of the hot liquid.
To prevent this possibility the
following steps should be
taken:
Avoid using straight sided
containers with narrow
necks.
Do not overheat.
Stir the liquid before placing
the container in the oven
and again halfway through
the heating time.
After heating, allow to stand
in the oven for a short time,
stir or shake them again
carefully and check the
temperature of them before
consumption to avoid burns
(especially, contents of
feeding bottles and baby
food jars).
230 V~, 50 Hz
When you unpack your microwave oven from its box, please check it immediately for
damage. If the door is damaged or bent, if there are dents inside the oven etc., get in
touch with your retail outlet immediately.
Using a microwave oven safely
Never use the microwave oven if it is damaged. It is particularly
important that the door closes properly.
The door should not be distorted, the hinges and latch should not
be broken, bent or loose, and the seals must be in perfect condition.
This microwave oven contains no user-serviceable components. Any
adjustments or repairs must be performed by a qualified technician.
Never use the oven with the door open. There is the risk of being
exposed to dangerous microwave energy. Never manipulate or
tamper with the safety locks and the hinges of the door.
Keep the seals and seal surfaces clean and free of contamination
like food remains and cleaner residue.
The oven should not be adjusted or repared by anyone except
properly qualified service personnel. It is hazardous for anyone
other than a trained person to carry out any service or repair
operation which involves the removal of any cover which gives
protection against exposure to microwave energy.
Only allow children to use the oven without supervision when
adequate instructions have been given so that the child is able to
use the oven in a safe way and understands the hazards of
improper use.
Microwave heating of beverages can result in delayed eruptive
boiling, therfore care has to be taken when handling the container.
Use the microwave oven for cooking purposes only.
Do not use it to dry animals, clothing, paper or other objects or for
sterilisation or as a storage space for books, cooking utensils etc.
Prior to use! The grill elements of your oven have been covered by a
coating in order to protect during transporting and storage.To remove
the coating heat the elements about 5 minutes (bad odour):
Place a bowl suitable for microwaves, not too small, filled with 0,2 l
water or more into the oven chamber. See chapter "Easy grilling" and
start grilling with the time set to 5:00 minutes.
The right place for your microwave oven
The microwave oven should stand on a flat, stable surface. This
appliance is designed for standing only.
The area immediately around the oven should be free to allow the
circulation of fresh air for cooling.
Do not place the microwave oven near a radio or television set etc.
This might cause interference.
Never place the oven where it is exposed to convection, steam or
humidity.
The minimum height of free space necessary above top surface of
the oven is 150mm.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOC-985TB and is the answer not in the manual?

Questions and answers

Summary of Contents for Daewoo KOC-985TB

  • Page 1 KOC-985TB-English 99.11.24 4:47 PM Page b T h i n g s y o u When you unpack your microwave oven from its box, please check it immediately for damage. If the door is damaged or bent, if there are dents inside the oven etc., get in SHOULD KNOW! touch with your retail outlet immediately.
  • Page 2 Faulty connections can start fires and create other risks and prevent the oven from working correctly. DAEWOO is not liable for any damage due to faulty connection. A defective power cable must be replaced by a qualified technician...
  • Page 3: Cooking Safely With Microwaves

    KOC-985TB-English 99.11.24 4:47 PM Page 2 MICROWAVES When preparing ready-to-serve food (like TV dinners) always carefully follow the instructions provided by the food manufacturer on the package and also the tips and O V E N a n d guidelines contained at the end of this manual.
  • Page 4: The Microwave Oven

    KOC-985TB-English 99.11.24 4:48 PM Page 3 M I C R O W AV E S O V E N a n d The microwave oven Safety door lock The oven will only operate with the door fully closed. When the door is open the oven turns off and will only start again after the door is closed.
  • Page 5 KOC-985TB-English 99.11.24 4:48 PM Page 4 U s i n g t h e Your DAEWOO microwave oven always keeps you well informed: the display tells you which buttons can be pressed next or which settings are required (user guide). The controls...
  • Page 6: Setting The Clock

    KOC-985TB-English 99.11.24 4:48 PM Page 5 U s i n g t h e Setting the clock When not in use the display shows the time. When first connected to the mains, the display looks like this (also after power disconnection).
  • Page 7: Speedy Cooking

    KOC-985TB-English 99.11.24 4:48 PM Page 6 C o o k i n g w i t h MICROWAVES Cookery books and recipes provide details of power settings and times. Easy cooking Defrost Grill Combi Weight Time Program Temp cook cook...
  • Page 8: Programmed Cooking

    KOC-985TB-English 99.11.24 4:49 PM Page 7 C o o k i n g w i t h M I C R O W A V E S Programmed cooking You need set neither power nor time. Select one of the five menu programs.
  • Page 9: Easy Baking

    KOC-985TB-English 99.11.24 4:49 PM Page 8 C o o k i n g w i t h The temperature can be selected between 100˚ C and 210˚ C in 10˚ C steps for C O N V E C T I O N cooking and baking.
  • Page 10 KOC-985TB-English 99.11.24 4:49 PM Page 9 C o o k i n g w i t h C O N V E C T I O N This appliance has multiple heating systems to help cook meals uniformly and crisply. The oven does not need to be preheated.
  • Page 11: Defrosting By Time

    KOC-985TB-English 99.11.24 4:49 PM Page 10 D E F R O S T I N G G R I L L I N G a n d Defrosting by time Defrost Grill Combi Weight Time Program Temp cook cook Defrost...
  • Page 12 KOC-985TB-English 99.11.24 4:49 PM Page 11 D E F R O S T I N G G R I L L I N G a n d Easy grilling GRILL Press the button once. " " appears below "GRILL" in the display.
  • Page 13 KOC-985TB-English 99.11.24 4:50 PM Page 12 Combi cooking with utensil bar A P P E N D I X - This oven is available for rotisserie cooking by using accessories (utensil bar, forks) during combi cooking instead of rotisserie function key.
  • Page 14: Error Messages

    KOC-985TB-English 99.11.24 4:50 PM Page 13 A P P E N D I X Skins, peels, shells ... Some foods have a skin or peel or a shell (eggs, potatoes, apples, liver, sausages). Puncture the skin or peel with for example a fork to allow steam to escape and the food to expand - this releases pressure and prevents the food from bursting.
  • Page 15: Before Calling Technical Service

    KOC-985TB-English 99.11.24 4:50 PM Page 14 No components of this microwave oven are user-serviceable. Any repairs or A P P E N D I X adjustments must always be performed by qualified service technicians. Before calling technical service Defrost Grill...
  • Page 16: Care And Maintenance

    KOC-985TB-English 99.11.24 4:50 PM Page 15 A P P E N D I X Microwave suitable dishes and utensils Microwave suitable dishes are transparent to microwaves (i.e. made of such materials as plastic, glass and ceramics), especially when also fireproof. Suitable dishes only become slightly warm after one minute microwave cooking at high power.
  • Page 17: Technical Data

    KOC-985TB-English 99.11.24 4:50 PM Page 16 A P P E N D I X Technical data Defrost Grill Combi Weight Time Program Temp cook cook Defrost Grill Combi Temp Power supply 230 V~, 50 Hz Program Cook 1. Roast Beef 2.
