EA01242G
Wall-mount housing
In the case of the wall-mount housing, the 8 slots are arranged in two parallel rows, one above the other.
• If the input/output card to be replaced is installed in the top row, steps 7 and 8 can be ignored.
• If the input/output card to be replaced is installed in the bottom row, the input/output card in the row above must also be
removed.
1 →
3 →
4
2 →
4 →
