Summary of Contents for Heinrichs PITe-Series
- Page 1 PITe with Magnetic-Inductive Flow Velocity Sensor UMF2 (B) Installation and operating manual Please read the instructions carefully and store them in a safe place...
-
Page 2: Table Of Contents
Heinrichs Messtechnik Installation and Operation Manual PITe Contents INTRODUCTION ............................4 1.1 H ............................4 AZARD WARNINGS 1.2 P ........................4 ACKAGING STORAGE TRANSPORT 1.3 W ..............................5 ARRANTY IDENTIFICATION ............................5 2.1 M ..........................5 ANUFACTURER SUPPLIER 2.2 P ................................ - Page 3 Heinrichs Messtechnik Installation and Operation Manual PITe DECLARATION OF CONFORMITY ......................20 FINAL NOTES ............................22 Page 3 of 22...
-
Page 4: Introduction
If however you have any queries or problems concerning your purchased product, please contact our head office in Cologne. Heinrichs Messtechnik GmbH accepts no liability for any loss or damage of any kind arising from improper operation of any product, improper handling or use of any replacement part, or from external electrical or mechanical effects, overvoltage or lightning. -
Page 5: Warranty
Heinrichs Messtechnik GmbH extends no express or implied warranty in regard to the applicability of the present document for any purpose other than that described. -
Page 6: Area Of Application
Special electrodes are available for media that tend to form greasy films or crusts. To perform flow measurements, the PITe sensor must be operated with a Heinrichs Messtechnik transmitter of the UMF-x series, for example the UMF2 (B). The transmitter UMF2 (B) is a... -
Page 7: Installation Commissioning And Mainteinance
Heinrichs Messtechnik GmbH accepts no liability for loss or damage of any kind arising from improper operation of any product, improper handling or use of any replacement part, or from external electrical or mechanical effects, overvoltage or lightning. -
Page 8: Mode Of Operation And System Design
(4-20 mA or pulses). The PITe-*** sensor can be operated with all transmitters for magnetic-inductive flow meters manufactured by Heinrichs Messtechnik. The sensor is installed in the pipe while the transmitter is mounted separately in the field for better access. -
Page 9: Sensor Versions
Heinrichs Messtechnik Installation and Operation Manual PITe 6.3.1 Sensor versions PITe Wetted parts stainless steel / Hastelloy / PTFE, Sensor neck connection: union nut (threaded version) or flange stainless steel Threaded version Flanged version (Option) Weld-on adaptor Ø40mm with Weld-on adaptor Ø40mm with... -
Page 10: Installation / Conditions Of Use
7 Installation / Conditions of use Installation requirements Screws, bolts, nuts and seals are not supplied by Heinrichs Messtechnik GmbH and must therefore be provided by the operator. So not to damage any part of the sensor during installation, only use tools specifically designed for intended purpose. - Page 11 Heinrichs Messtechnik Installation and Operation Manual PITe Open inlet or outlet When installed at an inlet or an outlet, the device should be installed, where possible, in a siphon. This will ensure that the pipe section fitted with the sensor cannot autonomously drain. The empty pipe detection circuit of the transmitter is an additional safety feature for recognizing empty or partially filled pipes.
- Page 12 Heinrichs Messtechnik Installation and Operation Manual PITe Long pipelines In long pipelines, there is always a danger of pressure surges. Therefore, disturbing elements such as regulating and shut-off devices should be arranged downstream from the sensor. However, when installed in vertical piping, especially when operating at high temperatures, the regulating and shut-off devices should be placed in front of the sensor (danger of vacuum).
-
Page 13: Immersion Depth Of Pite-*** In The Pipe
Heinrichs Messtechnik Installation and Operation Manual PITe 7.1.2 Immersion depth of PITe-*** in the pipe The weld spigots must be installed so that the sensor head projects 40 mm into the pipeline, regardless of the pipes nominal diameter. Caution: Before welding the socket to the pipe, it is essential that the sensor be removed from the... -
Page 14: Environmental Conditions
Heinrichs Messtechnik Installation and Operation Manual PITe The measuring signal tapped at the electrodes amounts to only a few millivolts. Correct grounding of the electromagnetic flow sensor is therefor essential for achieving exact measurement. The transmitter requires a reference potential to evaluate the measured voltage on the electrodes. The metrological grounding of the medium for PITe is achieved via the wetted part of the sensor tube. -
Page 15: Cathode Protective Units
Heinrichs Messtechnik Installation and Operation Manual PITe The electrodes and measuring electronic are referenced to the potential of the functional earth FE of the sensor. FE is not connected to PE, but may be connected in the sensor junction box if wished. If ground disks (earthing rings) are used for grounding purposes, then these must be connected to the functional earth FE. - Page 16 Heinrichs Messtechnik Installation and Operation Manual PITe If the calibration of the sensor / UMF2 (B) transmitter combination has not been performed by the manufacturer, the necessary settings must be implemented in the transmitter before the sensor can operate correctly. This applies in particular to cases where the sensor has been exchanged, or when the pipe cross-section at the installation site is altered.
-
Page 17: Power Supply / Electrical Connection
Heinrichs Messtechnik Installation and Operation Manual PITe 10 Power supply / electrical connection See name plate or Operating Instructions of the UMF2 (B) transmitter. 10.1 Electrical connection The outer shield must be connected to the “PE” Terminal. The inner shields are each to be connected to there respective “FE”... -
Page 18: Dimensions/Weight
Heinrichs Messtechnik Installation and Operation Manual PITe 11 Dimensions/weight 11.1 Dimensional drawings Threaded version (standard) Flanged version (optional) Page 18 of 22... -
Page 19: Declaration Of Decontamination
Heinrichs Messtechnik Installation and Operation Manual PITe 12 Declaration of Decontamination for the cleaning of the device Company: ........Town/City: .......... Department: ........Name: ..........Tel.-N .: ........The enclosed flowmeter Model: PITe......Was operated using the following fluid: .............. -
Page 20: Declaration Of Conformity
Heinrichs Messtechnik Installation and Operation Manual PITe 13 Declaration of Conformity Konformitätserklärung Declaration of Conformity . 16.4149.01 Hersteller: Heinrichs Messtechnik GmbH Robert-Perthel-Strasse 9 Manufacturer: 50739 Köln Produktbeschreibung: Magnetisch Induktiver Durchflussmessgerät UMF2 (B) für Product description: Verwendung mit der Sensorreihe PIT* und PITe*... - Page 21 Heinrichs Messtechnik Installation and Operation Manual PITe Anhang N zur Konformitätserklärung Annex N of the Declaration of Conformity . 16.4149.01 Produktbeschreibung: Magnetisch Induktiver Durchflussmessgerät UMF2 (B) für Product description: Verwendung mit der Sensorreihe PIT* und PITe* Magnetic inductive flowmeter UMF2 (B) for use with the sensor series PIT* and PITe* Die Konformität mit den auf Seite 1 genannte Richtlinien diese Erklärung wird nachgewiesen durch die...
-
Page 22: Final Notes
Installation and Operation Manual PITe 14 Final Notes This document is available on our web site www.heinrichs.eu. You may download and print it for the sole intension of using it in conjunction with our mass flowmeters. All rights reserved. No instructions,...
