Up/Down-Torch; Torch Functions - LORCH HandyTIG 180 DC Basic Plus Operation Manual

16

Up/Down-torch

16.1

Torch functions

70
71
Abb. 18: Up/Down torch buttons
70
torch button start/stop
to start and stop the welding process.
torch button secondary current
71
press the button to weld with the secondary cur-
rent (default value is 50% of selected welding
current). The secondary cur-rent flows as long as
the torch button is pressed.
If the slope function is activated, the downslope
can be termi-nated prematurely by pressing the
torch button.
- 38 -
73
72
Down/Job 1
72
during the welding process, the welding current
I1 can be reduced by pressing the torch key (the
secondary current I2 can not be changed). Dur-
ing an active job (LED 30 or 31 light up) use torch
keys Job 1 and 2 to change between both jobs.
73
Up/Job 2
during the welding process, the welding I1 current
can be increased by pressing the torch key. (the
secondary current I2 can not be changed During
an active job (LED 30 or 31 light up) use torch
keys Job 1 and 2 to change between both jobs.
Up/Down-torch
10.15
