Machine elements

1
Abb. 10: Machine elements
1
Mains cable
Mains switch
2
Gas connector
3
Connector remote control
4
Front panel
5
6
Shoulder strap
7
Connector positive pole
2

Explanation of symbols

2.1
Meaning of the symbols in the opera-
tion manual
Danger to life and limb!
If the danger warnings are disregarded,
this can cause slight or severe injuries or
even death.
Danger of property damage!
Disregarding danger warnings can cause
damage to workpieces, tools, and equip-
ment.
General note.
i
Designates useful information about the
product and equipment
- 26 -
2
3
4
10
5
9
8
7
8
Connector negative pole
9
Connector - torch controller
Air intake
10
Some depicted or described accessories
i
are not included in the scope of delivery.
Subject to change.
2.2
Meaning of the symbols on the
machine
Danger!
Read the user information in the operation
manual.
Disconnect the mains plug!
Pull out the mains plug before opening the
housing
Explanation of symbols
6
10.15
