Hubbell KILLARK L1L Series Installation, Operation & Maintenance Data Sheet

Led luminaire

Advertisement

INSTALLATION, OPERATION &
MAINTENANCE DATA SHEET
L1L SERIES LED LUMINAIRE
L1L SERIES LED LUMINAIRE
CAUTION:
Before installing, make sure you are compliant with area classifications, failure to do so may result in bodily injury, death
and property damage. Do not attempt installation until you are familiar with the following procedures. All installation must
comply with the applicable Electrical Code.
Make sure that the circuit is de-energized before starting installation or maintenance.
Verify that the installation is grounded. Failure to ground will create electrical shock hazards, which can cause serious
injury and or death.
IMPORTANT:
Technical information, advice and recommendations contained in these documents are based on information that Killark
believes to be reliable. All the information and advice contained in these documents is intended only for use by persons
having been trained and possessing the requisite skill and know-how and to be used by such persons only at their own
discretion and risk.
The nature of these instructions is informative only and do not cover all of the details, variations or combinations in which
this equipment may be used, its storage, delivery, installation, check out, safe operation, and maintenance. Since
conditions of use of the product are outside of the care, custody and control of Killark, the purchaser should determine the
suitability of the product for its intended use, and assumes all risk and liability whatsoever in connection therewith.
ATTENTION:
Avant d'installer le luminaire, s'assurer que le luminaire est conforme à la classification des zones, le non- respect de
cette règle risque d'entraîner des dommages corporels et / ou matériels. Ne pas tenter d'entreprendre l'installation avant
d'être familiarisé avec les procédures suivantes. Toute installation doit être conforme au code électrique local et / ou
national et être effectuée par un électricien qualifié.
Veiller à ce que le circuit soit mis hors tension avant de commencer l'installation ou la maintenance.
Vérifier si le luminaire est mis à la terre. S'il n'est pas mis à la terre il pourrait causer des risques de choc électrique
susceptibles d'entraîner des blessures graves ou la mort.
WARNING:
Incorrect installation of this Luminaire might cause potential ignition sources from optical radiation. Follow
INSTALLATION, OPERATION & MAINTENANCE DATA SHEET.
2112 Fenton Logistics Park Blvd
Fenton, Missouri 63026 USA
P/N KIL00921498 FORM NO. K1498 ECO-6-023-19 R04/19
Page 1 of 4
