Hubbell LAL Series Installation, Operation & Maintenance Data Sheet

Luminaires designed to be installed in hazardous locations

Advertisement

INSTALLATION, OPERATION &
MAINTENANCE DATA SHEET
LAL SERIES LED LUMINAIRE
LAL SERIES LED LUMINAIRE
CAUTION:
Before installing, make sure you are compliant with area classifications, failure to do so may result in bodily injury,
death and property damage. Do not attempt installation until you are familiar with the following procedures. All
installation must comply with the applicable Electrical Code.
Make sure that the circuit is de-energized before starting installation or maintenance.
Verify that the installation is grounded. Failure to ground will create electrical shock hazards, which can cause
serious injury and or death.
IMPORTANT:
Technical information, advice and recommendations contained in these documents are based on information
that Killark believes to be reliable. All the information and advice contained in these documents is intended only
for use by persons having been trained and possessing the requisite skill and know-how and to be used by such
persons only at their own discretion and risk.
The nature of these instructions is informative only and do not cover all of the details, variations or combinations
in which this equipment may be used, its storage, delivery, installation, check out, safe operation, and
maintenance. Since conditions of use of the product are outside of the care, custody and control of Killark, the
purchaser should determine the suitability of the product for its intended use, and assumes all risk and liability
whatsoever in connection therewith.
ATTENTION:
Avant d'installer le luminaire, s'assurer que le luminaire est conforme à la classification des zones, le non-
respect de cette règle risque d'entraîner des dommages corporels et / ou matériels. Ne pas tenter d'entreprendre
l'installation avant d'être familiarisé avec les procédures suivantes. Toute installation doit être conforme au code
électrique local et / ou national et être effectuée par un électricien qualifié.
Veiller à ce que le circuit soit mis hors tension avant de commencer l'installation ou la maintenance.
Vérifier si le luminaire est mis à la terre. S'il n'est pas mis à la terre il pourrait causer des risques de choc
électrique susceptibles d'entraîner des blessures graves ou la mort.
3940 Dr. Martin Luther King Drive
St. Louis, MO 63113
P/N KIL00921449 FORM NO. K1449 ECO6-012-17 1/17
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hubbell LAL Series

  • Page 1 INSTALLATION, OPERATION & MAINTENANCE DATA SHEET LAL SERIES LED LUMINAIRE LAL SERIES LED LUMINAIRE CAUTION: Before installing, make sure you are compliant with area classifications, failure to do so may result in bodily injury, death and property damage. Do not attempt installation until you are familiar with the following procedures. All installation must comply with the applicable Electrical Code.
  • Page 2 Conditions for Safe Use The Luminaire shall only be installed where there is a low risk of mechanical damage. Potential electrostatic charging hazard, clean with damp cloth. Luminaires are designed to be installed in Hazardous Locations: Class I, Division 2, Groups A, B, C and D;...
  • Page 3 LAL INSTALLATION NSTRUCTIONS A. Channels are incorporated in the housing for 5/16” or M8 hex bolts or nuts. (See Figure 1) 1. 5/16” or M8 hex bolts can be slid into channels for direct mounting; or used to attach brackets which include L- brackets, Wall Brackets, Ceiling Brackets, Beam Clamps, and Suspension Chains etc…...
  • Page 4 BATTERY BACKUP FIXTURES IMPORTANT: To turn the fixture completely off, an un-switched AC power source of 120VAC to 277VAC is required for the yellow/black and white leads. If the yellow/black and white leads are attached to switched power, the fixture will go into battery backup mode if the switch is turned off.
  • Page 5 3. Remove the two screws that hold the driver to Battery Back-Up Connection the gear tray. with Terminal Block 4. Remove the two screws that hold the battery compartment cover to the driver. 5. Disconnect the connector and replace the new battery.
