Wen LA8800 Manual

Lathe stand
Hide thumbs

Advertisement

Quick Links

For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe,
reliable service.
LATHE STAND
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
MODEL LA8800
(M-F 8am-5pm CST)

Advertisement

loading
Need help?

Need help?

Do you have a question about the LA8800 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen LA8800

Summary of Contents for Wen LA8800

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    Know Your Lathe Stand ..............6 Assembly & Adjustments ..............7 Maintenance ..................9 Exploded View & Parts List ............10 Warranty Statement ............... 12 SPECIFICATIONS Model Number LA8800 Minimum Length 23.75" Maximum Length 35.5" Width 23.5" Minimum Working Height 24.5"...

  • Page 3: Introduction

    INTRODUCTION Thanks for purchasing the WEN lathe stand. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety concerns, as well as helpful assembly and operating instructions for your tool.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Read and understand all warnings, cautions and operating instructions before using this tool. Failure to follow all instructions listed below may result in personal injury and tool damage.
  • Page 5 GENERAL SAFETY RULES 4. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents. 5.

  • Page 6: Know Your Lathe Stand

    KNOW YOUR LATHE STAND 230 mm 11 mm 52.5 mm 90 mm PACKING LIST Check your packing list against the diagram below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. Tools needed for assembly (not included): Adjustable Wrench and pliers OR socket set, bubble level Mounting Platform (2) Inner Beam (1)

  • Page 7: Assembly & Adjustments

    ASSEMBLY & ADJUSTMENTS ATTACHING FEET TO BASE (FIG. 1) 1. Locate one base (Fig. 1 - 8). 2. Install two M10 washers (Fig. 1 - 3), two M12 hex nuts (Fig. 1 - 2), and two M12X100 hex bolts (Fig. 1 - 1) through the top of the base on each side. 3.
  • Page 8 ASSEMBLY & ADJUSTMENTS ATTACHING INNER & OUTER BEAMS (FIG. 4) 1. Slide the inner beam (Fig. 4 - 2) into the outer beam (Fig. 4 - 4). 2. Add two M10x20 hex bolts (Fig. 4 - 3) to the welded hex nuts (Fig.

  • Page 9: Maintenance

    ASSEMBLY & ADJUSTMENTS ADJUSTING FOR LATHE LENGTH (FIG. 7) 1. Measure the length of your lathe from center of one mounting hole to the center of the other mounting hole. 2. Loosen the two M10x20 hex bolts (Fig. 7 - 1) on the outer beam (Fig.

  • Page 10: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST ASSEMBLY & ADJUSTMENTS...
  • Page 11 EXPLODED VIEW & PARTS LIST ASSEMBLY & ADJUSTMENTS Part No. Description LA8800-001 Mounting Platform LA8800-002 Washer M10 LA8800-003 Hex Bolt M10x80 LA8800-004 Hex Nut M10 LA8800-005 Column LA8800-006 Inner Beam LA8800-007 Hex Bolt M10x20 LA8800-008 Outer Beam LA8800-009 Hex Bolt M12x100...

  • Page 12: Warranty Statement

    (2) years from date of purchase or 500 hours of use; whichever comes first. Ninety days for all WEN products if the tool is used for professional or commercial use.
