X-C 6250 Pro (300) NT User’s Manual

Vehicle Cradle

The vehicle cradle is a vehicle-based docking station designed to safely
secure the computer in the vehicle. A standard key lock located on the
front of the cradle locks the computer onto the cradle for security
purposes. You can use the vehicle cradle to:
Charge batteries
•
Communicate with other devices
•
Or, Access USB devices (not currently availabe with NT 4.0)
•

Front View

Rear Guide Blocks
Rear Latching Hooks
Power “On” Indicator
Back View
Cradle Contact Pins
Rear Latching Hooks
Identification Tag
External Antenna
90
All manuals and user guides at all-guides.com
Serial Port
USB
(Com2)
Terminal Block
Mounting
Screws
Cradle Contact Pins
.ront Guide Blocks
Latching Dovetail
Key Lock
Release Lever
(Under Handle)
Latching Dovetail
.ront Guide Block
Rear Guide Block
Rear Latching Hooks
DC
Terminal Block
GND
Mounting
Screws
79-0030-001 11 January 2001
Handle
