Page 1: Washing Machine
INSTRUCTIONS FOR INSTALLATION AND USE WF8 G4 WF11 G4 WF18 G4 WF22 G4 WASHING MACHINE MICROPROCESSOR G400 LAVA-WF8-11-18 G4 v.05 , 211/C ASIERE 32037 - S OSPIROLO TALY... -
Page 2: Table Of Contents
www.groupdynamics-laundry.com sales@groupdynamics.lv INSTRUCTIONS FOR INSTALLATION AND USE 1.2 FOREWORD CONTENTS Congratulations on your selection of our equipment. If you follow carefully the present instructions you will certainly be satisfied with its performance and guarantee. Page Be informed that, in the event of claims or remarks, the reference 1) General information .............. -
Page 3: Requirements For Installation
www.groupdynamics-laundry.com sales@groupdynamics.lv fork lift, either manual or electric, provided it is adequate for IMPORTANT: handling such appliances and it has the requisite lifting capacity CONNECTING THE MACHINE TO THE EARTHING SYSTEM (cfr. technical data). Check beforehand that the equipment can IS MANDATORY. -
Page 4: Instructions For Use
www.groupdynamics-laundry.com sales@groupdynamics.lv level and sturdy surface. Align and level by the use of a spirit level. bar (0.1 MPa and 0.6 MPa). For servicing purposes, it is advisable to leave a 500mm clearance Refer to the rating plate details. between the rear face of the machine and the wall behind. 4.7.1 FOR ALL WASHER VERSIONS Besides, when machines are installed in a line, leaving at least a 20mm clearance between one machine and the next is recommended. -
Page 5: Machine Information
www.groupdynamics-laundry.com sales@groupdynamics.lv SEL: Cycle (program) selection BUTTON It is however possible to stop the beeper by pressing the " - " push ECO: ECONOMY BUTTON: to reduce water consumption by button or even inhibit the beeper altogether through programming. 20%. THIS DOES NOT consider the effective wash load and works only if the "weighing"... -
Page 6: Wash Programs
www.groupdynamics-laundry.com sales@groupdynamics.lv 6.6.1 WASH PROGRAMS b) Firmware card: the display will read "software card" and will allow no action other than removing the card. Wash cycles can only be saved and loaded (as preset) when the machine is on, no cycle is in progress and the door is open. On c) Correct card: the display will read "cycles card"... - Page 7 www.groupdynamics-laundry.com sales@groupdynamics.lv...
-
Page 8: Safety Procedures
www.groupdynamics-laundry.com sales@groupdynamics.lv CAUTION! 6.6.2 FIRMWARE If the machine has been programmed via PC or optional functions To save and load the firmware, insert the Smart Card when the have been enabled, the cycle tables provided below do not apply. machine is off. When the machine is then turned on the system will The manufacturer reserves the right to change cycle the features or react by showing the following messages: the machine's... - Page 9 www.groupdynamics-laundry.com sales@groupdynamics.lv PARAMETER CONFIGURATION MACHINE STANDBY STATUS MACHINE PARAMETERS MACHINE PARAMETERS 1) COOLING 2) SPINNING 3) PREWASH 4) DEFERRED START 5) BUZZER 6) HEATING 7) ENABLE CYCLES ....MACHINE PARAMETERS 1) COOLING MACHINE PARAMETERS...
- Page 10 www.groupdynamics-laundry.com sales@groupdynamics.lv MACHINE STANDBY STATUS MACHINE PARAMETERS MACHINE PARAMETERS ..8) DRUM MOVEMENT INTAKE/DRAIN 9) HEATING HYSTERESIS 10) PUMP LEVEL 11) START WITH H2O 12) CALIBRATION 13) VIEW CYCLE TIME MACHINE PARAMETERS 8) DRUM MOVEMENT MACHINE PARAMETERS INTAKE/DRAIN 8) DRUM MOVEMENT INTAKE/DRAIN...
- Page 11 www.groupdynamics-laundry.com sales@groupdynamics.lv Clean and inspect the drain valve and the water intake ALARM E1 WATER IN THE TUB valves. DISPLAY DESCRIPTION E1: WATER IN THE TUB Perform level calibration for the electronic card. Replace the tube connecting the tub to the pressure If the pressure switch detects a water level above 4cm CORRECTIVE ACTION switch.
- Page 12 www.groupdynamics-laundry.com sales@groupdynamics.lv ALARM E8 LEVEL ERROR BUZZER The BUZZER will not go on. DISPLAY DESCRIPTION E8: Level error This function is automatically enabled and disabled at each ALARM RESET spinning step. If a water level 10 cm above the established height is DESCRIPTION detected, the cycle is interrupted.
-
Page 13: Instructions For Maintenance
www.groupdynamics-laundry.com sales@groupdynamics.lv INSTRUCTIONS FOR MAINTENANCE MOTOR OVERLOAD SWITCH TRIPPED WITH ALARM NON AUTORESET ALARMS 1 “OH inverter supertemperature” 8. INFORMATION ON SPECIAL USE AND 2 “OLi inverter overload” 3 “OLM motor overload” SAFETY MEASURES 4 “OLR brake overload” 5 “OT motor torque overload” When carrying out the first cycle, verify the following: 6 “PH inverter phase failure”... -
Page 14: Decommissioning And Dismantling
www.groupdynamics-laundry.com sales@groupdynamics.lv When this message is displayed, request yearly maintenance. 8.2.2 SAFETY DEVICES To dismiss this reading and start the 1000 cycle count from scratch, - Door closed safety microswitch cuts off power to the whole press the push-button "- " for at least 5 secs with the door closed. auxiliary circuit and consequently stops the machine. -
Page 15: Figures
www.groupdynamics-laundry.com sales@groupdynamics.lv SPACE REQUIRED FOR MACHINE INSTALLATION, USE AND MAINTENANCE ),* ),* $ .* F i g . 1 2 2 k g 8 3 5... - Page 16 www.groupdynamics-laundry.com sales@groupdynamics.lv MACHINE DESCRIPTION...
-
Page 17: Description Of Cycles
www.groupdynamics-laundry.com sales@groupdynamics.lv Cycles 1 to 9 with initial automatic weighing Cycles from 10 to 19 are identical to 1 to 9, except for initial automatic weighing, which is disabled. Cycle 1: very soiled whites Cycle 6: terry cloth For very soiled hard-wearing laundry For toweling items 40°C prewash with strong wash action 40°C prewash with gentle wash action... -
Page 18: Technical Data
www.groupdynamics-laundry.com sales@groupdynamics.lv TECHNICAL DATA MODELLI WFG4 WFG4 MODELS Capacità rapporto 1:10 16.5 1:10 Capacity ratio Dimensione cesto Diam. Diam. Drum size Prof. Depth Volume Volume Dimensione oblò Diam. Diam. Door opening Velocità cesto r.p.m. 25÷1000 25÷1000 25÷1000 25÷860 r.p.m. Drum speed Fattore G 74/300 74/300... -
Page 19: Key To Components
www.groupdynamics-laundry.com sales@groupdynamics.lv Key to components – Electrical board of models WF8-11-18-22G4 power card power card BALANCE tilt microswitch liter meter common (optional) soap pump power card (optional) CP (COINPROGRAM) coin-meter programming switch (optional) cycle relay (optional) CS (COINSW) coin-meter microswitch (optional) soap-ozone injecting pump power card (optional) DOORSW door closed microswitch... -
Page 20: Wiring Diagrams
www.groupdynamics-laundry.com sales@groupdynamics.lv COMPLETE WIRING DIAGRAM MODS. 8-11-18... - Page 21 www.groupdynamics-laundry.com sales@groupdynamics.lv COMPLETE WIRING DIAGRAM MOD. 22- 230V L1 / R L2 / S L3 / T SPECIAL VERSIONS FAN1 245Vca Coin Program Balance Switch 800 mA Energy Control Hot Water electronic Tank Liquid Soap voltage stabilizer 800 mA SCH6 No Heating Soft cold Hard cold...
- Page 22 www.groupdynamics-laundry.com sales@groupdynamics.lv COMPLETE WIRING DIAGRAM MOD. 22 - 400V L1 / R L2 / S L3 / T SPECIAL VERSIONS FAN1 245Vca Coin Program Balance Switch 800 mA Energy Control Hot Water electronic Tank Liquid Soap voltage stabilizer 800 mA SCH6 No Heating Soft cold...
- Page 23 www.groupdynamics-laundry.com sales@groupdynamics.lv...
- Page 24 www.groupdynamics-laundry.com sales@groupdynamics.lv TARGHETTA TECNICA, RATING PLATE, PLAQUETTE TECHNIQUE, GERÄTESCHILD, PLACA DE CARACTERÍSTICAS MODELLO MODEL NR. MATR. SERIAL NR. ALIM. EL. EL. POWER POTENZA TOT. TOTAL INPUT PRESSIONE VAPORE STEAM PRESSURE ATTENZIONE! E' OBBLIGATORIO IL COLLEGAMENTO A TERRA CAUTION! THE APPLIANCE MUST BE CONNECTED TO EARTH RIVENDITORE, DISTRIBUTOR, REVENDEUR, VERTRIEB, VENDEDOR ASSISTENZA TECNICA, AFTER-SALES SERVICE,...
