MD-300
PC on TV
Full Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-300 and is the answer not in the manual?

Questions and answers

Related Manuals for Sitecom MD-300

Summary of Contents for Sitecom MD-300

  • Page 1 All manuals and user guides at all-guides.com MD-300 PC on TV Full Manual...

  • Page 2: Table Of Contents

    9 Frequently asked questions .................25 10 Certifications ....................28 Revision 1.0 © Sitecom Europe BV 2011 Note: All the information contained in this manual was correct at the time of publication. However, as our engineers are always updating and improving the product, your device’s software may have a slightly different appearance or modified functionality than presented in this manual.

  • Page 3: Introduction

    All manuals and user guides at all-guides.com 1 Introduction Thank you for purchasing the MD-300 PConTV. The MD-300 PConTV is the first device that can show all content of your Windows as well as Mac computers on your TV wirelessly. You can easily control up to 8 computers with your mouse and/or keyboard.

  • Page 4: Cautions

    All manuals and user guides at all-guides.com 2 Cautions This device’s design and manufacturer has your safety in mind. In order to safely and effectively use this device, please read the following before usage. Usage Cautions The user should not modify this device. The environmental temperature should be within +0 ~ +40 degrees Celsius.

  • Page 5: Package Content

    All manuals and user guides at all-guides.com 3 Package content The following items are included in your PConTV package: • PConTV device • Quick Installation Guide • 2 WiFi antennae • Universal power adaptor • Installation CD • User’s Manual (on CD) •...

  • Page 6: Setup Possibilities

    All manuals and user guides at all-guides.com 4 Setup Possibilities 1. Ethernet setup (recommended): Optimal performance Local client PC’s and PConTV in full Ethernet setup. 2. Homeplug power-line modem Setup: Optimal performance Local client PC’s and PConTV in Home Plug** setup.
  • Page 7 All manuals and user guides at all-guides.com 3. Partly wireless, Partly Ethernet Setup Local client PC’s wireless* and PConTV in Ethernet setup. 4. Wireless Setup Local client PC’s and PConTV in full wireless setup.* Performance depends on wireless performance of home ADSL or cable router. HomePlug devices sold separately.

  • Page 8: Quick Start

    All manuals and user guides at all-guides.com 5 Quick start 1. Connect a HDMI cable to the PConTV, connect it to your HDMI input on your TV and turn on your TV. 2. Connect the power adaptor to your PConTV, and plug it into a power outlet. 3.
  • Page 9 All manuals and user guides at all-guides.com 9. Connect to selected access point. 10. Connecting to PConTV server. If only one server is found, it will automatically connect to the server. 11. The application will temporarily adjust your Windows or Mac resolution for best projection result, and then project your screen to TV.

  • Page 10: Using Pcontv Software User Interface

    All manuals and user guides at all-guides.com 6 Using PConTV software user interface After you have installed the PConTV software application from the installation CD to your PC (‘s) you can run the PConTV software user interface to connect to the PConTV. If there is more than one PConTV active in the same network, the software will list the devices for you to choose.
  • Page 11 All manuals and user guides at all-guides.com Each activation key can be used to register on eight different PCs. If you have trouble activating your software, please contact customer service for assistance. Video Mode vs. App Mode On the PConTV software user interface you can find a switch button to operate two modes: Video Mode and App Mode.
  • Page 12 All manuals and user guides at all-guides.com Main Menu Bar (Task bar): Click <About> to show version information of this program. Click <Check for Updates> to check for updates.
  • Page 13 All manuals and user guides at all-guides.com Using the PConTV software user interface pop-up Menu When the PConTV software is running, you can move your mouse cursor to the Menu button (to be found on the right edge of the PConTV software user interface). Click on the Menu (as shown above) button to show the menu items.
  • Page 14 All manuals and user guides at all-guides.com Click <Search Remote Box> to connect to another PConTV. The last PConTV you connected is remembered. To connect to another PConTV in your network, Click on <Rescan>. Click <Projection quality> to adjust projection image quality in quality requires higher bandwidth.
  • Page 15 All manuals and user guides at all-guides.com Click <PC Screen Resolution> to adjust projection image quality. Larger resolution requires higher bandwidth. Default is Middle. Click <TV Offset Compensation> Many TV’s have an overscan design which will cut the edges of the PC Desktop shown on the TV screen. If you cannot turn off overscan from your TV menu, please use the <TV Offset Compensation>...
  • Page 16 All manuals and user guides at all-guides.com wireless performance will be depending on the strength of your Wireless module in your home router. Please make sure that the signal between your home router (N-type router recommended) and the PConTV device is good to ensure good performance. Check the <Enable>...

  • Page 17: Controlling Your Computers

    All manuals and user guides at all-guides.com 7 Controlling your computers Working with multiple computers You can use the PConTV with more than one Windows or Mac computer. Just install the software on every computer you want to use, and then run the software on each computer.
  • Page 18 All manuals and user guides at all-guides.com Once connected, the mouse or keyboard can be used to select a PC from the PC list above, and also to operate every PC when its screen is shown on TV. If you want to use a game controller for gaming, attach your controller directly to your laptop or PC.

  • Page 19: Web Management

    All manuals and user guides at all-guides.com 8 Web management Home page Make sure your Windows or Mac PC is connected to the PConTV successfully. Open your browser, and enter the IP address of your PConTV. (You can find the PConTV IP address on the TV screen when the PConTV is powered on and is presenting the startup screen in the lower left corner of this startup screen).
  • Page 20 All manuals and user guides at all-guides.com Click [Admin] and then enter the password to login to the web page. The default password is “admin”. System status *** Click [System Status] to show current system status. Model Name: Product model name Versions: ♦...
  • Page 21 All manuals and user guides at all-guides.com Network setup <IP Setup> You can select “obtain IP address automatically” or “Use the following IP address” ♦ IP Address: The default value is 192.168.100.10 (not connected to any network). ♦ Subnet Mask: The default value is 255.255.255.0 ♦...
  • Page 22 All manuals and user guides at all-guides.com <DHCP Server Setup> You can select “Auto” or “Disable”. When “Auto” is selected, it will automatically disable DHCP on the PConTV when another DHCP server is detected, otherwise it will enable its DHCP service. ♦...
  • Page 23 All manuals and user guides at all-guides.com Reset to default *** Click [Reset to Default] button to restore the factory default settings. <Apply>: Confirmation and action. Firmware update *** Click [Firmware Update] button to upgrade firmware. ♦ Get the latest firmware. ♦...
  • Page 24 All manuals and user guides at all-guides.com !!!! Warning: Don’t power off PConTV while the firmware upgrade is in progress, otherwise the PConTV device may be damaged and have to be returned to your vendor for repair!!!!! Reboot system *** Click on [Reboot System] button to restart system. <Reboot>: reboot system automatically.

  • Page 25: Frequently Asked Questions

    All manuals and user guides at all-guides.com 9 Frequently asked questions Q. My PC cannot connect to PConTV. What can I do? A. Check the status shown on the projection panel. 1. If the left line is not connected, then your PC is not connected to any network. Please check your network connection.
  • Page 26 All manuals and user guides at all-guides.com benchmark score measured during installation should be 4 stars or above for video projection. 2. System too busy. Close all other programs and try again. 3. Network not fast enough. Check connection speed. You may try lower screen resolution or projection quality to save bandwidth.
  • Page 27 All manuals and user guides at all-guides.com Q. Which video player can be used best on my PC to work with PConTV? A. The recommended video player we suggest you to use is VLC player. This player is capable to play al popular video formats. It is free to use and offers multi-platform software.

  • Page 28: Certifications

    Power adapter European ErP (2009/125/EC) North America Energy Start V www.sitecom.com Disclaimer: • Apple®, iPod®, iPhone®, iPad®, Microsoft®, Windows®, Mac®, Intel®, AMD®,ATI®, VLC®, and nVidia® are registered marks of their respective company. None of these companies is related to this product not do they endorse the performance or compatibility of this product with their products.
