- Page 1 INSTALLATION INSTRUCTIONS Y1-4500 CEILING SHOWER PROJECTION ARM...
- Page 2 Dimensions in Inches (& Millimetres) Ø2 3/8" (Ø60mm) 1 13/16" (46mm) Ø1 3/16" (Ø30mm) 2-1/2-14NPT Whilst every effort is made to ensure accuracy, design and dimensions are subject to change without notice as part of the company’s product development process.
-
Page 3: What You Need To Know
What you need to know Tools: Maintenance Adjustable Wrench Your new bathroom faucet is designed for years Groove Joint Pliers of trouble-free performance. Hacksaw Keep it looking new by cleaning it periodically with Phillips Screwdriver a soft cloth. Avoid abrasive cleaners, wire wool and Pipe Tape harsh chemicals as these will dull the finish and Spatula... -
Page 4: Installation Procedure
Steps 1-4 Installation Procedure Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. Position the escutcheon (or mounting Mark the location of mounting screws. template) on ceiling central to where you wish to make an installation hole 7/10"... - Page 5 Steps 5-6 Installation Procedure Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. Connect the other end of the 1/2’’ copper Attach the escutcheon with the mounting pipe with main water supply. Make sure all screws provided.
- Page 6 Steps 7-8 Installation Procedure Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. Fix the decorative tube at appropriate Installation is completed. position with set screw.
-
Page 7: Exploded View
Exploded View Parts List Fixing anchor bolt (291210) Screw (008191) Escutcheon (019346) Clip (012317) Screw (292628) Connecting Tube (035523) Adaptor (067684) - Page 8 The right to modify designs and dimensions is reserved. Christo Lefroy Brooks is a member of ACID (Anti Copying in Design).
