- Page 1 INSTALLATION INSTRUCTIONS M2-2400 CROSS HANDLE 3-HOLE BATH FILLER TRIM ONLY, TO SUIT R1-4017 ROUGH M2-2401 LEVER 3-HOLE BATH FILLER TRIM ONLY, TO SUIT R1-4018 ROUGH M2-2400 M2-2401...
- Page 2 Dimensions in Inches (& Millimetres) M2-2400 8" (203mm) 3 1/16" (77mm) 5° Ø1" (Ø25.4mm) 3-Ø2 3/8" (3-Ø60mm) Whilst every effort is made to ensure accuracy, design and dimensions are subject to change without notice as part of the company’s product development process.
- Page 3 Dimensions in Inches (& Millimetres) M2-2401 8" (203mm) 3 1/16" (77mm) 5˚ Ø1" (Ø25.4mm) Whilst every effort is made to ensure accuracy, design and dimensions are subject to change without notice as part of the company’s product development process.
-
Page 4: What You Need To Know
What you need to know Tools: Maintenance Adjustable Wrench Your new bathroom faucet is designed for years Groove Joint Pliers of trouble-free performance. Hacksaw Keep it looking new by cleaning it periodically with Phillips Screwdriver a soft cloth. Avoid abrasive cleaners, wire wool and Pipe Tape harsh chemicals as these will dull the finish and Spatula... -
Page 5: Installation Procedure
Steps 1-4 Installation Procedure Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. Once the front wall is finished, take off the Disassemble central canopy and spout by protective caps for installing the trim. - Page 6 Steps 5-7 Installation Procedure Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. Install the handle by fixing the screw with After installation, turn on valve to do water stem extension.
-
Page 7: Exploded View
Exploded View Parts List Cross handle (029685H) M2-2400 Set screw (292598) Canopy (018014) Clip (012242) Stem extension (067773) Adaptor (057507) Escutcheon (071325) O-ring (004640N) Screw (008115) Stem extension (110413) Oil seal (010899) Aerator insert (114237R) Adrator housing (305037) Spout (139657) - Page 8 The right to modify designs and dimensions is reserved. Christo Lefroy Brooks is a member of ACID (Anti Copying in Design).
