SAM1411
Installation and Use
P/N: 6806800M91A
October 2011
Embedded Computing for
Business-Critical Continuity
TM

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAM1411 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emerson SAM1411

Summary of Contents for Emerson SAM1411

  • Page 1 Embedded Computing for Business-Critical Continuity SAM1411 Installation and Use P/N: 6806800M91A October 2011...
  • Page 2 Emerson reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Emerson to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    Alarm Connector ..............41 SAM1411 Installation and Use (6806800M91A)

  • Page 4: Table Of Contents

    SAM1411 Installation ........

  • Page 5: Table Of Contents

    Related Documentation ............. . . 79 Emerson Network Power - Embedded Computing Documents ......79 Related Specifications .
  • Page 6 Contents Contents Contents SAM1411 Installation and Use (6806800M91A)
  • Page 7 U-Boot Commands ............73 Table A-1 Emerson Network Power - Embedded Computing Publications ....79 Table A-2 Related Specifications .
  • Page 8 List of Tables SAM1411 Installation and Use (6806800M91A)

  • Page 9: List Of Figures

    SAM1411 Block Diagram ........
  • Page 10 List of Figures SAM1411 Installation and Use (6806800M91A)

  • Page 11: About This Manual

    Firmware Upgrade Facility on page 59, provides information on the software upgrade tools swupgrade.sh and fw_tool. U-Boot Commands on page 73, lists the U-Boot Commands. Related Documentation on page 79, lists related documentation and specifications. SAM1411 Installation and Use (6806800M91A)
  • Page 12 Internet Protocol Intelligent Platform Management IPMB Intelligent Platform Management Bus IPMC Intelligent Platform Management Controller IPMI Intelligent Platform Management Interface Light Emitting Diode Mezzanine Management Controller NEBS Network Equipment Building System Out-Of-Service Printed Circuit Board SAM1411 Installation and Use (6806800M91A)
  • Page 13 Used for on-screen output and code related elements Screen or commands in body text Used to characterize user input and to separate it Courier + Bold from system output Reference Used for references and for table and figure descriptions SAM1411 Installation and Use (6806800M91A)
  • Page 14 Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury Indicates a property damage message No danger encountered. Pay attention to important information SAM1411 Installation and Use (6806800M91A)
  • Page 15 About this Manual Summary of Changes Part Number Date Description 6806800M91A October 2011 Initial version SAM1411 Installation and Use (6806800M91A)
  • Page 16 About this Manual About this Manual SAM1411 Installation and Use (6806800M91A)

  • Page 17: Safety Notes

    Emerson intends to provide all necessary information to install and handle the product in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete.
  • Page 18 Changes or modifications not expressly approved by Emerson could void the user's authority to operate the equipment. Board products are tested in a representative system to show compliance with the above mentioned requirements.
  • Page 19 Therefore, only install it in or remove it from a powered system if the system itself supports hot swap or high availability and if the system documentation explicitly includes guidelines. SAM1411 Installation and Use (6806800M91A)
  • Page 20 If you have further questions, ask your system administrator. Replacement/Expansion Only replace or expand components or system parts with those recommended by Emerson. Otherwise, you are fully responsible for the impact on EMC or any possible malfunction of the product.

  • Page 21: Sicherheitshinweise

    Produkt mit vielfältigen Einsatzmöglichkeiten handelt, können wir die Vollständigkeit der im Handbuch enthaltenen Informationen nicht garantieren. Falls Sie weitere Informationen benötigen sollten, wenden Sie sich bitte an die für Sie zuständige Geschäftsstelle von Emerson. Das System erfüllt die für die Industrie geforderten Sicherheitsvorschriften und darf ausschließlich für Anwendungen in der Telekommunikationsindustrie und im Zusammenhang...
  • Page 22 Sicherheitshinweise Das Produkt wurde in einem Emerson Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten...
  • Page 23 Hohe Luftfeuchtigkeit und Kondensat auf der Oberfläche des Boards können zu Kurzschlüssen führen. Betreiben Sie das Board nur innerhalb der angegebenen Grenzwerte für die relative Luftfeuchtigkeit und Temperatur. Stellen Sie vor dem Einschalten des Stroms sicher, dass sich auf dem Board kein Kondensat befindet. SAM1411 Installation and Use (6806800M91A)
  • Page 24 Hinweise: Kennzeichnen Sie TPE-Anschlüsse in der Nähe Ihres Arbeitsplatzes deutlich als Netzwerkanschlüsse. Schließen Sie an TPE-Buchsen ausschließlich SELV-Kreise (Sicherheitskleinspannungsstromkreise) an. Die Länge des mit dem Board verbundenen Twisted-Pair Ethernet-Kabels darf 100 m nicht überschreiten. SAM1411 Installation and Use (6806800M91A)
  • Page 25 Sicherheitshinweise Falls Sie Fragen haben, wenden Sie sich bitte an Ihren Systemadministrator. Austausch/Erweiterung Verwenden Sie bei Austausch oder Erweiterung nur von Emerson empfohlene Komponenten und Systemteile. Andernfalls sind Sie für mögliche Auswirkungen auf EMV oder Fehlfunktionen des Produktes voll verantwortlich.
  • Page 26 Sicherheitshinweise SAM1411 Installation and Use (6806800M91A)

  • Page 27: Introduction

    Introduction Overview The SAM1411 is a shelf manager board to be used in the AdvancedTCA systems. It plugs into a dedicated shelf management slot of an AdvancedTCA system. The SAM1411 performs the system monitoring, control, and management functions of the entire shelf. It provides management for up to 16 AdvancedTCA front blades, fans, power entry modules (PEMs), alarm modules, and shelf FRU info modules that are present in an AdvancedTCA system.
  • Page 28 Introduction Telco Alarm connector to the faceplate Telco Alarm signals to the ADP LEDs Local Temperature Sensor SAM1411 Installation and Use (6806800M91A)

  • Page 29: Standard Compliances

    Introduction Standard Compliances The SAM1411, when installed in a compliant chassis, meets the following standards: Table 1-1 Standard Compliances Standard Description UL 60950-1, Defines legal safety requirements EN 60950-1, IEC 60950-1 CAN/CSA C22.2 No 60950-1 CISPR 22 Defines legal EMC requirements on system level (predefined Emerson...
  • Page 30 The product has been designed to meet the directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) Directive 2002/95/EC. The shelf manager board SAM1411 can be operated from -5ºC up to +55ºC without forced cooling. SAM1411 Installation and Use (6806800M91A)
  • Page 31 Introduction Figure 1-1 Declaration of Conformity SAM1411 Installation and Use (6806800M91A)

  • Page 32: Ordering Information

    Introduction Ordering Information Table 1-2 shows the ordering information of the board. For further details, contact the local Emerson representative. Table 1-2 Ordering Information Order No. Description SAM1411 Shelf manager board used in AXP1411 systems SAM1411 Installation and Use (6806800M91A)

  • Page 33: Shelf Manager Hardware

    Chapter 2 Shelf Manager Hardware Overview The SAM1411 is compliant to PICMG 3.0 R3.0 (AdvancedTCA). It is equipped with a backplane connector and is plugged into a 2U slot. Figure 2-1 SAM1411 Block Diagram SAM1411 Installation and Use (6806800M91A)

  • Page 34: Payload Hardware

    The following interfaces are available: Three Ethernet interfaces Two redundancy interfaces (serial) Block transfer interface One diagnostic console interface (serial) 2.2.1 Ethernet Interfaces The shelf manager board has three Ethernet ports which are available concurrently. SAM1411 Installation and Use (6806800M91A)

  • Page 35: Redundancy Interfaces

    AdvancedTCA shelf. 2.2.2 Redundancy Interfaces The SAM1411 uses a private, redundant, high-speed, full duplex serial connection for heartbeating and data replication between the two shelf manager boards. The redundancy interface is routed to the backplane via differential line LVDS transceivers. The physical interface of both channels are compliant with the PICMG 3.0 R3.0 (AdvancedTCA)

  • Page 36: Console Interface

    SAM1411 Control via IPMI Programmer’s Reference Guide. Power Supply The SAM1411 is powered by dual redundant +12 VDC feeds, one from each of the PEMs. This +12 VDC is derived from the -48 VDC feed to each PEM. Each of the two +12 V feeds are separately fused with a 2 A fuse.

  • Page 37: Onboard And External Supply

    2.4.1 Onboard and External Supply The SAM1411 has no provisions to switch off the power input. The board is powered when the power input to either PEM is in the operating range of -40.5 V to -72 V. An on-board DC/DC-converter supplies all onboard circuitry, and provides 3.3 V power supply to external circuits with a consumption of not more than 4.2 W.
  • Page 38 Shelf Manager Hardware SAM1411 Installation and Use (6806800M91A)

  • Page 39: Controls, Indicators, And Connectors

    One 15-pin D-shell connector for the Telco Alarm cable One RJ45 connector for the faceplate Ethernet connector (with integrated Link and Activity LEDs) OOS/IS/ACT/HS LED status indicators Figure 3-1 Face Plate SAM1411 Installation and Use (6806800M91A)

  • Page 40: Leds

    Table 3-1 describes the LEDs that can be found on the face plate of the board. The OOS, I/S, ACT, and H/S LEDs can be controlled via IPMI. For more information, refer SAM1411 Control via IPMI Programmer’s Reference Guide. Table 3-1 Face Plate LEDs...

  • Page 41: Alarm Connector

    Minor Alarm - NO (Normally Open) Minor Alarm - NC (Normally Closed) Minor Alarm - COM (Common) Major Alarm - NO (Normally Open) Major Alarm - NC (Normally Closed) Major Alarm - COM (Common) Pwr Alarm - NO (Normally Open) SAM1411 Installation and Use (6806800M91A)
  • Page 42 Controls, Indicators, and Connectors Table 3-2 Alarm Pin Description Description Pwr Alarm - COM (Common) SAM1411 Installation and Use (6806800M91A)

  • Page 43: Sam1411 Installation

    Chapter 4 SAM1411 Installation Overview To install the SAM1411 into the AdvancedTCA system, follow these steps: 1. Unpack and inspect the board, see Unpacking and Inspecting the Board on page 2. Make sure environmental and power requirements are met, see Requirements on page 3.

  • Page 44: Requirements

    High humidity and condensation on the board surface causes short circuits. Do not operate the board outside the specified environmental limits. Make sure the board is completely dry and there is no moisture on any surface before applying power. SAM1411 Installation and Use (6806800M91A)

  • Page 45: Power Requirements

    (rated voltage), according to Telecommunication Network Voltage (TNV-2). A TNV-2 circuit is a circuit whose normal operating voltages exceed the limits for a safety-extra- low-voltage (SELV) under normal operating conditions, and which is not subject to overvoltages from telecommunication networks. SAM1411 Installation and Use (6806800M91A)

  • Page 46: Rotary Switch Settings

    4.3.3 Rotary Switch Settings The two rotary switches on the SAM1411 are used to set the SGA. The first byte of the shelf address of the shelf FRU information is automatically set to the SGA value. SAM1411 Installation and Use (6806800M91A)
  • Page 47 S1 sets the lower nibble and S2 sets the upper nibble. Use a screwdriver to set the switches by turning them. A little arrow on the switch shows you the value to which the switch is set. Figure 4-1 Rotary Switch Location SAM1411 Installation and Use (6806800M91A)

  • Page 48: Installing And Removing The Board

    SAM1411 Installation Two SAM1411 in the same shelf must always be set to the same SGA. Otherwise, the software detects that the FRU information in the two SAM1411s is different and stops the power-up process. The red LED blinks and the boards are not powered.

  • Page 49: Installing The Board

    7. Wait until the blue LED is on. 8. Screw in the captive screw hand tight. The blue LED blinks. 9. Wait until the blue LED is OFF. This indicates that the board is activated. SAM1411 Installation and Use (6806800M91A)

  • Page 50: Removing The Board

    The board should start to move out of the chassis. Do not force it. If the SAM does not move, it means the captive screw is not fully unscrewed. Unscrew until loose and rotate the ejector handle down. 6. Remove the module from the shelf. SAM1411 Installation and Use (6806800M91A)

  • Page 51: Shelf Manager File System

    5.1.1 Persistent File Support To make files persistent that are usually located under the RAM disk root-file system, Emerson has implemented a persistent file mechanism. All files that are to be stored under the persistent file system instead of the RAM disk file system are listed in a persistent file map. The...
  • Page 52 RAM disk file system to the persistent file system. The persistent map itself is also symlinked at startup from the RAM disk file system to the persistent file system. A default map is copied if it does not exists. SAM1411 Installation and Use (6806800M91A)

  • Page 53: Use Cases

    RAM disk file system is copied automatically during system startup. 5. Reboot the system After system reboot the file on the persistent media is used instead of the file on the RAM disk. SAM1411 Installation and Use (6806800M91A)

  • Page 54: How To Remove A File From The Persistent File System

    /usr/local/var/log. On rebooting the Shelf Manager, all files stored in /usr/local/var/log are moved to /usr/local/var/log.PREVIOUS. This allows two separate set of log files to be saved - the current logs in /usr/local/var/log and the logs from the previous boot in /usr/local/var/log.PREVIOUS. SAM1411 Installation and Use (6806800M91A)

  • Page 55: Log Files

    LogFile name Location of the logfile Default: /var/log/supervisor.log LogFile size Maximum logfile size Default: 500 KB The IP addresses in the log file are dynamic. Only change the elements listed in the table above. SAM1411 Installation and Use (6806800M91A)
  • Page 56 <Supervisor msgPort="5566" queueLen="100" filePort="5568" sendChunkSize="500" startWaitTime="100" restartWaitTime="1000" transitionMaxTime="20000" switchWaitTime="30000" switchIgnoreTime="5000" tieBreak="8" localConnectOnly="0" fileInterface="0.0.0.0"/> <!-- for file transfer using ppp interface fileInterface="@srcIpAddr1@" --> <HeartBeater id="1" port="5567" type="UDP"> <HeartBeaterGroup name="shmgr" id="1" > <HeartBeaterNode id="1" ipAddr="192.168.101.9" port="5567" interval="400" warning="3" inaccessible="5" /> SAM1411 Installation and Use (6806800M91A)
  • Page 57 Shelf Manager File System <HeartBeaterNode id="2" ipAddr="192.168.102.9" port="5567" interval="400" warning="3" inaccessible="5" /> </HeartBeaterGroup> </HeartBeater> </SupervisorConfiguration> SAM1411 Installation and Use (6806800M91A)
  • Page 58 Shelf Manager File System SAM1411 Installation and Use (6806800M91A)

  • Page 59: Firmware Upgrade Facility

    Firmware Upgrade Facility Overview The Firmware Upgrade Facility (FUF) provides a uniform way to upgrade firmware on Emerson hub blades, node blades, and AMC modules. It consists of a Firmware Upgrade Command-line Utility (FCU), flash device drivers, and specially prepared firmware recovery image files.

  • Page 60: Fcu–Firmware Upgrade Command-Line Utility

    -v -f <filename> [-t<slave address>] fcu -u -f <filename> [-t<slave address>] fcu -a -f <filename> fcu -m -b <bank-letter> -d <device-id> [-t<slave address>] fcu -s -f <filename> fcu --activate -b <bank-letter> -d <device-id> Parameters --full-upgrade SAM1411 Installation and Use (6806800M91A)
  • Page 61 --help. Currently supported values are listed in the following table: Device ID Description U-Boot firmware device for ATCA-SAM1411 atca-sam1411-cpu Device Tree Binary device for ATCA-SAM1411 atca-sam1411-dtb Kernel device of ATCA-SAM1411 atca-sam1411-kernel Root filesystem (ramdisk) device for ATCA-SAM1411 atca-sam1411-rootfs IPMC firmware device atca-sam1411-hpm.1-ipmc...
  • Page 62 Otherwise, you must specify a bank and a device. Note that on the ATCA-SAM1411 the U-Boot, DTB, Kernel, and Ramdisk are coupled, this means when you mark a U-Boot image for the next reboot, the other corresponding images are automatically marked as well.
  • Page 63 Usage Some FCU options can be combined. Some options are exclusive. The following list describes the valid option combinations: --full-upgrade --file=<filename> --full-upgrade --file=<filename> --target=xxxxxx --help --mark --bank=<bank-letter> --device=<device-id> --query --query --device=<device-id> --show --file=<filename> SAM1411 Installation and Use (6806800M91A)
  • Page 64 When upgrading firmware, it is strongly recommended that you upgrade only one device at a time. While FCU performs many checks during upgrade to ensure success, if something goes wrong and both firmware banks become corrupted, the blade becomes inoperable. SAM1411 Installation and Use (6806800M91A)

  • Page 65: Upgrading Firmware

    Upgrading CPU Firmware Upgrading CPU Firmware Follow these steps to upgrade the CPU firmware (U-Boot): 1. Query the current and backup U-Boot firmware on the ATCA-SAM1411: # fcu -qd atca-sam1411-cpu 2. Show the version of the new U-Boot image: # fcu -s -f /opt/bladeservices/rom/sam1411-cpu.fri 3.

  • Page 66: Upgrading The Kernel

    The flashcp utility does not upgrade the backup bank, but it upgrades the currently selected bank. Also, the ramdisk must be copied to the ATCA-SAM1411 and placed into /usr/local/ directory in order to upgrade due to the size of the ramdisk image.
  • Page 67 Marked for next use : yes Firmware was booted from this bank BANK Firmware Name : U-Boot Firmware Version : U-Boot 2010.06.2 (Mar 01 2011 - 10:06:53) MPC83XX Marked for next use : no ********************[[[[[ REPORT END ]]]]]******************** SAM1411 Installation and Use (6806800M91A)

  • Page 68: Activating The Backup Boot Bank

    2. Mark the backup boot bank for next use after the next reboot. If Bank A is "Marked for next use", mark Bank 'B' for the next reboot. # fcu -mb B -d atca-sam1411-cpu If Bank B is "Marked for next use", mark Bank 'A' for the next reboot.

  • Page 69: Upgrading Ipmc Firmware

    Follow these steps to upgrade the IPMC firmware. The IPMC firmware becomes active immediately after the successful upgrade. 1. Copy the IPMC firmware file to the ATCA-SAM1411 in the /root directory. The firmware file is not stored within the ramdisk.
  • Page 70 7. There may be changes to files normally stored in the persistent file area when upgrading. Refer to the ATCA-SAM1411 Release Notes for more information. If there are no files in the persistent file area that need to be saved across a reboot (that is, user specific files or changes to configuration files), the persistent file area can be cleared later (before rebooting the Shelf Manager).
  • Page 71 Firmware Upgrade Facility 13. Clear the persistent file area or verify that necessary changes are made according to the ATCA-SAM1411 Release Notes. Reboot both Shelf Managers by issuing the below command from the Linux command line: reboot SAM1411 Installation and Use (6806800M91A)
  • Page 72 Firmware Upgrade Facility SAM1411 Installation and Use (6806800M91A)

  • Page 73: U-Boot Commands

    The SAM1411 uses U-Boot version 2010.06 to initialize Linux on the PPC. When power is applied to the SAM1411, U-Boot initializes the RAM and downloads the kernel image to memory. It also provides support for Ethernet protocols like TFTP, that makes it possible to download images from network servers.
  • Page 74 (default /) fccinfo Print FCC registers Flattened device tree utility commands flinfo Print FLASH memory information fsinfo print information about filesystems fsload load binary file from a filesystem image Start application at address 'addr SAM1411 Installation and Use (6806800M91A)
  • Page 75 MMC sub system mmc_spi mmc_spi setup mmcinfo mmcinfo <dev num>-- display MMC info mtdparts define flash/nand partitions mtest Simple RAM read/write test muxinfo Print CPM Multiplexing registers Memory write (fill) next single step execution, stepping over subroutines SAM1411 Installation and Use (6806800M91A)
  • Page 76 Delay execution for some time smcinfo Print SMC registers sntp synchronize RTC via network source run script from memory spiinfo Print Serial Peripheral Interface (SPI) registers step single step execution test minimal test like /bin/sh SAM1411 Installation and Use (6806800M91A)
  • Page 77 U-Boot Commands Table 7-1 U-Boot Commands (continued) Command Description tftpboot Boot image via network using TFTP protocol true do nothing, successfully version Print monitor version where Print the running stack SAM1411 Installation and Use (6806800M91A)
  • Page 78 U-Boot Commands SAM1411 Installation and Use (6806800M91A)

  • Page 79: A.1 Emerson Network Power - Embedded Computing Documents

    The publications listed below are referenced in this manual. You can obtain electronic copies of Emerson Network Power - Embedded Computing publications by contacting your local Emerson sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 80 Related Documentation Table A-2 Related Specifications (continued) Organization Document Title Service Availability Forum SAF Hardware Platform Interface, SAI-HPI-B.02.01 December 13, 2006 saforum.org SAM1411 Installation and Use (6806800M91A)

  • Page 81: Index

    Input signals upgrade procedure, firmware image Interface use cases Block Transfer persistent file system Ethernet remove a file from the persistent file system IPMB0 rollback factory configuration Redundancy IPMB0 interface IPMC Blue Ordering information Output signals SAM1411 Installation and Use (6806800M91A)
  • Page 82 Index SAM1411 Installation and Use (6806800M91A)
  • Page 84 Precision Cooling Surge & Signal Protection Emerson, Business-Critical Continuity, Emerson Network Power and the Emerson Network Power logo are trademarks and service marks of Emerson Electric Co. All other product or service names are the property of their respective owners.
