Installation Job Aid for Avaya Virtual
Services Platform 7200 Series
Support
Go to the Avaya Support website at
documentation, product notices, and knowledge articles. You can also search for release notes,
downloads, and resolutions to issues. Use the online service request system to create a service
request. Chat with live agents to get answers to questions, or request an agent to connect you to a
support team if an issue requires additional expertise.
Safety messages
Caution:
To protect the switch against ESD damage, take the following measures before you connect
data cables to the device:
• Always use antistatic wrist straps. Make sure you adjust the strap to provide good skin
contact.
• Ensure that you properly ground work surfaces and equipment racks for protection against
electrostatic discharge. You must connect the common point to the building ground wire. In
a properly wired building, the nearest reliable ground is typically at the electrical outlet.
• Avoid contact between equipment and clothing. The wrist or ankle strap protects only the
equipment from ESD voltages on the body; ESD voltages on clothing can still cause
damage.
• Avoid touching any connector pins.
• Do not remove the wrist or ankle strap until the installation is complete.
Caution:
When you mount this device in a rack, do not stack units directly on top of one another. You
must secure each unit to the rack with appropriate mounting brackets. Mounting brackets
cannot support multiple units.
©
2015 Avaya Inc.
http://support.avaya.com
Installation Job Aid for Avaya Virtual Services Platform 7200 Series
for the most up-to-date
Release 4.2.1
NN47228-301
Issue 01.02
January 2015
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Virtual Services Platform 7200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Avaya Virtual Services Platform 7200 Series

  • Page 1 When you mount this device in a rack, do not stack units directly on top of one another. You must secure each unit to the rack with appropriate mounting brackets. Mounting brackets cannot support multiple units. © 2015 Avaya Inc. Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 2: Technical Specifications

    Warning: The lithium battery is not field replaceable. It should be removed and replaced by authorized personnel only. Contact Avaya Technical Support for assistance if the battery requires replacement. Warning: Fiber optic equipment can emit laser or infrared light that can injure your eyes. Never look into an optical fiber or connector port.
  • Page 3: Installing A Power Supply

    • If you only have one power supply, you can install it in either PSU1 or PSU2. • If you install a second power supply, neither one acts as a primary power supply. The two power supplies load share equally. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 4: Installing An Ac Power Supply

    Important: Avaya does not support installing a combination of AC-input and DC-input power supplies in the same chassis. To install an AC power supply, see Installing an AC power supply. To install a DC power supply, see Installing a DC power supply.
  • Page 5 If a power supply fails, replace it as soon as you can but leave it in place until you do. Leaving a power supply slot unpopulated impairs the ability of the fans to cool the chassis. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 6: Ac Power Supply Specifications

    AC power supply specifications The VSP 7254XSQ comes with an 460 W AC power supply and you can install a secondary power supply for redundancy. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 7 Input Voltage (rms): 100–127 V or 200–240 V, 47–63 Hz (50–60 Hz nominal) Power Consumption: 460 W maximum Thermal Rating: 1570 BTU/Hr maximum Inrush Current: 55 A maximum January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 8: Ac Power Cord Specifications

    • 100 or 120VAC • NEMA5-15P male plug • 50–60 Hz • UL-recognized (UL stamped on cord jacket) • Single phase • CSA-certified (CSA label secured to the cord) January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 9: Installing A Dc Power Supply

    Installing a DC power supply Important: Avaya does not support installing a combination of AC-input and DC-input power supplies in the same chassis. The VSP 7200 Series supports two field-replaceable 800 W DC power supplies. One comes with the switch and you can install a second power supply to provide redundancy and load sharing.
  • Page 10 2. Slide the power supply into the slot. 3. Verify that the power supply is fully seated in the slot. The spring latch should engage and return to its original position. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 11 4. Once you install a power supply, use the following steps to connect the DC power supply wiring assembly: a. Avaya supplies a DC power supply wiring assembly to connect the DC power supply to the DC input power source.
  • Page 12 Important: You can hot swap power supplies while the switch is operational. One power supply is required for continued switch operation. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 13: Dc Power Supply Specifications

    • 88% minimum at 100% load level • 92% minimum at 50% load level • 88% minimum at 20% load level • 80% minimum at 10% load level January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 14: Installing A Fan Tray

    2. Enter the following command to determine which fan tray failed. show sys-info fan This command shows the status of each fan tray: up, down, or Not Present when a fan is removed. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 15 Fan Status Fan Type --------------------------------------- regularSpeed regularSpeed regularSpeed Check the internal temperature of the switch. VSP-7254XSQ:1>show sys-info temperature Temperature Info : CPU Temperature MAC Temperature PHY1 Temperature PHY2 Temperature January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 16 Note: The instructions in this section apply to all switches in the Avaya Virtual Services Platform 7200 Series and Avaya Virtual Services Platform 8000 Series. The illustrations show the VSP 8200 as an example, but the instructions apply to any switch in these series.
  • Page 17 Pull the inner chassis rail and slide it out as far as you can. b. Slide the white release lock in the direction of the arrow stamped on the lock. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 18 3. Lift the locking mechanism on the rack rail to slide the outer section back into the main section. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 19 Slide the chassis rail to the rear until the rail locks into the standoffs. c. Make sure the safety tab locks into place. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 20 Adjust the length of the rack rail so it fits the rack depth by loosening the two screws on the rack rail, adjusting the length, and then tightening the screws. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 21 Push the end of the front bracket assembly so it opens up. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 22 Insert the bracket pins into the desired holes in the frame. e. Close the bracket assembly so that it wraps around the frame and locks into place. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 23 6. Use the following steps to install the switch in the equipment rack to complete the installation: a. Insert the chassis rails on the switch into the rack rails on the frame. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 24 To slide the switch back into the rack, push the blue locks on the chassis rails towards the back and slide the switch into the frame. 7. Connect power and network connections to the switch. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 25 5. Remove the two screws and nuts securing the short rear bracket to the rack rail. This bracket is for 300mm-600mm equipment racks only and is not used in this installation. Save the bracket for possible future use. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 26 Lift the locking mechanism and slowly slide the rail back into the main assembly. This exposes a “window” over the screw holes so you can install the remaining three screws one at a time. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 27 Insert the bracket pins into the desired holes in the frame. d. Close the bracket assembly so that it wraps around the frame and locks into place. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 28 To slide the switch back into the rack, push the blue locks on the chassis rails towards the back and slide the switch into the frame. 10. Connect power and network connections to the switch. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 29 • 900mm equipment rack that weighs less than 14kg • 600mm equipment rack that weighs less than 21kg • 300mm equipment rack that weighs less than 42kg January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 30 Follow these steps if you have to remove the switch from an equipment rack. Important: This procedure requires two people. Procedure 1. Disconnect the power cord from the switch. 2. Slide the switch out until the lock engages. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 31 3. While the person standing in back of the chassis slides both of the white release locks (one on each side of the chassis) towards the front, the person standing in front of the chassis pulls the chassis out of the rack. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 32 Procedure 1. Disconnect the power cord from the switch. 2. Attach a bracket to each side of the switch using a #2 Phillips screwdriver as illustrated below. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
  • Page 33 3. Slide the switch onto a shelf or tray in the rack. 4. Insert and tighten the rack-mount screws. 5. Verify that the switch is securely fastened to the rack. 6. Connect power and network connections to the switch. January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series...
