Planet Bike Aero Wireless Instructions

Thank you for purchasing the Planet Bike Aero Wireless
bicycle computer. Planet Bike will donate 25% of our
profits from this purchase and any other Planet Bike
products you buy to grassroots bicycle advocacy groups
that work to improve conditions for cyclists. Enjoy your
Aero Wireless bicycle
computer and thank
you for making a
difference!

2. Mounting Instructions

STEP 1:
Thread the quick ties through the slots in the wheel sensor and attach to the
right or left fork arm so that it is on the same side as the mounting bracket, making
sure that the battery cover is facing the wheel (diagram #1).
STEP 2:
Attach magnet to spoke using a screwdriver (diagram #2) so that the
magnet lines up with the top or bottom glossy line on the wheel sensor. Do not
over-tighten magnet screw.
STEP 3:
Unthread sensor knob until sensor can swivel freely and rotate the sensor until
it is within 2mm of the magnet (diagram 3). Tighten the knob to fix sensor position.
STEP 4:
Attach the computer bracket to the handlebars near the stem (diagram #4).
For 31.8 handlebars, no rubber shim is needed. For smaller diameter handlebars, use the
large shim to achieve a snug fit. Tighten the screw so the bracket will not rotate on
the handlebars. Slide the computer head into the bracket until the latch "snaps" into
place.
STEP 5:
Test for proper alignment of the magnet and sensor. First, push the large
mode button located below the screen to activate. Now, spin the front wheel. Speed will
begin to register if the magnet and sensor are properly aligned.
TO REMOVE COMPUTER FROM BRACKET:
slide the computer forwards off of the bracket (diagram #5).
3. Functions & Specifications
SEE TOP OF
NEXT PAGE.
R
T
M
D
S
SCREEN:
T
1
AVS BIKE ODO MAX
2
AVS ODO MAX
BIKE
3
AVS BIKE ODO MAX
4
AVS BIKE ODO MAX
W I R E L E S S
Push down the bracket latch and
LINE
: LCD Specification : Line 1, 2 and 3 modes do not change
1
CURRENT SPEED • Miles or Kilometers per hour • 0-99.9 mph/Kph • Increments of 0.1 mph/Kph
2
RIDE TIME, "RTM" • Up to 9:59:59 • Increments of 1 second
3
RIDE DISTANCE, "DST" • Up to 999.99 M or K • Increments of 0.01 M or K
4
ODOMETER, "ODO" • Up to 999.99 M or K • Increments of 0.01 M or K
OR
CHANGE MODE TO SCREEN 2-4 BY PUSHING MODE BUTTON TO ACCESS:
AVERAGE SPEED, "AVS" • 0-99.9 mph/Kph • Increments of 0.1 mph/Kph
OR
MAXIMUM SPEED, "MAX" • 0-99.9 mph/Kph • Increments of 0.1 mph/Kph
TEMPERATURE • -19˚ to 120˚F/ -19˚ to 50˚C
OR
CLOCK • 12 Hr format • Indicated by flashing colon ":"
BIKE ODOMETER, "BIKE ODO" • Up to 99,999 M or K • Increments of 0.1 M or K
This is the distance for the wheel size currently being used, it only appears when distance is registered
on both BIKE 1 and BIKE 2.

1. Parts List

1
. 31.8 mm Mounting Bracket
4
. Battery
5
. Wheel Magnet
MOUNTING SENSOR
1
MOUNTING BRACKET
Front
of bike
(ODO= Cumulative distance for BIKE 1 and BIKE 2)
2
. Wheel Sensor
6
. Rubber Shims
MOUNTING MAGNET (Front Wheel)
2
COMPUTER HEAD REMOVAL
Rear
of bike
Front
of bike
Rear
4
of bike
3
. Computer Case
7
. Quick Ties
TURN KNOB
COUNTER
CLOCKWISE
TO ADJUST ANGLE
Line up Sensor
and Magnet at
same level
* Less than
2 mm apart
* DO NOT line
up Magnet
between
GLOSSY LINES
3
on Sensor.
5
PUSH AND RELEASE FOR
MODE
CAUTION
:
CHANGE
HOLD FOR
LESS THAN ONE SECOND
OR YOU WILL RESET ALL
OF THE RIDE DATA
