Sampling and testing procedure
The instrument will check the optical performance of the
measuring system. This process takes approx. 1 – 2 seconds.
Please release the cuvette holder and do not touch it again until
TIP
the process is finished and an audible signal (beep) occurs.
2. If you have the "Hgb limit" mode activated and set the
Illustration 18: Display to select "Patient Type".
In case you wish to change or cancel the selected patient type,
simply touch the "Patient Type" button and make another
selection.
Illustration 19: Display after a patient type (male) is chosen.
24
normal range for each patient type (see Section 5.3.5
"Hgb mode and limits"), the display will show the "Patient
type" buttons that can be selected before testing occurs.
Select the patient type by touching the appropriate
button. If you select "NO", then no patient range will be
displayed or printed with the result.
