USER MANUAL

Ver. 1.0 6/22/19
In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from
time to time. Please check our website for the latest user manuals and product materials.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWAGGER 7 and is the answer not in the manual?

Questions and answers

Related Manuals for SWAGTRON SWAGGER 7

Summary of Contents for SWAGTRON SWAGGER 7

  • Page 1: User Manual

    USER MANUAL Ver. 1.0 6/22/19 In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
  • Page 3 PROTECT YOUR DOME HELMETS SAVE LIVES Helmets can reduce 85% of critical head injuries. Elbow pads can reduce 82% of elbow injuries. Knee pads can reduce 32% of knee injuries. From https://www.ncbi.nlm.nih.gov/pubmed/2716781 Always wear proper protective gear when riding. This includes knee and elbow pads and an age-appropriate helmet. • Helmets should fit comfortably and snugly, covering the forehead but not hindering your field of vision.
  • Page 4 ® The Swagger 7 takes the fun of a skateboard, the ease of an electric scooter, and tops it off with an extra bit of swag. To ensure your safety and the safety of others, please read and follow the guidelines in this user manual carefully and thoroughly before and during riding.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Section 1 Section 4 GENERAL INFORMATION CHARGING 1.1 Important Information ... 01 4.1 Charging the Battery ... . . 13 1.2 Safety Warnings.

  • Page 6: General Information

    Before operating this vehicle, please read all instructions. This manual will guide you through the functions, usage, and proper care of your Swagger 7 Folding Electric Scooter. If you have any questions or cannot find the information you need in the manual, please contact your place of purchase or our customer service at 1-844-299-0625.

  • Page 7: Safety Warnings

    1.2 Safety Warnings When reading this manual, note these icons: Notes with this icon MUST be read, understood, and obeyed to prevent injury or damage, etc. Notes with this icon include relevant information. • Do not place the battery in fire or direct contact with flames, heat or sunlight. •...

  • Page 8: Disposal At End-Of-Life

    The substances contained inside the battery present chemical risks to the environment. The recommended disposal for any Swagger 7 Folding Electric Scooter at its end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility. Local regulations and laws pertaining to the recycling and disposal of lithium-ion batteries and/or products containing them will vary according to country, state, and local governments.

  • Page 9: Fcc Information

    1.4 FCC Information DECLARATION OF CONFORMITY: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 10: Parts & Features

    Section 2 PARTS & FEATURES Please read the user manual in its entirety before using the Swagger 7 so that you may fully understand its parts and functions and be able to operate it safely. 2.1 What’s in the Box? • 1x Cable Ties*...

  • Page 11: Diagram

    2.2 Diagram 1. Brake 2. Bell 3. LCD Display 4. Lock 5. Throttle 6. Power Button 7. Speed Button 8. Handles 9. Headlight 10. Stem 11. Collar 12. Front Bumper 13. Motorized Front Wheel 14. Kickstand 15. Rear Wheel 16. Taillight 17.

  • Page 12: Display Information

    2.3 Display Information The Swagger 7’s display can show a lot of information. Be sure you understand these before attempting to ride. Press and hold the power button approximately 3 seconds to turn the scooter on/off. K M/H MP H 1.

  • Page 13: Program Menu

    2.4 Program Menu The display features five program settings which are not readily indicated on the screen by default. Follow the steps to access the settings screen and make changes. Step 1. Press and hold the SPEED and POWER buttons simultaneously for ~2s to enter the main settings screen, Step 2.
  • Page 14 This setting is for the maximum speed limited setting at Sport Mode (mode 3). There are three options here: Option 1: 12.4 mph (20 km/h) Option 2: 15.5 mph (25 km/h) Option 3: FF (no limit) Option 3 is the default setting. SWAGTRON SWAGGER 7 USER MANUAL 09...

  • Page 15: Folding & Assembly

    Section 3 FOLDING & ASSEMBLY Make sure the Swagger 7 is off before working with any of its parts. The scooter comes mostly assembled within the package. Some minor assembly is required before riding. All parts and tools are included.
  • Page 16 Step 3. Fold the latch up towards the stem and turn the collar counter-clockwise to lock it. Make sure the scooter is turned off before Lock moving, lifting, or otherwise transporting the scooter. Hook SWAGTRON SWAGGER 7 USER MANUAL 11...

  • Page 17: Tire Inflation

    • Under inflation is strongly recommended if you intend to ride outdoors in temperatures above 90°F degrees. Bring the Swagger 7 indoors and deflate the tires to 45 PSI. If the PSI is too high and the tire are exposed to excessively high temperatures, riding outdoors may cause serious damage to the tires...

  • Page 18: Charging

    Swagger 7. Only use the included charger to recharge the Swagger 7. You can charge the Swagger 7 battery when it’s installed in or detached from the scooter.

  • Page 19: Detaching/Install The Battery

    • Line up the inside cover with the insertion guides in the stem. Reinsert the inside cover into the stem. • Push down on the inside cover while turning it clock- wise to lock in place. • Close the outside cover. To purchase additional Swagger 7 batteries, visit www.swagtron.com.

  • Page 20: Usage

    • The Swagger 7 contains a motor and may be classified as a motor vehicle under local laws in your area. It is your responsibility to understand and abide by any local laws restricting how or where you may ride.

  • Page 21: How To Ride

    5.1 How to Ride Assuming you have equipped suitable protective gear and that the Swagger 7 has been placed on a level surface, is charged, and does not have any issues, follow the steps below. For your safety, please read this entire section before attempting to ride.
  • Page 22 Dismount one foot at a time. Be extra cautious when dismounting for the first time. This feature remains active until you manually turn it off in the Program Menu (see Section 2.4 Program Menu), even if you power off the scooter. SWAGTRON SWAGGER 7 USER MANUAL 17...

  • Page 23: Practicing Guidelines

    • The Swagger 7 is designed for relatively smooth, flat terrain. When driving on uneven terrain, slow down. • Until you are comfortable using the scooter, avoid operating in places with pedestrians or obstacles.

  • Page 24: Maintenance

    For questions, concerns, or part replacement, please contact customer service. 6.1 Cleaning The Swagger 7 may need cleaning after riding for extended periods of time. Follow the tips below. • Completely power off the scooter before cleaning. • Use dry, non-abrasive cloth to gently remove debris or dust.

  • Page 25: Storage

    The Swagger 7 weighs approximately 27.6 lbs (12.5kg). If you are unsure of your ability to lift this weight, please use both hands or have a second person help when lifting the entire scooter.

  • Page 26: Specifications

    * Specs provided here assume an average rider weighing approx. 165 lb (75 kg) riding on flat, even pavement. Performance will vary according to a number of factors, including riding style, rider weight and terrain conditions. SWAGTRON SWAGGER 7 USER MANUAL 21...
  • Page 27 Indicators Items Parameters Battery Type Lithium-ion (rechargeable) Battery Management Automatic shutoff, Overcharging, Under-voltage, Overheating Power Voltage 36V 6.4Ah Charging Time 3~4 hours Model FY-4202000 Input Voltage 100-240V 50/60Hz 2.5A Output Voltage 42V 2.0A Charger Shenzhen Fuyuandian Power Co.,Ltd Manufactured By 8F,Building A9,TianRui Industrial Park,1st Fuyuan Road, Xinhe, Fuyong,Baoan, shenzhen, Guangdong, China...

  • Page 28: 90-Day Limited Hardware Warranty

    This Warranty is not assignable or transferable. The original purchaser may call SWAGTRON’s toll-free number at 1-844-299-0625 for service request.
  • Page 29 (h) external causes such as accidents, abuse, or other actions or events beyond our reasonable control. ® Important: Do not disassemble the Product. Disassembling the Product will void this Warranty. Only SWAGTRON ® a party expressly authorized by SWAGTRON should perform service on this Product.
  • Page 30 Copyright © 2019 SWAGTRON. All rights reserved.
