USER MANUAL
Ver. 1.0 12/3/19
In order to continue serving our customers and providing the best products, our product information including our user manuals
may receive updates from time to time. Please check our website for the latest user manuals and product materials.
SWAGGER 5 DASH LITE
01
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWAGGER 5 DASH LITE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWAGTRON SWAGGER 5 DASH LITE

Summary of Contents for SWAGTRON SWAGGER 5 DASH LITE

  • Page 1 In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. SWAGGER 5 DASH LITE ENGLISH...
  • Page 2 PROTECT YOUR DOME HELMETS SAVE LIVES Helmets can reduce 85% of critical head injuries. Elbow pads can reduce 82% of elbow injuries. Knee pads can reduce 32% of knee injuries. From https://www.ncbi.nlm.nih.gov/pubmed/2716781 Always wear proper protective gear when riding. This includes knee and elbow pads and an age-appropriate helmet.
  • Page 3 Thank you for your purchase of the Swagger 5 Dash Lite Folding Electric Scooter by SWAGTRON ® To ensure your safety and the safety of others, please read the guidelines in this user manual and follow them during riding. If you have any questions regarding the Swagger 5 Dash LiteS, contact us at 1-844-299-0625 for further assistance.

  • Page 4: Table Of Contents

    5.2 Storage ............17 SECTION 6: SPECIFICATIONS ....... 18 2.2 Assembly ............08 SECTION 7: 90-DAY LIMITED HARDWARE 2.3 Swagger 5 Dash Lite Diagram ......09 WARRANTY ............20 2.4 Display Indicators ........... 10 2.5 Standing, Folding, and Unfolding ....11 SECTION 3: CHARGING ........

  • Page 5: Section1: General Information

    Within this manual, “the Swagger 5 Dash Lite”, “your Swagger 5 Dash Lite”, “your scooter” and “the scooter” refer to the Swagger 5 Dash Lite Folding Electric Scooter. The Swagger 5 Dash Lite is a personal scooter that uses electrical power. By riding the Swagger 5 Dash Lite, the user acknowledges and accepts responsibility for all risks associated with the use of the Swagger 5 Dash Lite which may include, but are not limited to, muscle injuries, broken bones, lacerations, serious injury, and possible death.

  • Page 6: Fcc Information

    1.2 FCC Information DECLARATION OF CONFORMITY: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Disposal At End-Of-Life

    The substances contained inside the battery present chemical risks to the environment. The recommended disposal for any Swagger 5 Dash Lite Folding Electric Scooter at its end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility. Local regulations and laws pertaining to the recycling and disposal of lithium-ion batteries and/or products containing them will vary according to country, state, and local governments.

  • Page 8: Section 2: Features

    SECTION 2: FEATURES 2.1 What’s in the Box? ■ 1x Swagger 5 Dash Lite Folding Electric Scooter ■ 2x Handles ■ 1x Charging Cable / Adapter ■ 2x Allen Keys ■ 1x User Manual 2.2 Assembly The scooter comes mostly pre-assembled. Simply screw each handle into each side of the middle connector bar.

  • Page 9: Swagger 5 Dash Lite Diagram

    2.3 Swagger 5 Dash Lite Diagram 1. Handles 2. Display 3. Stem 4. Suspension 5. Motorized Front Wheel 6. Support Wheels 7. Kickstand 8. Reflector 9. Rear Passive Wheel 10. Footbrake 11. Folding Slot 12. Deck 13. Lock Slots 14. Folding Latch 15.

  • Page 10: Display Indicators

    2.4 Display Indicators DO NOT expose the display to direct sunlight or high heat for extended periods of time. DO NOT store the scooter inside a vehicle or other location subject to high heat. Any of these conditions may damage the display’s interface. After 5 minutes of non-use, the display will turn off as the scooter turns off.

  • Page 11: Standing, Folding, And Unfolding

    Step 2. Pull the stem down towards the deck, line the pin with the second notch, and push the lever back into place as needed. SWAGGER 5 DASH LITE ENGLISH...
  • Page 12 Make sure the pin slides into the notch and the lever fully moves back in place; otherwise, the scooter may unfold. Unfolding Step 1. Pull the lever down towards the deck. The pin connected to the lever should slide up out of its notch.

  • Page 13: Section 3: Charging

    The charging time is 4~5 hours. Charging longer than that may affect battery life and/or performance. If the charger’s light doesn’t turn on, it may not be fully connected. Check that it is securely connected to the wall and to the scooter. SWAGGER 5 DASH LITE ENGLISH...

  • Page 14: Safety Warnings

    3.2 Safety Warnings - Do not place the scooter or its battery in fire or direct contact with heat. - Do not attempt to pierce the battery with sharp objects, strike, step on, or otherwise subject it to strong impact. - Do not expose the scooter or its battery to water or any liquids, or allow the battery to get wet.

  • Page 15: Section 4: Usage

    Brake Assuming you have equipped suitable protective gear and that the Swagger 5 Dash Lite has been placed on a level surface, is well charged, MFN Button and does not have any issues, follow the steps below. For your safety,...

  • Page 16: How To Ride

    4.2 How to Ride Step 1. Turn on the scooter. Carefully step on with one foot and stand upright but relaxed. Grab both handles. Step 2. Keep one foot on the ground and kick off to begin accelerating manually. Continue accelerating by pressing the throttle.

  • Page 17: Section 5: Maintenance

    Cover the scooter when storing to protect from dust. ■ If storing for more than one month, discharge and recharge the battery every three months. ■ DO NOT store in an unheated garage, shed, or other location with extreme temperature fluctuations or ranges. SWAGGER 5 DASH LITE ENGLISH...

  • Page 18: Section 6: Specifications

    SECTION 6: SPECIFICATIONS Properties Items Parameters Folded 46.5 x 17.3 x 8.66 in. (1180 x 440 x 220mm) Size Opened 45.67 x 17.3 x 43.7 in. (1160 x 440 x 1110mm) Weight Vehicle Weight About 28.66 lb. (13 kg) Max. Load 264.5 lb.
  • Page 19 AC100 - 240 V 50/60Hz 2A Rated Output Voltage 42 V Rated Current 1.5 A Charger Charging Time 4~5 hrs Manufactured by: Shenzhen hyleton Technology Co., Ltd Address: 4th Floor, Building A3, Fenghuanggang Third Industrial Zone, Xixiang, Bao’an District, Shenzhen SWAGGER 5 DASH LITE ENGLISH...

  • Page 20: Section 7: 90-Day Limited Hardware Warranty

    ® Your SWAGTRON Swagger 5 Dash Lite Folding Electric Scooter (“Product”) includes a 90-Day Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States (excluding Hawaii, Alaska and U.S. Territories) and Canada only and is available only to original purchasers.
  • Page 21 (h) external causes such as accidents, abuse, or other actions or events beyond our reasonable control. ® Important: Do not disassemble the Product. Disassembling the Product will void this Warranty. Only SWAGTRON or a party ®...
  • Page 22 COPYRIGHT © 2019 SWAGTRON. ALL RIGHTS RESERVED.
