  • Page 1 PDRP-1001 Deluge - Preaction Control Instruction Manual Series Panel 3825 Ohio Avenue St. Charles, IL 60174 1-800-SENSOR2 Fax: (630) 377-6495 Document 50734 I56-933-01 04/06/2001 Rev: PN 50734:D0 ECN 00-543...

  • Page 2: Fire Alarm System Limitations

    Fire Alarm System Limitations An automatic fire alarm system–typically made up of smoke detectors, heat detectors, manual pull stations, audible warn- ing devices, and a fire alarm control with remote notification capability–can provide early warning of a developing fire. Such a system, however, does not assure protection against property damage or loss of life resulting from a fire.

  • Page 3: Installation Precautions

    Installation Precautions WARNING - Several different sources of power can be con- nected to the fire alarm control panel. Disconnect all sources of power before servicing. Control unit and associated equip- ment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized.

  • Page 4: Nfpa Standards

    NFPA Standards This control panel complies with the following NFPA standards: • NFPA 13 - Sprinkler Systems • NFPA 15 - Water Spray Systems • NFPA 16 - Foam-Water Deluge Systems and Foam-Water Spray Systems • NFPA 72 - Central Station Signaling Systems (Automatic, Manual, and Waterflow) - Protected Premises Unit Requires NOTI-FIRE 911AC DACT or 411UDAC Universal Digital Alarm Communicator •...

  • Page 5: Table Of Contents

    NFPA Standards... 4 NFPA Standards ... 4 Underwriters Laboratories Documents ... 4 Other... 4 1. Product Description Overview ... 7 Features ... 7 Options ... 7 Circuits ... 8 Input Circuits... 8 Output circuits... 8 Front Panel Control Switches ... 8 Suplemental Documentation ...
  • Page 6 Table of Contents Setup and Configuration... 25 Transmitter Module - 4XTM ... 25 Zone Relay Module - 4XZM ... 26 LED Interface Module - 4XLM ... 27 Setting Mode of Operation ... 28 Basic Program ... 28 Discharge Timer ... 29 Power-Up Procedure ...

  • Page 7: Product Description

    1. Product Description Overview The PDRP-1001 Series Deluge - Preaction Control System has been designed as a control center for use in single- and dual-hazard deluge and preaction applications. The panel is a feature-packed control unit suitable to perform detection and control functions associated with the release of water-based fire protection systems.

  • Page 8: Circuits

    1. Product Description Circuits Input Circuits Initiating Device Circuit #1 (Style B/D) Initiating Device Circuit #2 (Style B/D) Waterflow (Style B/D) Supervisory (Style B/D) Output circuits NAC 1 - Alarm/Waterflow (Style Y/Z) NAC 2 - Waterflow/Supervisory (Style Y/Z) Releasing Circuit 1 (Style Y) Releasing Circuit 2 - Supervisory (Style Y) Note: Zone Relay Module (4XZM) tracks these four circuits.

  • Page 9: Control Panel

    Control Panel Control Panel Notification Appliance Circuits Style Z (Class A) / Style Y (Class B) 24VDC Regulated Nonresettable Regulated Resettable RMS-Regulated O U T #1 B + A + A – B – TB 1 TB 5 AM P Battery Fail LED Ground Fault LED PDRP-1001 Instruction Manual PN 50734:D0 04/06/01...

  • Page 10: Dip Switch Functions

    1. Product Description DIP Switch Functions The table below describes the DIP switch functions. For a more detailed explaination see "Setting Mode of Operation" on page 28. #1 & #2 #3, #4 & #5 Note: See “Setting Mode of Operation” on page 28 for a more detailed explanation of DIP switch functions.

  • Page 11: Remote Annunciator - Rza-4X

    Options Remote Annunciator - RZA-4X The Remote Annunciator mounts on a standard single-gang box, and provides LED indication of the same functions as the Zone Relay Module. • Alarm/Alarm Pressure (red) • Alarm Pressure/Aux Supervisory (red) • Releasing Circuit 1 (red) •...

  • Page 12: Specifications

    1. Product Description Specifications AC Power PDRP-1001 and PDRP-1001A: 110/120 VAC, 50/60 Hz, 1.2 amps PDRP-1001E: 220/240 VAC, 50/60 Hz, 0.6 amps Wire size: minimum #14 AWG with 600V insulation Battery (lead acid only) Maximum Charging Circuit: 27.6V, 1.5 amps Maximum Battery Capacity: 18 AH.

  • Page 13: Installation

    Cabinet Mounting Carefully unpack the system and check for shipping damage. Select a suitable location in a clean, dry, vibration-free environment that is not subject to extreme temperatures. Locate the top of the cabinet approximately five feet above the floor with the hinge on the left.

  • Page 14: Reinstallation Of Circuit Board

    2. Installation The figure below shows the exterior dimensions and mounting hole locations for the cabinet backbox and dimensions of the optional trim ring: 1 6.12 5 ” (4 0.96 cm ) 1 .0 0” (2 .5 4cm ) (3 6.83 cm ) 1 .0 0”...

  • Page 15: Installing Optional Voltmeter/Ammeter

    Installing Optional Voltmeter/Ammeter Installing Optional Voltmeter/Ammeter To monitor battery voltage and battery charging current, a 4XMM Meter Module is required. To install the power meter module follow the steps below: Step The figure below shows the mounting location and connections for the Voltmeter/Ammeter. PDRP-1001 Instruction Manual PN 50734:D0 04/06/01 Action Cut the jumper wire labeled “AMP”.

  • Page 16: Power Connections

    2. Installation Power Connections WARNING: Do not apply any type power to this control panel until all connections have been made and verified. AC Connections Disconnect (open) the circuit breaker in the AC main breaker panel and tag it “Out of Service”. Note: Refer to "Power-Up Procedure"...

  • Page 17: Power-Limited Wiring Requirements

    Power-limited Wiring Requirements Observe polarity when connecting the batteries. Connect the battery cable (p/n 75203 or 75202, depending on terminal size of battery) to terminal J9 on the main circuit board using the plug-in connector provided. Connect red wire to positive (+) terminal and black wire to negative (–) terminal on opposing batteries. Do NOT connect battery interconnect wire at this time.

  • Page 18: Initiating Device Circuits

    2. Installation Initiating Device Circuits The control panel provides four (4) Initiating Device Circuits (#1, #2, #3 and #4) and they may be configured as either Style D (Class A) or Style B (Class B). Initiating devices include: Heat, Photoelectric and Ionization type detectors, Manual Pull Stations and Waterflow alarm devices.

  • Page 19: Four-Wire Smoke Detector Connections

    Initiating Device Circuits Four-Wire Smoke Detector Connections A maximum of 200mA is available from the 24VDC Resettable Power circuit on TB1 (+24VR terminals). Any power that is drawn from the 24VDC Nonresettable Power on TB2 (+24VNR terminal) must be subtracted from available resettable power. See "Specifications" on page 12 and "Powering External Devices"...

  • Page 20: Output Circuits

    2. Installation Output Circuits Notification Appliance Circuits The control panel provides two Style Z (Class A) or Style Y (Class B) Notification Appliance Circuits, which are supervised and power-limited. Each circuit is capable of 1.5 amps of current. Total current drawn from both NACs and both Releasing Circuits (see "Releasing Circuits"...

  • Page 21: Releasing Circuits

    Output Circuits Releasing Circuits CAUTION: To prevent accidential discharge, connect releasing devices after initial panel tests are completed. The control panel provides two Style Y (Class B) Releasing Circuits, which are nonpower-limited. Note: All wiring must follow the requirements as specified under "Power-limited Wiring Requirements" on page 17. Each circuit is capable of 1.5 amps of current.

  • Page 22: Alarm Relay Circuit

    2. Installation Alarm Relay Circuit One Form-C dry contact alarm relay is provided in the basic panel for controlling supplementary devices. Contacts are rated 2 amps at 30 VDC and 0.5 amps at 30 VAC (resistive) and are non-silenceable when an alarm occurs.

  • Page 23: Optional Modules

    Optional Modules Optional Modules Overview The control panel has two module connectors - J5 (upper position) and J8 (lower position). Three modules are available for the panel and they can be used in any combination, including duplicate modules. The corresponding option jumper must be cut before installation of an optional module, to enable module supervision.

  • Page 24: Installation - Lower Position

    2. Installation Installation - Lower Position To install either the 4XTM, 4XZM or 4XLM module in the lower position follow these instructions: Step Action Cut jumper ‘OPT2’ on main circuit board. Remove the lower-right screw securing the main board to the lower rail. Replace with a stand-off and tighten securely.

  • Page 25: Setup And Configuration

    Optional Modules Setup and Configuration Transmitter Module - 4XTM Connect a Remote Alarm circuit, Remote Trouble circuit or a Municipal Box to the Transmitter Module as shown below. Polarities shown in activated positions. Note: Dummy load terminals 6 and 7 (4.7K, 1/4 W resistor) if Municipal Box is not connected. Note: Remote Alarm, Remote Trouble and Municipal Box wiring can leave the building.

  • Page 26: Zone Relay Module - 4Xzm

    2. Installation Zone Relay Module - 4XZM Note: The PAR-3 includes one (1) Zone Relay Module (4XZM). Relay #1 through #4 on this module will activate with outputs #1 through #4. For non-latching (silenceable) relay operation, cut the jumper “LATCH”. If this jumper is left intact, the relays will latch upon activation.

  • Page 27: Led Interface Module - 4Xlm

    Optional Modules LED Interface Module - 4XLM Connect the terminals on TB1 of the LED Interface Module to the corresponding terminals of the RZA- 4X Remote Annunciator. Make wiring connections with system power off. Maximum wire impedance is 50 ohm per wiring connection. The wiring of this module must follow the requirements as specified under "Power-limited Wiring Requirements"...

  • Page 28: Setting Mode Of Operation

    2. Installation Setting Mode of Operation Select operating mode by setting the SW1 DIP switches as described below. After any changes are made to the configuration of the switches, the panel must be reset. For Canadian use, refer to "Sprinkler Supervisory Tracking" on page 34. Basic Programming Switch 1: Cross Zone Switch 2: Dual Hazard...

  • Page 29: Discharge Timer

    Setting Mode of Operation Discharge Timer Select the desired discharge timer setting by setting DIP Switches 3, 4 and 5 accordingly. • For NFPA 13 and 15 applications timer must be set to “Disabled”. • For NFPA 16 applications timer may be set to “10 Minutes” or “15 Minutes”. Note: Timer will always start at Zone 2 normal to alarm transition.

  • Page 30: Power-Up Procedure

    2. Installation Power-Up Procedure WARNING: Prior to energizing this panel, notify all personnel and authorities, including any personnel who may be working on, around, or near this unit. WARNING: Battery contains sulfuric acid which can cause severe burns to the skin and eyes and can destroy fabrics.

  • Page 31: System Operation

    System Status LEDs Alarm, Trouble and Supervisory LEDs will flash on and off until the event(s) has been acknowledged (TONE or ALARM SILENCE), at which point the LED will illuminate steadily. AC Power - Green LED that illuminates steadily to indicate presence of AC power. System Alarm - Red LED that flashes when an alarm occurs.

  • Page 32: Control Switches

    3. System Operation Control Switches Tone Silence - Pressing this switch acknowledges alarms, troubles and supervisories. The panel has alarm and trouble resound with LED flash of new conditions. The flashing trouble LED(s) illuminate steadily on TONE SILENCE and the piezo turns off. A second trouble will resound the piezo. Trouble conditions are self-restoring.

  • Page 33: Piezo

    Piezo Piezo The piezo (local buzzer) generates different tone patterns for different event conditions: • Alarm - Generates a steady tone, no pulse. • Trouble - Pulses one second on, one second off. Repeats 30 pulses per minute. • Supervisory - Pulses one-half second on, one-half second off. Repeats 60 pulses per minute. Supervisory Service Initiating Device Circuit #4 is always used for monitoring supervisory devices (such as valve tamper switches).

  • Page 34: Last Event Recall

    3. System Operation Last Event Recall Last Event Recall allows the user to display the previous panel status. The Last Event Recall makes use of the four panel switches as follows: Press and hold in the TONE SILENCE switch. With the TONE SILENCE switch held in, press (in sequence) the SYSTEM RESET switch, the ALARM ACTIVATE switch, and then the ALARM SILENCE switch.

  • Page 35: Single Zone In Alarm (Cross Zone) Condition

    System Events Single Zone in Alarm (Cross Zone) Condition Upon actuation of a single-zone initiating device, a red alarm LED will illuminate to indicate whether Zone 1 or Zone 2 is in alarm. In addition to the LED, a single-zone alarm will activate the Alarm Relay; the piezo and NAC #1 will start sounding.
  • Page 36 3. System Operation System Events Notes PDRP-1001 Instruction Manual PN 50734:D0 04/06/01...

  • Page 37: Appendix A: Secondary Power Calculations

    Appendix A: Secondary Power Calculations Standby Battery Requirements The Standby Battery Current obtained in the table below represents the amount of current that must be supplied by the secondary power source (batteries) to sustain control panel operation for one hour. Note: The control panel will support the installation of one or two optional modules, including two of the same type of module.

  • Page 38: Calculating The Battery Capacity

    Appendix A: Secondary Power Calculations Calculating the Battery Capacity Use this table to determine the battery capacity required by the system. Standby Battery Current (from Table 1) ] amps 1. NFPA 72 Central Station and Local and Proprietary Fire Alarm Systems require 24 hours of standby time. 2.

  • Page 39: Appendix B: Compatible Devices

    Appendix B: Compatible Devices Two-wire Smoke Detectors, UL Listed Use the two-wire detectors listed below. Detector Model System Sensor 1400 System Sensor 1451 System Sensor 1851DH System Sensor 2400 System Sensor 2400AIT System Sensor 2400AT System Sensor 2400TH System Sensor 2451...

  • Page 40: Four-Wire Smoke Detectors, Ul Listed

    Four-wire Smoke Detectors, UL Listed Use the four-wire detectors listed below. Detector/Base System Sensor 2424 System Sensor 2424TH System Sensor 2451 System Sensor 2451TH w/B402 Base System Sensor 1424 System Sensor 1451 w/B402 Base System Sensor 2412 System Sensor 2412AT System Sensor 2412TH...

  • Page 41: Notification Appliances, Ul Listed

    Product System Sensor MA-12/24D Electronic Sounder System Sensor SS24 Strobe System Sensor SS24LO Strobe System Sensor SS24LOC Ceiling Strobe (SS24LOBC - beige) System Sensor SS24M Strobe System Sensor SS24MC Ceiling Strobe System Sensor MASS24D Electronic Sounder/Strobe System Sensor MASS24LO Electronic Sounder/Strobe...
  • Page 42 System Sensor SP101R24M Speaker/Strobe, 5” square grill System Sensor SP100W24MC Ceiling Speaker/Strobe, 8” round grill System Sensor MA12/24EH Multi Alert Horn with Mechanical Tone System Sensor MAEH24LO Multi Alert Horn with Mechanical Tone/Strobe System Sensor MAEH24LOC Multi Alert Horn with Mechanical Tone/Strobe...

  • Page 43: Door Holders, Ul Listed

    Wall Mount, Concealed Wiring DH150A Floor Mount DH154A Flush Mount DH158A Surface Mount Table 7 Door Holders Vendor Model System Sensor A77-716B Air Products & Controls, LTD MR-101/C MR-201/C Table 8 24 VDC Relays Appendix B: Compatible Devices Current (mA) Current...
  • Page 44 Appendix B: Compatible Devices 24 VDC Relays, UL Listed Notes PDRP-1001 Instruction Manual PN 50734:D0 04/06/01...

  • Page 45: Appendix C: Nfpa Standard-Specific Requirements

    Appendix C: NFPA Standard-Specific Requirements Minimum System Requirements The control panel has been designed for use in commercial, industrial, and institutional applications and meets the requirements for service under the National Fire Protection Association (NFPA) Standards outlined in this appendix. The minimum system components required for compliance with the appropriate NFPA standard are listed below.

  • Page 46: Digital Alarm Communicator/Transmitter - Noti-Fire 911Ac

    Appendix C: NFPA Standard-Specific Requirements Digital Alarm Communicator/Transmitter - Noti-Fire 911AC Note: This application is not FM approved Using the Noti-Fire 911AC DACT for connection to a Central Station Receiver or Protected Premises Receiving Unit. • AC Wiring for DACT/FACP must be connected to the same circuit. •...

  • Page 47: Universal Digital Alarm Communicator - 411Udac

    (6.1 meters) in length in the same room. • The PDRP-1001 Series is non suitable for transmission of a supervisory signal to the DACT. • Any zone of the 411UDAC can be wired to function as alarm or trouble; the unit must be programmed accordingly.

  • Page 48: Local Energy Municipal Box

    Appendix C: NFPA Standard-Specific Requirements Local Energy Municipal Box Using the 4XTM Transmitter Module for connection to a Local Energy Municipal Box. • The Municipal Box circuit supervises for ground faults and opens (i.e. missing wire) but not for direct short between two wires. It is not a power-limited circuit. •...

  • Page 49: Remote Station Receiver - Rs82-9

    Remote Station Receiver - RS82-9 Using the 4XTM Transmitter Module for connection to a Fire•Lite RS82-9 Remote Station Receiver. • Intended for connection to a polarity reversal circuit of a remote station receiving unit having compatible ratings. • All connections are power-limited and supervised with the exception of the reverse polarity loop. •...
  • Page 50 Appendix C: NFPA Standard-Specific Requirements Remote Station Receiver - RS82-9 Notes PDRP-1001 Instruction Manual PN 50734:D0 04/06/01...

  • Page 51: Appendix D: Testing & Maintenance

    Appendix D: Testing & Maintenance Testing Inspection Perform the following prior to applying power to the system. • Check the actual wiring hookup with the wiring diagrams. • Insure that no pieces of wire have fallen into the circuitry. • Check for missing or damaged parts. Alarm Test An initial alarm test should be conducted following installation to determine that all parts of the system are functioning properly.
  • Page 52 Appendix D: Testing & Maintenance Symptom Circuit trouble LED ON Any of the right column yellow LEDs flashing Any of the right column yellow System trouble LEDs steady LED ON Power trouble LED ON Power LED ON Yellow LED on 4XTM ON Any of the right column red LEDs Disconnecting Municipal Box...
  • Page 53 Numerics 110/120 VAC 12 220/240 VAC 12 411UDAC 45, 47 4XLM LED Interface Module 11, 23 4XMM Meter Module 11, 15 4XTM Transmitter Module 10, 23, 45, 48, 49 4XZM Zone Relay Module 10, 23 911AC DACT 45, 46 AC branch circuit 47 AC power 31, 47, 51 accidential discharge 21 acknowledge 32...
  • Page 54 Index inspection 51 interconnect wire, battery 30 Interface Module 11 interruption of circuits 34 J1 connector 13, 14 J2 Connector 15 J3 Connector 15 J9 Connector 17 JP1 jumper 47 jumper 23, 24 LATCH 26 keyhole 13 knockouts 13, 17 label Protected Premises Unit 26 terminal identification 23, 24...
  • Page 55 resettable power 19, 22 resistance, allowable 19 resistor 47 resound 32 reverse polarity 25 reverse polarity circuit 10 reverse polarity loop 49 RS82-9 Remote Station Receiver 45, 49 RZA-4X Remote Annunciator 11 second alarm 35 Secondary Power 30 secondary power source 37 self-restoring 32 separate transmission 48 short circuit 33...

  • Page 56: Limited Warranty

    For products not under System Sensor warranty is eighteen (18) months from date of original purchase by System Sensor tributor unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply.
