Summary of Contents for Taylor RD25
- Page 1 OPERATOR’S MANUAL Model RD30 & RC25 Remote Slush Freezer Original Operating Instructions 051060- M 11/99 (Original Publication) (Updated 7/6/15)
- Page 2 Complete this page for quick reference when service is required: Taylor Distributor: Address: Phone: Service: Parts: Date of Installation: Information found on the data label: Model Number: Serial Number: Electrical Specs: Voltage Cycle Phase Maximum Fuse Size: Minimum Wire Ampacity: E 1999 Carrier Commercial Refrigeration, Inc.
-
Page 3: Table Of Contents
Table of Contents Section 1 To the Installer ..........Installer Safety . - Page 4 Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal penalties. All rights reserved. Taylor Company a division of Carrier Commercial Refrigeration, Inc. 750 N. Blackhawk Blvd. Rockton, IL 61072...
-
Page 5: To The Installer
NEVER use a service of Taylor equipment. water jet or hose to rinse or clean the unit. Failure to Only authorized Taylor service personnel follow this instruction may result in electrocution. should perform installation and repairs on the equipment. -
Page 6: Electrical Connections
The installation performed by an authorized Taylor service technician. location is marked by the equipotential bonding symbol (5021 of IEC 60417-1) on both the removable To correct the rotation on a three- phase unit, panel and the equipment’s frame. -
Page 7: Refrigerant
To observe the suction pressure, attach refrigeration gauges to the suction access fitting in the dispenser. Pressures should read approximately 32 psi. (221 Taylor reminds technicians to be cautious of kPa) for non- alcoholic application and 28 psi. (193 government laws regarding refrigerant recovery, kPa) for alcoholic application. - Page 8 Units Equipped With Post Mix Valve Step 4 To adjust either the syrup or water flow rate, turn the Step 1 flow adjustment screw clockwise to increase flow, or Connect syrup and water lines. counterclockwise to decrease flow. Adjust the screws Note: Adjust the syrup supply pressure to maintain 60 until the desired brix is obtained.
-
Page 9: To The Operator
The unauthorized use of Note: Your Taylor warranty is valid only if the parts are alternate refrigerants will void your Taylor compressor authorized Taylor parts, purchased from the local warranty. -
Page 10: Safety
We at Taylor Company are concerned about the safety of the operator when he or she comes in contact with the freezer and its parts. Taylor has gone to extreme efforts to design and manufacture built- in safety DO NOT operate the freezer unless it is features to protect both you and the service technician. - Page 11 This freezer must be placed on a level surface. Failure to comply may result in personal DO NOT allow untrained personnel to injury. operate this machine. DO NOT operate the freezer unless all service panels and access doors are Cleaning and sanitizing schedules are restrained with screws.
-
Page 12: Operator Parts Identification
Section 4 Operator Parts Identification Model RD30 ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Cover- Rear 049201 Washer- Freezer Stud 049032 Cover- Hopper 049081 Panel A.- Front X49760 Retainer- Clip 049419 Support- Tray- Left 049056 Panel A.- Rear X48983 Support- Tray- Right 049057 Panel- Side- Right... - Page 13 Beater Door Assembly ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Door Assembly- Complete X48768 Arm- Torque 014500 Screw- 1/4- 20 x 9/16 Thumb 047632 O- Ring .291 ID x .080 W 018550 Knob- Draw Valve- Black Plastic 047358 Torque Assembly X49022 Plate- Draw Spout Mounting 049275...
-
Page 14: Important: To The Operator
Section 5 Important: To the Operator Figure 1 Control Switch Mix Out Light The control switch is located on the front of the A mix out indicating light is located on the front panel. machine. The center position is “OFF”. The down When the light is lit, it indicates that the hopper is position is the “WASH”... -
Page 15: Operating Procedures
Note: When lubricating parts, use an approved food Install the drive shaft into the freezing cylinder, square grade lubricant (example: Taylor Lube HP). Every end first. The drive shaft seal must fit securely over the three months discard rubber parts and install new rear shell bearing. - Page 16 Step 4 Before installing the beater assembly, check the scraper blades for any signs of wear or damage. If a scraper blade is nicked or worn, replace both blades. Check the scraper blade clips to make sure they are not bent and the slot is even for the entire length of the clip.
- Page 17 Step 7 Insert the torque rotor (guide bearing end first) into the pilot hole in the center of the drive shaft. The hole in the torque rotor shaft should be rotated to the 12 o’clock position. Figure 12 Step 11 Insert the draw valve and spring into the door spout until the threaded end of the shaft passes through the hole in the end of the door spout.
- Page 18 Step 13 Note: Do not lubricate the door bearing. Align the draw spout assembly with the door. Place the draw spout mounting plate over the draw spout Step 16 assembly and align the holes. Position the door on the freezer studs at the front of the freezing cylinder.
-
Page 19: Sanitizing
Sanitizing Step 18 Position the torque arm by inserting it through the slot Step 1 in the torque switch arm and down into the hole in the Fill System. Disconnect the product supply lines from torque rotor which protrudes from the door. Verify the mix delivery container. - Page 20 For units equipped with a post mix valve, the Note: If the sanitizing solution does not continue to following procedure is to be used in place of Step flow after releasing the prime button, press and hold 1 - 2 of the Sanitizing Procedure. the prime button for an additional ten (10) seconds.
- Page 21 Step 3 Dispenser. Prepare a pail of approved 100 PPM sanitizing solution (examples: 2- 1/2 gal. [9.5 liters] of Kay- 5R or 2 gal. [7.6 liters] of Stera- SheenR). USE WARM WATER AND FOLLOW THE MANUFACTUR- ER’S SPECIFICATIONS. Remove the upper rear cover, and open the hopper cover.
-
Page 22: Priming
Priming Step 1 With a pail beneath the door spout, open the draw valve. Press the fill switch to allow fresh product to flow into the freezing cylinder. This will force out any remaining sanitizing solution. When full strength product is flowing from the door spout, close the draw valve. -
Page 23: Rinsing
Rinsing Cleaning Step 1 Prepare a pail of approved 100 PPM cleaning solution (examples: 2- 1/2 gal. [9.5 liters] of Kay- 5R or 2 gal. Step 1 [7.6 liters] of Stera- SheenR). USE WARM WATER Remove the upper rear cover, and open the hopper FOLLOW MANUFACTURER’S cover. -
Page 24: Brush Cleaning
Brush Cleaning Note: To remove o- rings, use a single service towel to grasp the o- ring. Apply pressure in an upward direction until the o- ring pops out of its groove. With Step 1 the other hand, push the top of the o- ring forward and Prepare a sink with an approved cleaning solution in it will roll out of the groove and can be removed easily WARM... -
Page 25: Important: Operator Checklist
Read and follow label directions carefully. Too strong of a solution may damage Your local Taylor Distributor can perform this service the parts and too weak of a solution will not do for you. an adequate job of cleaning or sanitizing. -
Page 26: Troubleshooting Guide
Section 8 Troubleshooting Guide PROBLEM PROBABLE CAUSE REMEDY PAGE REF. 1. No product is being a. Product freeze- up due to a. Follow directions for mixing product carefully. dispensed with the draw improper product mixing. valve open. b. The torque arm is not b. - Page 27 6. Excessive mix leakage in a. Improper or inadequate a. Use the correct lubricant (Taylor Lube) and follow the rear drip pan. lubrication on the drive proper lubrication shaft o- ring or seal. procedures.
- Page 28 10. There is excessive a. There is improper or a. Use the correct lubricant (Taylor Lube) and follow leakage from the draw inadequate lubrication on proper lubrication spout. the draw valve o- rings. procedures.
-
Page 29: Parts Replacement Schedule
Section 9 Parts Replacement Schedule PART DESCRIPTION EVERY EVERY ANNUALLY 3 MONTHS 6 MONTHS Scraper Blade Inspect & Replace Minimum if Necessary Drive Shaft Seal Freezer Door O- Ring Door Port O- Ring Front Bearing Door Spout O- Ring Drive Shaft O- Ring Torque Arm O- Ring Brushes Inspect &... -
Page 30: Section 10 Limited Warranty On Equipment
Taylor, through an authorized Taylor distributor or service agency, will provide a new or re- manufactured part, at Taylor’s option, to replace the failed defective part at no charge for the part. Except as otherwise stated herein, these are Taylor’s exclusive obligations under this limited warranty for a Product failure. - Page 31 LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
-
Page 32: Limited Warranty On Parts
Taylor warrants the Parts against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original installation of the Part in the Taylor unit. If a Part fails due to defect during the applicable warranty period, Taylor, through an authorized Taylor distributor or service agency, will provide a new or re- manufactured Part, at Taylor’s option, to replace the failed defective Part at no... - Page 33 Parts or the units in which they are installed repaired or altered in any way so as, in the judgment of Taylor, to adversely affect performance, or normal wear or deterioration.
-
Page 34: Taylor Company
LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Part, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Part under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
