Summary of Contents for Greenwood SR100TR

  • Page 1 SR100/SR100TR/SR100HTR Installation instructions...
  • Page 2 Ø Ø = 125mm 220 mm 30 mm 8 mm 8 mm 30 mm 220 mm 8 mm 8 mm Ø X = 60mm Ø = 105mm...
  • Page 3: Installation Instructions

    until cable comes to a dead stop. sensitivity. • Peel open the terminal cover, so that terminal screws are visible, then tighten Timer: screws and replace terminal cover, making sure that cover is fully replaced. • The timer is pre-set at approximately 15 minutes. • Terminal seals must be re-fitted securely to ensure IP24 protection. • It may be adjusted by using a small screwdriver and rotating clockwise to increase time to 30 minutes (maximum) and anticlockwise to reduce time to 2 minutes (minimum). Greenwood Air Management Ltd Greenwood House, Brookside Avenue, Rustington, West Sussex, BN16 3LF, UK T: +44 (0) 1903 771021 W: www.greenwood.co.uk 05.10.906 May 2010 MCS 097...
