Summary of Contents for Bluewater Pro Series
- Page 1 Applies only to products with serial number 1845-01001 and later COM PL ET E US ER M ANUAL B LU EWAT ER P RO WAT E R P U RIF IER...
-
Page 2: Table Of Contents
CONT EN TS IN TROD U CT ION About this manual Limited warranty Environment information Disposal Symbols Safety instructions Safety information PRO D U CT OV ERVIEW Models Pro outside Pro inside and replacement components Move the water purifier SYS T E M OV ERVIEW System description Leak protection system Low pressure protection... -
Page 3: Introduct Ion
NSF/ANSI and meets the applicable published 58 and CSA Standard B483.1. It has also standard. been tested and certified against NSF/ ANSI 372. © Bluewater Group 2019... -
Page 4: Safety Instructions
Safety information Install the water purifier in accordance with local regulations. If you are not sure, contact a Bluewater dealer for aid. Bluewater has no responsibility for installation of the water purifier. Only use the cleaned water when the lights “Purification level II and/or III”... - Page 5 Only approved Bluewater staff can do servicing and repairs on the water purifier. Only use original replacement cartridges and parts from Bluewater. For the spare parts catalogue and contact information for purchases, see www.bluewatergroup.com. The water to be cleaned must obey the requirements in "Technical information"...
-
Page 6: Pro D U Ct Ov Erview 0
P RODUCT OVERVIEW Models Model Capable of handling Suitable for commercial Clean water rinse valve higher TDS, including use without an automatic suitable for environments brackish inlet water shutoff where extra high water quality is required Pro 400B-HR Pro 400C-HF ... -
Page 7: Pro Inside And Replacement Components
Flashes/On: Something is wrong, see "Troubleshooting" on page 32. button Various functions purification level I Purification level I-III indicates clean water purification level. Low level I to high level III. purification level II purification level III © Bluewater Group 2019... -
Page 8: Move The Water Purifier
>5 days, see "Put into storage" on page 27. Contact your Bluewater dealer for advice before moving the water purifier from one place to another. Figure 5. Move the water purifier... -
Page 9: Sys T E M Ov Erview 0
SYSTEM OVE RVIEW System description Figure 6. System overview, an example of Pro installation Description Description Water purifier Drain water hose, installed with an air-gap Power cord Bracket for drain water hose Feed water tube Clean water tube © Bluewater Group 2019... -
Page 10: Leak Protection System
Leak protection system A sensor at the bottom of the water purifier senses water leaks. If there is a leak, the feed water supply is stopped. The water purifier cannot be started again until the leak has been repaired. Low pressure protection If Pro stops because of low pressure, the cause of the low pressure must be removed. -
Page 11: Water Production
Flush when drawing water. After maximum operation time 15 minutes. (Pro 400B must be manually restarted) Water purifier in standby mode. Pro is connected to water and power. Flush is performed every 12 hours, regardless of when clean water was last produced. © Bluewater Group 2019... -
Page 12: In S Tallatio N
INSTAL L ATI ON Install the water purifier in accordance with local regulations. If you are not sure, contact a Bluewater dealer for aid. Bluewater has no responsibility for installation of the water purifier. Install the water purifier in a vertical position on a horizontal surface. -
Page 13: Unpack Pro
Make sure that Pro shows no signs of damage, and that no accessories are missing. Tell the Bluewater dealer about missing parts, damage and other problems. Tell the transport company immediately if Pro is damaged during transport. -
Page 14: Position Pro
Position Pro Put Pro in a vertical position on a horizontal surface below the kitchen sink. Make sure that the surface can support Pro Position Pro near the cold water supply, the drain and an earthed electrical supply. • Make sure that it is easy to see the control panel. •... -
Page 15: Install Feed Water Connection
The flushed water goes through the drain water hose to the drain water outlet. This hose can be a maximum of four meters long. The minimum internal diameter is 13 mm. Figure 14. Install drain water connection © Bluewater Group 2019... -
Page 16: Connect The Water Purifier
Connect the water purifier Do not connect the clean water hose to other drinking water equipment before Pro has been flushed. Applies to models that connects to a faucet. 19 mm 3/4” 3/4” ZH EU 60 min >3 s Figure 15. Connect the water purifier Complete User manual... -
Page 17: Do A Check For Leaks
Do a check for leaks The hose connections must be tight! Figure 16. Do a check for leaks © Bluewater Group 2019... -
Page 18: M Ai Nte Nance
Regular maintenance is important for correct function and long term operation. Only educated and approved personnel can do the maintenance. If the water quality changes greatly, contact your Bluewater dealer for advice. Do not drink the water when the water purifier flushes, or when you do maintenance with chemicals. -
Page 19: Each 4-6 Months
The descaling product is harmful. Keep it where children cannot get it. Clean your hands when you have used it. Order the descaling product from a Bluewater dealer. Frequency depends on water quality and usage! To extend the water purifier lifetime: Descale Pro with 6 month intervals or when the flow is decreased. - Page 20 45 s >3 s 10 h 1 min Complete User manual...
-
Page 21: Replace Prefilter
Replace the filters after what comes first of 4-6 months or 37 850 l (10 000 gal) of purified water. Pro 600: change both filters when filter light I or II lights up. Order filters from a Bluewater dealer. ×2 ×1... -
Page 22: Each Year
I / II I / II Pro400 Pro400 2 min Pro400 II Pro400 Pro400 Pro400 Pro600 Pro600 Figure 20. Replace prefilter Each year Test the water An approved lab must do a test of the water that is cleaned by Pro at least one time every year, if the feed water has been classed as unfit. -
Page 23: Other
The water purifier should always be flushed: • when it is installed again after storage/freeze protection • when it has been cleaned • when the membrane has been replaced. 1 min 36 min >3 s Figure 21. Flush Pro © Bluewater Group 2019... - Page 24 Clean the grid filter The grid filter in the feed water connection catches larger particles. If the flow is decreased or if Pro makes a noise, the grid filter can be blocked. 1 min Figure 22. Clean the grid filter Complete User manual...
- Page 25 Clean your hands when you have used it. Use sodium hypochlorite (NaClO) without added color or fragrance additives. Disinfect the water purifier when the water tastes or smells bad. ×1 ×1 60 min 400 ml ~25°C (77°F) 25 ml (NaClO 3.5%) >3 s © Bluewater Group 2019...
- Page 26 I / II I+II 45 s 30 min I + II I + II I + II 1 min 36 min >3 s Figure 23. Use disinfectant and flush Complete User manual...
- Page 27 Put the water purifier into storage if it will not be used for 4 months or more, or if it is to be disconnected from the water and electricity for >5 days. Order the preserving agent from a Bluewater dealer. I + II...
- Page 28 60 s -30°C (-22°F) Figure 24. Put into storage Reinstall after storage Preserving agent is harmful! Keep it where children cannot get it. Clean your hands when you have used it. I + II 48 h +5°C (40°F) I + II I + II Complete User manual...
- Page 29 19 mm 3/4” 1 min 36 min >3 s Figure 25. Reinstall after storage and flush © Bluewater Group 2019...
-
Page 30: Tec H Nical In Form At Ion
T ECHN I C AL IN FORM ATIO N Technical data Model Size W×H×D Weight Power Power supply earthed Pro 400B-HR 220-240V 225×466×460 mm 29 kg 530 W 220-240V, 50-60 Hz Pro 400C-HF Pro 400C-HR Pro 400BC-HR 120V 8.9×18.3×18.1 “ 64 lbs 6 Amp 120V, 60 Hz... -
Page 31: Requirements On Feed Water To Water Purifier
Only connect to the cold water supply. The temperature limits are in the table "Requirements on feed water to water purifier" on page 31. If the water quality changes greatly, contact your Bluewater dealer for advice. Pro 400B-HR Pro 400C-HF... -
Page 32: T Roub L Eshootin G
Connect it again to start the automatic quality has become too low. flush. Do this 2 times. The salinity of the feed water Contact your Bluewater dealer. has increased. The water quality meter does Disconnect the water purifier from power. - Page 33 There is a bad smell Microbial growth in the water See "Use disinfectant to clean the system" from the water purifier. because the water purifier has on page 25. not been used for a week or longer. © Bluewater Group 2019...
-
Page 34: Product Performance
NSF/ANSI 58 and CSA Standard B483.1. WQA certifies product performance, and reviews the manufacturing facility and procedures toassure product consistency and integrity. The Bluewater Pro water purifier has been tested according to NSF/ANSI 58 for reduction of the substances listed below: •... - Page 35 © Bluewater Group 2019...
- Page 36 Bluewater is a world leading water purification company. Headquartered in Stockholm, Sweden, the company helps people and businesses globally enjoy the health and wellbeing benefits of cleaner, healthier tap water. Bluewater innovates, makes and sells compact water purifiers that harness the company’s patented reverse...
