A
dd a warm glow to your Lionel rail-
road's city streets with these realistic illu-
minated street lamps.
Installing your street lamp using a lockon
T
o install your street lamp, begin by
attaching a lockon (available separately)
to any straight section of track. Fit the center
lip of the lockon onto the edge of an outside
rail. Press the lockon upward so that the
spring contact snaps onto the center rail. The
lockon should face outward when setting up
LIONEL
STREET LAMP
First, hook center lip
of lockon to the out-
side of the rail
Spring clips
Connecting the street lamp to a lockon
71-2874-250
The street lamps operate between 10-14
volts alternating current. They're easy to
install—just follow these simple instructions.
your track. Make sure it is firmly connected.
To connect the street lamp to the lockon,
insert a wire into each loop that emerges
when the spring tab on the lockon connector
is depressed. Release the tab, and spring
pressure will hold the wire in place. It's also
possible to solder the wires to the track.
Attaching a lockon to the track
Lockon
Rev. 6/96
Then, snap lockon's
spring contact to
the middle rail
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lionel 71-2874-250
Summary of Contents for Lionel 71-2874-250
- Page 1 Rev. 6/96 ® STREET LAMP The street lamps operate between 10-14 dd a warm glow to your Lionel rail- volts alternating current. They’re easy to road’s city streets with these realistic illu- install—just follow these simple instructions. minated street lamps.
- Page 2 Installing your street lamps using extension wires nals by wiring them in parallel across two our Lionel street lamps also may be con- extension wires. Connections may be sol- nected directly to the transformer by dered or twisted securely and then wrapped means of extension wires.
