Envitec AlcoQuant 6020 Operating Instructions Manual page 18

During sample collection the following is displayed:
ATTENTION:
The time required for the analysis depends, among other things, on the alcohol content of the sample
After the sample has been analysed, the relevant result is displayed.
If no alcohol is detected, a signal sounds off and the green LED lights up.
If alcohol is displayed then a dual signal tone sounds (failure signal) and the red LED lights up.
The result of the current breathalysation is displayed until:
• The device is switched back to being ready for measuring by pressing the "OK" key
once, or
• The device is switched off by pressing the "ON/OFF
After pressing "Print"-Button a measurement report will be printed by an attached Printer
(optional accessory).
ATTENTION:
2.5 minutes after the last operating procedure an acoustic signal is given and the device switches itself off.
AlcoQuant® 6020 – Breathalyser – Operating Instructions
18
12:34
Analysis
or
.
key (3 sec.).
