- Page 1 MSH-883, MSH-887, MSH-892, MSH-895, MSH-898 TRUE DIVERSITY WIRELESS MICROPHONE SYSTEM, 40 CHANNELS “PLL” UHF 863-865 MHz N Instruction Manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions
The wireless system receiver has 2 aerials and 1 True Diversity circuit that continually compares and selects the best signal from the aerial. CONTROLS AND FUNCTIONS INDIVIDUAL RECEIVER (models MSH-883 and MSH-887) - 4 -... - Page 5 DOUBLE RECEIVER (models MSH-892, MSH-895 and MSH-898)) 1.- STANDBY: on/off button for the receiver in standby mode. 2.- IR: infrared receiver. 3.- IR-SW: by pressing this button the receiver transmission channel is sent to the transmitter microphone. Then, place both the IR receivers opposite each other. The transmitter as well as the receiver will be tuned into the same frequency and the same channel number.
- Page 6 HAND-HELD MICROPHONE (mod. MSHT-40M) 1.- Grille: for protecting the microphone capsule and helping to reduce breathing noises and the wind. 2.- Display: this shows information on the tuned frequency,such as the channel number, battery level, RF signal level and audio signal. If the battery level is low, the display will light up red. 3.- Battery cover: unscrew this cover to get to the battery compartment.
- Page 7 BELT-PACK MICROPHONE (mod. MSHT-45P) 1.- Display:This shows information on the tuned frequency,such as the channel number, battery level, RF signal level and audio signal. If the battery level is low, the display will light up red. 2.- w/s: for selecting desired options to set the wireless belt-pack microphone. 3.- SET: This button lets you select between the following setup options: channel number and frequency, RF transmission level (high/low), battery type selection (1.2 V - rechargeable/1.5 V - alkaline) to show the battery level correctly and the microphone transmitter lock.
- Page 8 CONNECTION SITUATION Place the receiver on a horizontal surface at a distance of 1m minimum from the floor, walls or metal surfaces. Keep the equipment away from sources of electric noise, such as lighting fixtures, motors, digital equipment, etc. CONNECTION Connect the audio output to the input on a mixer or amplifier with connection best adapted to your needs: Using the balanced XLR connector or the unbalanced 6.3 mmmono jack connector.
- Page 9 INSTALLATION IN 19” RACK The individual receivers (mods. MSH-883 and MSH-887) are supplied with a short bracket for assembly in a 19” rack and a connection plate to join 2 individual receivers, so that you can combine 2 receivers to be iinstalled in a 1 U 19”...
- Page 10 INSTRUCTIONS FOR USE 1.- Install the receiver and make the connections in accordance with the CONNECTION section. 2.- After making the connections, switch on the wireless microphone. 3.- Select the receiver output volume. Do not use balanced and unbalanced outputs at the same time as it could cause signal loss and noise.
-
Page 11: Autoscan Mode
CHANNEL SELECTION MODES IN THE RECEIVER MANUAL MODE To select an interference-free channel manually, follow the steps below: Press the on/off button to switch the receiver on. Press the SET button on the receiver. Use the w/s buttons to select a channel and a certain frequency. AUTO-SCAN MODE To select an interference-free channel automatically, follow the steps below: Press the on/off switch to switch the receiver on. -
Page 12: Troubleshooting
- Check if the receiver volume is too high or too low. - Check if the interference comes from another wireless microphone system, TV, radio, etc SPECIFICATIONS MSH-883 MSH-887 CHARACTERISTICS True diversity receiver with tie-clip True diversity receiver with wireless... - Page 13 MSH-892 MSH-895 MSH-898 CHARACTERISTICS True diversity receiver True diversity receiver True diversity receiver with with 2 tie-clip with 2 wireless hand-held 1 tie-clip microphone with microphones with microphones with unidirectional electret unidirectional electret unidirectional electret condenser capsule and 1 condenser capsule and 2 condenser capsule.
-
Page 14: Channel Table
CHANNEL TABLE CHANNEL FREQUENCY CHANNEL FREQUENCY 863.000 MHz 864.000 MHz 863.050 MHz 864.050 MHz 863.100 MHz 864.100 MHz 863.150 MHz 864.150 MHz 863.200 MHz 864.200 MHz 863.250 MHz 864.250 MHz 863.300 MHz 864.300 MHz 863.350 MHz 864.350 MHz 863.400 MHz 864.400 MHz 863.450 MHz 864.450 MHz... -
Page 15: Warranty
If any service is needed during the warranty period because of lack of conformity, please contact the business or distributor where the product was purchased in no more than 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it.
