SETUP INSTRUCTIONS
2011
350 SX‑F EU
350 SX‑F USA
350 XC‑F USA
Art. no. 3211680en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 350 SX-F EU 2011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KTM 350 SX-F EU 2011

  • Page 1 SETUP INSTRUCTIONS 2011 350 SX‑F EU 350 SX‑F USA 350 XC‑F USA Art. no. 3211680en...
  • Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.
  • Page 4: Means Of Representation

    MEANS OF REPRESENTATION Symbols used The symbols used are explained in the following. Identifies an expected reaction (e.g. to a work step or a function). Identifies an unexpected reaction (e.g. to a work step or a function). Identifies a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 SET‑UP Unpacking and setting up the vehicle Packaging 2 – Remove the box and the plastic packaging. Info To avoid damaging the motorcycle during the setup, leave the protective film on the vehicle until you have finished. – Remove the separate enclosure and unpack it. Check that the scope of delivery is complete on the basis of the enclosed packing list.
  • Page 6 SET‑UP – Position FI warning lamp with holder . Mount and tighten the screw.  Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) – Plug connector into the wiring harness.  – Mount cable holder on the frame.  B00534-10 –...
  • Page 7 Apply the label included in the delivery (optional). – Refuel. ( p. 9) – Position all controls exactly on the handlebar. Tighten all screws. – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection.
  • Page 8 WORK Installing the front wheel Warning Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs. – Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary. – Check the wheel bearing for damage and wear.
  • Page 9: Mounting The Seat

    – Do not discard batteries with the household trash. Dispose of a defective battery in an environmentally compatible manner. Give the battery to your KTM dealer or to a recycling center that accepts used batteries. Warning Environmental hazard Hazardous substances cause environmental damage.
  • Page 10 WORK Info Even when there is no load on the battery, it still loses power steadily. The charge state and the type of charge are very important for the service life of the battery. Rapid recharging with a high charging current shortens the battery's service life. If the charging current, charging voltage and charging time are exceeded, electrolyte escapes through the safety valves.
  • Page 11 WORK Refueling 3.10 Danger Fire hazard Fuel is highly flammable. – Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no fuel is spilt, especially on hot vehicle components. Clean up spilt fuel immediately. –...
  • Page 12: Technical Data - Chassis Tightening Torques

    TECHNICAL DATA - CHASSIS TIGHTENING TORQUES – Spoke nipple, front wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) – Spoke nipple, rear wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) – Remaining nuts, chassis 15 Nm (11.1 lbf ft) –...
  • Page 13 SUBSTANCES Super unleaded (ROZ 95 / RON 95 / PON 91) According to – DIN EN 228 (ROZ 95 / RON 95 / PON 91)
  • Page 14: Auxiliary Substances

    AUXILIARY SUBSTANCES Long-life grease Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Bike Grease 2000...
  • Page 15 *3211680en* 3211680en KTM-Sportmotorcycle AG 5230 Mattighofen/Austria http://www.ktm.com...

This manual is also suitable for:

350 sx-f usa 2011350 xc-f usa 2011
