- Page 1 SETUP INSTRUCTIONS 2017 350 SX‑F 350 XC‑F Art. no. 3213577en...
- Page 3 KTM accepts no liability for delivery options, devi- ations from illustrations and descriptions, misprints, and other errors.
-
Page 4: Means Of Representation
MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 SETUP Unpacking and setting up the vehicle Package 2 – Remove the box and the plastic packaging. Info To avoid damaging the motorcycle during the setup, leave the protective film on the vehicle until you have finished. – Remove the separate enclosure and unpack it. Check that the scope of supply is complete on the basis of the enclosed packing list.
- Page 6 SETUP – Route the clutch line with the clutch master cylinder toward the front between the upper and lower triple clamps. K00686-01 – Position the fork legs and tighten the screws of the triple clamp. Guideline Screw, top triple clamp 17 Nm (12.5 lbf ft) Screw, bottom triple clamp...
- Page 7 SETUP – Position the handlebar clamp. – Mount screws , but do not tighten yet. – First bolt the handlebar support with screws onto the longer, higher side of the handlebar supports so that both parts touch. – Tighten screws evenly.
- Page 8 SETUP – Position spring as shown. Spring engages in area K00621-12 – Press the spring with special tool Pliers for footrest spring (79029083000) The special tool is applied to area on the footrest. – Mount pin K00622-12 – Mount the washer and split pin –...
- Page 9 SETUP – Position spring as shown. Spring engages in area K00621-12 – Press the spring with special tool Pliers for footrest spring (79029083000) The special tool is applied to area on the footrest. – Mount pin K00622-12 – Mount the washer and split pin K00623-12 Left footrest (XC‑F US) –...
- Page 10 Position all controls in their exact positions on the handlebar. Tighten all screws. Guideline Screw, fixed grip 5 Nm Loctite ® 243™ (3.7 lbf ft) – Prepare the vehicle according to the specifications in the KTM Dealer.net for han- dover to the customer.
- Page 11 WORK Raising the motorcycle with a lift stand Note Danger of damage The parked vehicle can roll away or fall over. – Park the vehicle on a firm and level surface. – Raise the motorcycle at the frame underneath the engine. Lift stand (78129955100) Neither wheel is in contact with the ground.
-
Page 12: Tighten Screws
WORK – Position the front wheel and insert the wheel spindle. The brake linings are correctly positioned. – Mount and tighten screw Guideline Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) – Operate the hand brake lever several times until the brake linings are seated cor- rectly against the brake disc. - Page 13 WORK Removing the seat – Remove screws S01230-10 – Raise the rear of the seat, pull the seat back, and lift it off. S01231-01 Mounting the seat – Mount the front of the seat on the collar bushing of the fuel tank, lower the seat at the rear, and push the seat forward.
-
Page 14: Installing The Battery
WORK Installing the battery Main work – Insert the battery into the battery compartment with the terminals facing forward and secure with holding bracket (All SX‑F models) Battery (C22S) (XC‑F US) Battery (HJTZ5S-FP) – Mount and tighten screw Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) –... - Page 15 WORK Info Even when there is no load on the battery, it discharges steadily. The charging level and the method of charging are very important for the service life of the battery. Rapid recharging with a high charging current shortens the service life of the battery. If the charging current, charging voltage, and charging time are exceeded, the battery will be destroyed.
- Page 16 WORK Warning Environmental hazard Improper handling of fuel is a danger to the environment. – Do not allow fuel to enter the groundwater, the soil, or the sewage system. (All SX‑F models) – Turn filler cap counterclockwise and lift it off. S01197-10 (XC‑F US) –...
- Page 17 WORK Warning Danger of poisoning Fuel is poisonous and a health hazard. – Avoid skin, eye and clothing contact with fuel. – Immediately consult a doctor if you swallow fuel. – Do not inhale fuel vapors. – In case of skin contact, rinse the affected area with plenty of water. –...
-
Page 18: Technical Data
TECHNICAL DATA Chassis tightening torques – EJOT PT ® Screw, air filter box cover K60x20-Z 3 Nm (2.2 lbf ft) – Screw, combination switch EJOT PT ® K50x18 3 Nm (2.2 lbf ft) – Screw, intake air temperature sensor EJOT DELTA PT ®... - Page 19 TECHNICAL DATA – Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft) Loctite ® 243™ – Nut, rear wheel spindle M25x1.5 80 Nm (59 lbf ft)
- Page 20 SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
-
Page 21: Auxiliary Substances
AUXILIARY SUBSTANCES Long-life grease Recommended supplier Motorex ® – Bike Grease 2000... - Page 22 *3213577en* 3213577en 10/2016 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...
