- Page 1 Bicycle Computer CY-528H Manual...
-
Page 2: Table Of Contents
Contents 1. Item List 6.1.5. Heart Rate Over Time 2. Operation 6.1.6. Heart Rate HR TM 2.1. Attaching bracket on the handle bar 6.1.7. Heart Rate Below Time 2.2. Attaching speed sensor/magnet on bicycle 6.2. Mode Key Functions 2.3. Wearing the chest belt for heart rate function 6.2.1. STOPWATCH 3. Nomendature 6.2.2. TIMER COUNT UP/TIMER COUNT DOWN 4. Main Screen Display 6.2.3. TRIP TIME 5. Basic Setting 6.2.4. AVERAGE SPEED 5.1. Setting Key Functions 6.2.5. MAXIMUM SPEED 5.1.1. KM/H or ML/H 6.2.6. TIME BIKE 1 5.1.2. TIMER COUNT UP or TIMER COUNT DOWN 6.2.7. TIME BIKE 2 5.1.3. TRIP COUNT UP or TRIP COUNT DOWN... -
Page 3: Item List
Bicycle Computer Chapter 2 Chapter 1 Operation Item list 2.1 attaching bracket on the handle bar Please check that all the following items have been included with your cycle computer before starting. Bracket Nylon ties CY-500 series cycle computer Battery Cover Stabling Pads Cadence & Magnet Speed Sensor... -
Page 4: Attaching Speed Sensor/Magnet On Bicycle
Bicycle Computer 2.2 Attaching speed sensor/magnet on bicycle 2.3 Wearing the chest belt for heart rate function The transmitter should be positioned right below the breasts/ pectoral muscles. The strap should be comfortable, but secure. Note: Transmitter will automatically get into “wake up” mode after the user wear it. Please check for green light on the Speed sensor to make sure 2 devices operated normally when riding your bicycle for the first time. Note: Please rotate the wheel to check the the sensor and magnet installation, initial flashing green light indicates the sensor detected magnet signals normally. -
Page 5: Main Screen Display
Bicycle Computer Chapter 3 Chapter 4 Nomenclatur Main Screen Display... -
Page 6: Basic Setting
Bicycle Computer Chapter 5 Basic Setting Prior to the uses of this device, it is important to pre-set the basic settings in order to gain accurate and useful information. 5.1 Setting Key Functions 5.1.1 KM/H or ML/H The user can select the unit for speed which will Press M key to get into clock/speed mode. be displayed on the screen. Under any clock/speed functions, press S key for 3 seconds. • Under KM/H or ML/H, press C key or H key to switch. Screen Display Changes • Press M key to go to the next setting. 5.1.1 5.1.2 5.1.3... -
Page 7: Trip Count Up Or Trip Count Down
Bicycle Computer 5.1.3 TRIP COUNT UP or TRIP COUNT DOWN 5.1.5 BIKE 1 or BIKE 2 The user can select TRIP COUNT UP or TRIP CY-528H has two bike settings, it allows COUNT DOWN in the setting mode. the user to set two different bike wheel After selects the function, it (TRIP UP / TRIP sizes. DOWN) will display. Under BIKE 1 or BIKE 2 • Under TRIP COUNT UP or TRIP COUNT DOWN, • Press H key or C key to adjust number press C key or H key to switch. -
Page 8: Temperature
Bicycle Computer 5.1.7 TEMPERATURE 5.1.10 Set Weight The user can select temperature unit (°C or °F) that will be Under Set Weight • Press H or C key to adjust number. display on the screen. • Press M to go to the next setting. Under Temperature • Press A key or C key to adjust number. • Press M to transfer next setting! 5.1.8 Set Sex 5.1.11 LANGUAGE... -
Page 9: Hr Target Zone Setting Mode
Bicycle Computer 5.2 HR Target Zone Setting Mode 5.2.1 SET Target zone will vary for each • Press H key to access heart rate function mode. individual user depending on age, • Under any heart rate function, press S key for 3 seconds. personal fitness goals, existing health considerations (high blood pressure, circulation or respiration), medications and doctor’s recommendations. Training Areas: 50% - 60% Maintain Fitness Under the SET 60% - 70% Endurance... -
Page 10: Basic Function Indication
Bicycle Computer Chapter 6 Basic Functions Indication CY-528H is equipped with several different features that include independent functions and mode for cycling. Before starting to use the device, it is suggested and would be much more user friendly once the user has a thorough understanding of the functions. 6.1 Heart Rate Functions 6.1.1 AVERAGE PULSE 6.1.2 MAXIMUM PULSE Displays the average measured pulse. Displays the maximum measured pulse. Press H key to go to heart rate functions. SCREEN DISPLAY CHANGES 6.1.3 MAXIMUM PULSE % 6.1.4 Displays the maximum measured Displays time spent for heart rate. pulse in %. Heart rate time will be recorded after wearing chest belt and starts to ride bicycle. -
Page 11: Mode Key Functions
Bicycle Computer 6.1.5 OVER TIME 6.1.6 HR TM 6.2 Mode Key Function Displays amount of time that is over Displays amount of time spent within Press H key to go to heart rate functions. the user’s target zone. the user’s target zone. SCREEN DISPLAY CHANGES 6.1.7 BELOW TIME Displays amount of time that is below the user’s target zone. -
Page 12: Stopwatch
Bicycle Computer 6.2.1 STOP WATCH 6.2.3 TRIP TIME 6.2.4 AVERAGE SPEED Displays the user’s trip time from the Displays the user’s average speed from The user can press C key to start or stop stopwatch, beginning to the current point. the beginning to the current point. To clear the time by holding C key for 5 seconds. 6.2.2 TIMER COUNT UP/TIMER COUNT DOWN Timer count up: The timer will increase once the user starts to ride bicycle. Timer count down: The timer will decrease towards zero once the user starts to ride bicycle. The user can set up the count down time in the setting mode. 6.2.5 MAXIMUM SPEED 6.2.6 TIME BIKE 1 Displays the user’s maximum speed Displays the total riding time for Bike. -
Page 13: Total Time
Bicycle Computer 6.2.10 TRIP DISTANCE 6.2.7 TIME BIKE 2 6.2.8 TOTAL TIME Displays the user’s trip distance from the beginning to the current point. Displays the total riding time for Bike2 Displays the total riding time ( Bike 1+ Bike 2) 6.2.11 ODO BIKE 1 6.2.9 TRIP COUNT UP/TRIP COUNT DOWN Displays the odometer under first wheel size. Trip count up: The distance will increase once the user starts to ride bicycle. Trip count down: The distance will decrease once the user starts to ride bicycle. The user can set up the count down distance in the setting mode. 6.2.12 ODO BIKE 2 Displays the odometer under second wheel size. -
Page 14: Total Odo
Bicycle Computer 6.2.13 TOTAL ODO 6.3 Clear Functions Displays the total odometer of bike1 + bike 2 Pressing C key (clear button) to clear all the numbers to zero. Clear the measured value for TIMER COUNT UP/DOWN function Under TIMER COUNT UP press C key for 3 seconds will return to zero. TIMER COUNT DOWN press C key for 3 seconds will return to default. NOTE: The ODO number can only be cleared by replacing battery. 6.2.14 KCAL Clear the measured value for TRIP COUNT UP/DOWN function Under TRIP COUNT UP press C key for 3 seconds will return to zero. -
Page 15: Low Battery Indication
Bicycle Computer Chapter 7 Low Battery Indication In CY-528, a sign of low power under any mode will show to indicate low battery. Clear the measured value for speed function Under TRIP TIME, press C key for 3 seconds. Low power for speed sensor if this symbol appears TRIP TIME, AVG. SPEED, MAX. SPEED, TRIP DIST, AVG. PULSE, MAX. PULSE, MAX PULSE %, PULSE TM, Target Zone (ABOVE, IN ZONE, BELOW) will return to zero. Low power for chest belt if this symbol appears Low power for computer if this symbol appears Chapter 8 Battery Replacement Clear the measured value for Pulse functions CY-500 series computer: Under HR TM, press C key for 3 seconds. Unscrew the back cover. The (+) side should be facing up. Gently remove the AVG. PULSE, MAX. PULSE, MAX. PULSE %, HR TM, Target Zone (ABOVE, IN battery and replace it with a new battery model CR2032. ZONE, BELOW) will return to zero! Sensor: Unscrew the back cover. The (+) side should be facing up. Gently remove the... -
Page 16: Troubleshooting
Bicycle Computer Chapter 9 Chapter 11 Troubleshooting Specifications Q1. Display is black or very light: Speed Censor / Transmitter & The battery power may be low. Try a new battery to make sure the battery is Receiver Cadence Belt installed correctly. Operating 0 ºC~ 40 ºC 0 ºC~ 40 ºC 0 ºC~ 40 ºC Q2. Display becomes dark or black: Temperature The unit is too hot. Place the unit in a shaded area, and it will return to normal. -
Page 17: Limited Warrenty
Bicycle Computer Chapter 11 Chapter 12 Limited Warranty Important Health Notice This product is for three years limited warranty commencing Please read over the following information before using the Cycle on the date of purchase. The product will be free from defects Computer. -
Page 18: Wheel Size Chart
Bicycle Computer Chapter 13 Wheel Size Chart Tire Scale L (mm) Tire Scale L (mm) Tire Scale L (mm) 14 x 1.50 1020 26 x 1(65) 1952 650 x 35A 2090 14 x 1.75 1055 26 x 1.25 1953 650 X 38A 2125 16 x 1.50 1185 26 x 1-1/8 1970 650 X 38B 2105 16 x 1.75 1195 26 x 1-3/8 2068 700 X 18C 2070 18 x 1.50 1340 26 x 1-1/2 2100 700 X 19C 2080...
