  • Page 1 Technical Documentation AF 50 80 100...

  • Page 3: Table Of Contents

    Exterior Venetian Blind 50/80/100 Table of Contents Types: AF 50, AF 80, AF 100 AF 50 ............................Pages 1-4 AF 80 ............................Pages 5-12 AF 100 ............................Pages 13-20 General: Top Rails ........................Page 21 General: Slat Joints ......................Page 22 General: Brackets ........................

  • Page 5: Af 50

    Gear Blind OS 58/56 Crank Handle Operated Exterior Venetian Blind - 50 mm Type: AF 50 K Field of Application and Exterior venetian blind with low-noise wind pro- tection device, suitable for large door and window openings up to a surface area of 20 m².
  • Page 6 Gear Blind OS 58/56 Electrically Operated Exterior Venetian Blind - 50 mm Type: AF 50- M Field of Application and Convenient exterior venetian blind with low- noise wind protection device, also suitable for large door and window openings up to a surface area of 20 m².
  • Page 7 Gear Blind OS 58/56 Tender Specifi cation and Limit Sizes Type: AF 50 Top Rail Ladder Cord U-shaped moulded cold roll profi le, galvanised and borde- High-strength shrink-resistant terylene-polyester. red on both edges; dimensions 58 x 56 mm. (Cutting edges For a surcharge with transverse tensioning, joined to every without surface treatment.) slat non-positively (double Omega-punching), if requested.
  • Page 8 Gear Blind OS 58/56 Installation Location and Dimensioning Instructions Type: AF 50 References Quantity Blind type Colour of the slats, inside fi ttings, any special colours Complete width = minimum clear width of 3 measuring points minus 20-30 mm Complete height = minimum clear height minus 20-30 mm Specify operating...

  • Page 9: Af 80

    Gear Blind OS 58/56 Crank Handle Operated Exterior Venetian Blind - 80 mm Type: AF 80 K Field of Application and Exterior venetian blind with low-noise wind pro- tection device, suitable for large door and window openings up to a surface area of 20 m².
  • Page 10 Gear Blind OS 58/56 Electrically Operated Exterior Venetian Blind - 80 mm Type: AF 80- M Field of Application and Convenient exterior venetian blind with low- noise wind protection device, also suitable for large door and window openings up to a surface area of 20 m².
  • Page 11 Gear Blind OS 58/56 Tender Specifi cation Type: AF 80 Top Rail powder-coated die-cast aluminium distance bracket and die- cast zinc Collinox-coated clamping lock. U-shaped moulded cold roll profi le, galvanised and bordered on both edges; dimensions 58 x 56 mm. For a surcharge, top rail with extruded aluminium, dimensions 59 x 59.5 mm, if requested.
  • Page 12 Gear Blind OS 58/56 Limit Sizes Type: AF 80 Standard Heights of Packages Heights of Packages with Clip in each Slat Heights of Packages with Guide Pin in every 4 Slat Subject to technical modifi cations - Date 06/2006...
  • Page 13 Gear Blind OS 58/56 Installation Location and Dimensioning Instructions Type: AF 80 References Quantity Blind type Colour of the slats, inside fi ttings, any special colours Complete width = minimum clear width of 3 measuring points minus 20-30 mm Complete height = minimum clear height minus 20 - 30 mm Specify operating...
  • Page 14 Gear Blind OS 58/56 Exterior Venetian Blind 80 mm with Side Guide Rail Type: AF 80 with side guide rail Field of Application and Exterior venetian blind with side guide rail, also suitable for large door and window openings up to a surface area of 20 m².
  • Page 15 Gear Blind OS 58/56 Installation Location and Dimensioning Instructions Type: AF 80 with side guide rail References Quantity Blind type Colour of slats, inside fi ttings, any special colours Complete width = minimum clear width of 3 measuring points minus approx. 3 mm Complete height = minimum clear height minus 5 mm...
  • Page 16 Gear Blind OS 58/56 Subject to technical modifi cations - Date 06/2006...

  • Page 17: Af 100

    Gear Blind OS 58/56 Crank Handle Operated Exterior Venetian Blind - 100 mm Type: AF 100 K Field of Application and Exterior venetian blind with low-noise wind pro- tection device, suitable for large door and window openings up to a surface area of 20 m².
  • Page 18 Gear Blind OS 58/56 Motor Operated Exterior Venetian Blind - 100 mm Type: AF 100- M Field of Application and Convenient exterior venetian blind with low- noise wind protection device, also suitable for large door and window openings up to a surface area of 20 m².
  • Page 19 Gear Blind OS 58/56 Tender Specifi cation Type: AF 100 Top Rail Side Guide Rails U-shaped moulded cold roll profi le, galvanised and bordered Extruded aluminium profi le with anti-noise plastic insert. on both edges; dimensions 58 x 56 mm. For a surcharge, top Dimensions: 20/27, 27/27, 30/80, 30/17, 18/20.
  • Page 20 Gear Blind OS 58/56 Limit Sizes Type: AF 100 Standard Heights of Packages Heights of Packages with Clip in each Slat Heights of Packages with Guide Pin in every 4 Slat Subject to technical modifi cations - Date 06/2006...
  • Page 21 Gear Blind OS 58/56 Installation Location and Dimensioning Instructions Type: AF 100 References Quantity Blind type Colour of slats, inside fi ttings, any special colours Complete width = minimum clear width of 3 measuring points minus 20-30 mm Complete height = minimum clear height minus 20 - 30 mm Specify operating...
  • Page 22 Gear Blind OS 58/56 Exterior Venetian Blind 100 mm with Side Guide Rail Type: AF 100 with side guide rail Field of Application and Exterior venetian blind with side guide rail, also suitable for large door and window openings up to a surface area of 20 m².
  • Page 23 Gear Blind OS 58/56 Installation Location and Dimensioning Instructions Type: AF 100 with side guide rail References Quantity Blind type Colour of slates, fi ttings, any special colours Complete width = minimum clear width of 3 measuring points minus ca. 3 mm Complete height = minimum clear height minus 5 mm...
  • Page 24 Gear Blind OS 58/56 Subject to technical modifi cations - Date 06/2006...

  • Page 25: General: Top Rails

    Gear Blind OS 58/56 General: Top Rails Types: AF 50, AF 80, AF 100 Top Rail Galvanised sheet steel roll form. Dimensions 58 x 56 mm. Installation with closed side facing upwards. (Special colour not pos- sible) Top Rail (Surcharge) Made of extruded alumi- nium.

  • Page 26: General: Slat Joints

    Gear Blind OS 58/56 General: Slat Joints Types: AF 50, AF 80, AF 100 The slats are kept evenly apart using a ladder cord. With blind types AF 80 and AF 100, every 4 slat is equipped with plastic slat clips, thereby pre- venting the lifting tape from getting too worn and the ladder cord from...

  • Page 27: General: Brackets

    Gear Blind OS 58/56 General: Brackets Types: AF 50, AF 80, AF 100 Complete Width No. of Brackets up to 2000mm Vertical Bracket Made of galvanised steel. long hole Dimensions 69 x 97 mm. Article no.: JA170503 Horizontal Bracket (Com- bined Bracket) Standard In 2 parts, made of galva- nised steel.
  • Page 28 Gear Blind OS 58/56 General: Brackets Types: AF 50, AF 80, AF 100 Horizontal Bracket (Combined Bracket) In 2 parts, galvanised steel. Dimensions angle 160 x 105 x 88 mm. Dimensions vertical bra- cket 69 x 97 mm. Article no.: JA1705W6 Combined Box Bracket with Support Height at 160 mm, Thickness of...
  • Page 29 Gear Blind OS 58/56 General: Brackets Types: AF 50, AF 80, AF 100 Horizontal Bracket (Com- bined Bracket) In 2 parts, galvanised steel. Dimensions angle 160 x 105 x 88 mm. Dimensions vertical bra- cket 69 x 97 mm. Article no.: JA1705W Combined Box Bracket to be installed below the upgraded Insulation...

  • Page 30: General: Types Of Installation

    Gear Blind OS 58/56 General: Types of Installation Types: AF 50, AF 80, AF 100 Subject to technical modifi cations - Date 06/2006...

  • Page 31: General: Tensioning Wires

    Gear Blind OS 58/56 General: Tensioning Wires Types: AF 50, AF 80, AF 100 Dimension from the outer edge of the tensioning bracket to the middle of the tensioning wire: AF 50 = 56 mm, AF 80 = 86 mm. Subject to technical modifi...
  • Page 32 Gear Blind OS 58/56 General: Tensioning Wires Types: AF 50, AF 80, AF 100 Dimension from the outer edge of the tensioning bracket to the middle of the tensioning wire: AF 50 = 56 mm, AF 80 = 86 mm, AF 100 = 66 mm Tensioning Wire Alternatives: “Stable”...

  • Page 33: General: Tensioning Springs

    Gear Blind OS 58/56 General: Tensioning Springs Types: AF 50, AF 80, AF 100 Top Profi le Bracket with Double Wire Bracket (standard) Galvanized steel, with 2 springs to counter-balance the high pulling forces. Note: only possible with top rail SGP and instal- lation with the open side pointing downwards! Top Rail Open Underneath...

  • Page 34: General: Side Guide Rails

    Gear Blind OS 58/56 General: Side Guide Rails Types: AF 80, AF 100 Single Guide Rail 20/27 und 27/27 Installation using distance brackets on the window frame or the facade. Standard length of the side guide rail = complete height minus 70 mm Double Guide Rail 27/27 Installation using distance brackets on the window...
  • Page 35 Gear Blind OS 58/56 General: Side Guide Rails Types: AF 80, AF 100 Lateral Side Guide Rail18/20 Lateral installation into the wall clearance. Standard side guide rail length = complete height minus 70 mm Lateral Side Guide Rail 18/20 Lateral installation into a notch provided by the customer.
  • Page 36 Gear Blind OS 58/56 Square Side Guide Rails for SB 140 and RB 140 Types: AF 80, AF 100 Single Guide Rail 20/27 und 27/27 Installation using distance brackets on the window frame or the facade. Standard length of the side guide rail = complete height minus 70 mm Double Guide Rail 27/27...
  • Page 37 Gear Blind OS 58/56 Round Side Guide Rails for SB 140 and RB 140 Types: AF 80, AF 100 Round Single Guide Rail, Dimension ø 45 Installation using distance brackets on the window frame or the facade. Round Double Guide Rail, Dimension ø...

  • Page 38: General: Light Control Function

    Gear Blind OS 58/56 General: Light Control Function Types: AF 50, AF 80, AF 100 The blind with light con- trol function is characte- rised by three essential criteria: Blind generally with bearing with working position (Variotec) Lower half of the blind with perforated slats, if requested Various possibilities...

  • Page 39: General: Daylight Transport Function

    Gear Blind OS 58/56 General: Daylight Transport Function Types: AF 50, AF 80 The blind with daylight transport function is cha- racterized by various slat positioning possibilities: The blind is raised in the closed position. The upper part of the blind can be opened to a maximum of 90°...

  • Page 40: General: Tiltings

    Gear Blind OS 58/56 General: Tiltings Types: AF 50, AF 80, AF 100 Tilting Both Ways (Standard) When lowering the blind, it is closed towards the exterior, and when raising, towards the interior. In between it can be smooth- ly adjusted. Working Position (Variotec) When lowering, the blind...

  • Page 41: General: Horiso

    Gear Blind OS 58/56 General: Horiso Types: AF 50, AF 80, AF 100 Top Rail (Standard) Made of extruded alu- minim. Dimensions 59 x 59.5mm. Installation with closed side facing upward. Tilting Device Precision ball bearing, dustproof for 6 mm lifting tape for AF 50 and for 10 mm lifting tape for AF 80 and AF 100.
  • Page 42 Gear Blind OS 58/56 General: Horiso Types: AF 50, AF 80, AF 100 Standard Heights of Packages Standard Heights of Packages Heights of Packages with Clip in each Slat Heights of Packages with Guide Pin in every 4 Slat Subject to technical modifi cations - Date 06/2006...
  • Page 43 Gear Blind OS 58/56 General: Horiso Types: AF 50, AF 80, AF 100 Standard Heights of Packages Heights of Packages with Clip in each Slat Heights of Packages with Guide Pin in every 4 Slat Subject to technical modifi cations - Date 06/2006...

  • Page 44: General: Horiso S

    Gear Blind OS 58/56 General: Horiso S Types: AF 80, AF 100 Top Rail (Standard) Made of extruded alumini- um. Dimensions 80 x 75 mm. Installation with closed side facing upward. Tilting Device Precision ball bearing, dustproof for 10 mm lifting tape for AF 80 and AF 100.
  • Page 45 Gear Blind OS 58/56 General: Horiso S Types: AF 80, AF 100 Standard Heights of Packages Heights of Packages with Clip in each Slat Heights of Packages with Guide Pin in every 4 Slat Subject to technical modifi cations - Date 06/2006...
  • Page 46 Gear Blind OS 58/56 General: Horiso S Types: AF 80, AF 100 Standard Heights of Packages Heights of Packages with Clip in each Slat Heights of Packages with Guide Pin in every 4 Slat Subject to technical modifi cations - Date 06/2006...

  • Page 47: General: Linking Options

    Gear Blind OS 58/56 General: Linking Options Types: AF 50, AF 80, AF 100 Close Linking with divided top rail and linking distance of 15 mm to 50 mm Close Linking at passage through exi- sting components with divided top rail. Mention linking distance on order form.

  • Page 48: General: Crank Handle Operation

    Gear Blind OS 58/56 General: Crank Handle Operation Types: AF 50, AF 80, AF 100 Subject to technical modifi cations - Date 06/2006...
  • Page 49 Gear Blind OS 58/56 General: Crank Handle Operation Types: AF 50, AF 80, AF 100 Subject to technical modifi cations - Date 06/2006...

  • Page 50: General: Motorized Drive

    500 ms. Usually only 30 – 80 ms are provided for. If incorrectly set up, the limit switches of the electric drives can fail (fuse). The Hella company declines guarantee in such a case. Subject to technical modifi cations - Date 06/2006...
  • Page 51 Gear Blind OS 58/56 General: Motorized Drive Types: AF 50, AF 80, AF 100 Wiring Diagram for Indi- Switches or Circuits that vidual Control Individual Enable Up and Down Network Right Drive 1 Pole Commands Simulta- neously The drives must be wired Drive Junction box as suggested by the...
  • Page 52 Gear Blind OS 58/56 General: Motorized Drive Types: AF 50, AF 80, AF 100 Individual Operation Control of 1 drive using a switch (Inis Uno VB). Note: maximum 1 drive per switch Individual Operation with Dual Switch Control of 2 drives using a dual switch (Inis Uno VB) Group Operation Simultaneous control of...
  • Page 53 Gear Blind OS 58/56 General: Motorized Drive Types: AF 50, AF 80, AF 100 Individual Remote Control Controlling a drive with an additional Orienta Recei- ver RTS radio receiver that is built into the top rail. As a transmitter, either a Telis 1 RTS (1-channel ra- dio hand-held transmitter) can be used, or a Centralis...

  • Page 54: General: Colour Defi Nition

    Gear Blind OS 58/56 General: Colour Defi nition Types: AF 50, AF 80, AF 100 Available Colours: Slats 50/80/100mm According to current range Slats 50/80/100mm perforated Standard in white and silver Colours according to current range for a surcharge Top rail (roll form) Galvanised Top rail (extruded) Standard in shiny aluminium...
