Hella Front-mounted box nova - VN Installation Instructions And Instructions For Use

Installation Instructions and Instructions for Use
These instructions must be read
before installation
Model front-mounted box nova - VN
Operating guidelines
Installation instructions
Installation Instructions and Instructions for Use
Preliminary remarks HELLA
Model front-mounted box nova - VN
With this HELLA product you have opted for a high-quality product with a most up-to-date
technology that can nevertheless be easily installed and operated. In these instructions we
describe the basic installation, commissioning and use.
For authorized specialist staff
For the consumer (user)
Please refer to the enclosed installation instruction and instructions for use for outdoor
blinds / venetian blinds for additional information and notes regarding HELLA outdoor
blinds / venetian blinds.
The following symbols will assist you with the installation or use and require a safety-
conscious conduct:
Attention!
This symbol indicates instructions that, if disregarded, can put the user in
danger.
Attention!
This symbol indicates instructions that, if disregarded, can potentially
result in damage to the product.
This symbol indicates instructions for use or helpful information.
This symbol requires you to act.
Attention!
This symbol indicates a risk of injury or danger to life due to an electric
shock.
This symbol indicates parts of the product, for which you will find im-
portant information in these installation instructions.
This symbol indicates the
cleaning of the product.
Subject to technical modifications. - Date of Issue Februa-
and use!
This symbol indicates the
maintenance and repair of
the product.
ry/2016
Installation Instructions and Instructions for Use

Table of Contents

Preliminary remarks HELLA Model front-mounted box nova - VN ....................................... 1
General notes ....................................................................................................................... 2
CE identification ................................................................................................................... 3
Safety instructions ................................................................................................................ 4
Before installation ................................................................................................................. 5
Overview: Tools for the installation ....................................................................................... 6
Overview: Model nova front-mounted box - VN .................................................................. 7
Type overview ...................................................................................................................... 8
Installation in general.......................................................................................................... 10
Installation of the guide rail insert ....................................................................................... 11
Installation insect screen rail for integrated moscita insect roller screen ............................ 12
Commissioning / functional check ...................................................................................... 13
Motor drive ......................................................................................................................... 14
Removal ............................................................................................................................. 14
Handing over report (for the fitter) ...................................................................................... 15
Handing over report (for the user) ...................................................................................... 16
Installation Instructions and Instructions for Use
General notes
Questions
In case of questions concerning the installation or the use of your product, please consult
your authorized specialist shop.
Spare parts / repairs
Spare parts are available at your HELLA specialist shop. Only spare parts that are ap-
proved by HELLA are allowed to be used.
Liability
In case of non-observance of the directions and information given in these instructions and
in case of improper operation or unintended use, the manufacturer shall not accept any
warranty claims concerning any damage to the product. In these cases the liability for
consequential damage to any parts or persons is ruled out as well.
Legal notes
The graphs and texts of these instructions were carefully prepared. We cannot be held
liable for any errors and their potential consequences! Subject to technical modifications to
the product and to these instructions! These instructions include copyrighted information.
All rights reserved! The listed product or brand names are trademarks of the respective
owners.
1 2 Subject to technical modifications. - Date of Issue Februa-
ry/2016
