- Page 1 08/2009 Mod:MCV/12C Production code: DELTA 12...
-
Page 2: Table Of Contents
Z15.027 Dear customer, we congratulate you for choosing a high quality product which will surely satisfy your expectations. With our thanks for choosing us, we kindly invite you to examine the present operating instructions manual before operating your new machine. SUMMARY IMPORTANT SAFETY SUGGESTIONS AND Setting of air-inlet valve ........ -
Page 3: Important Safety Suggestions And Precautions
English Automatic cream-whipper Z15.027 V01 MPORTANT SAFETY SUGGESTIONS AND PRECAUTIONS LEASE READ THESE INSTRUCTIONS BEFORE ATTEMPTING TO INSTALL AND OPERATE YOUR MACHINE HIS MANUAL PROVIDES ALL INFORMATION REQUIRED TO INSTALL OPERATE AND MAINTAIN MACHINE UNDER SAFE CONDITIONS AILURE TO COMPLY WITH THE SAFETY MEASURES SET OUT IN THIS HANDBOOK MAY RESULT IN SERIOUS DAMAGE TO THE MACHINE AS WELL AS FOR FEIT ANY MANUFACTURER S GUARANTEE... -
Page 4: Technical Data
English Operating instructions Z15.027 ECHNICAL DATA Technical data plate and CE marking The technical data plate and CE marking must not be removed. It is located on the back part of the machine and identifies: — the name and address of the manufacturer [F]; —... -
Page 5: Installation
English Automatic cream-whipper Z15.027 V01 NSTALLATION HE INSTALLATION MUST BE MADE IN COMPLIANCE WITH THE LAWS IN FORCE ALWAYS FOLLOWING INSTRUCTIONS OF THE MANUFACTURER Placing Place the machine on a flat and steady surface. Install the machine away from any source of heat, avoiding direct exposure to sun radiation and making sure that air can freely circulate around each side of the ma- chine itself. -
Page 6: Electrical Connection
English Operating instructions Z15.027 — install drip tray [8] in the appropriate slot in the front panel; — In models equipped with pedal dispensing control, connect the pedal’s plug in the relevant socket, marked by the appropriate symbol. It is possible to use the dispensing push-button also when the pedal is connected. Electrical connection HE ELECTRICAL SAFETY OF THIS MACHINE IS REACHED ONLY WHEN THE SAME IS CORRECTLY CONNECTED... -
Page 7: Controls And Indicators
English Automatic cream-whipper Z15.027 V01 Controls and indicators ON-OFF Pushbutton POWER Indicator — By pressing it, the machine is activated: the refrigerator is activated and the supply pump is ready to be activated. The Display shows the preservation temperature inside the refrigeration tank. Do not operate ON-OFF Pushbutton repeatedly. -
Page 8: Setting Of Air-Inlet Valve
English Operating instructions Z15.027 Before starting the production of whipped cream, wash, rinse and sanitize the machine with the appropriate deter- gents (see Section 6). Note: Lean cream will not whip, while fat cream tends to make into butter. The more the cream is sugared, the less it whips. Avoid adding any sugar for more than 5%. We recommend using liquid sugar. -
Page 9: Using The Timer Function
English Automatic cream-whipper Z15.027 V01 Using the TIMER function With TIMER, whipped-cream portions can be measured and dispensed by electroni- cally timing the pump’s operation. — Press TIMER and check that indicator light is blinking. The Display will show dispensing time. —... -
Page 10: Washing And Sanitising
English Operating instructions Z15.027 Filling extension To use the filling extension it is sufficient to: — unscrew the nozzle from the faucet’s cream dispenser [10]; — screw the extension’s rubber holder [33] on the cream dispenser [10]; — screw the nozzle [7] on the cream dispenser [34] placed at the extremity of the handle [35]. Note: It is possible to set the steel nozzle ([42] - optional) or the steel cream injector [41] on the filling exten- sion. -
Page 11: Washing Procedure
English Automatic cream-whipper Z15.027 V01 Washing procedure Washing parts which are in contact with cream (suction pipe, pump, labyrinth / labyrinth-tube and faucet): • remove any left-over cream and store it in a refrigerator; • dilute detergent with approximately 1 litre of warm water and pour in the container; •... -
Page 12: Accurate Washing Of The Accessories
English Operating instructions Z15.027 For a deep cleaning, we suggest to disassemble the pump’s lid operating as follows: • unscrew the non-return valve’s knob [24] from the pump [3] and extract the sphere [25] making sure not to lose it; •... -
Page 13: Maintenance
English Automatic cream-whipper Z15.027 V01 — unscrew the cream dispenser [34] from its handle [35]; — wash the dispenser’s holes and the inside of the handle with a proper brush; — wash all parts with hot water and detergent solution until all residual cream is removed checking that the inside of the tube is clean;... -
Page 14: Warnings For The Service Engineer
English Operating instructions Z15.027 Warnings for the service engineer LL OPERATIONS ON CIRCUITS OR ON INTERNAL COMPONENTS OF THE MACHINE FOR WHICH IT IS NECESSARY TO TAKE AWAY THE LATERAL PROTECTIVE PANELS MUST BE MADE WHILE THE MACHINE ITSELF IS SHUT DOWN AND ONLY AFTER UNPLUGGING IT EFORE TURNING ON THE MACHINE ALL LIMBS AND ANY OTHER... - Page 15 English Automatic cream-whipper Z15.027 V01 The cream is not suitable with the labyrinth. Call the Assistance Service. Cause: Preservation temperature is too high. Call Assistance Service to adjust it. Cause: The refrigerating plant is damaged. Call the Assistance Service. Cream comes out liquid from the outlet nozzle. Cause:The air-inlet valve is obstructed.
- Page 16 English Operating instructions Z15.027 Cause: Preservation temperature is too high. Call Assistance Service to adjust it. Cause: The condenser is dirty. Call the Assistance Service. Cause: The refrigerating system is damaged. Call the Assistance Service. Dispensing does not activate or abruptly interrupts (the pump motor seems stopped) without switching off the electrical protections or blowing the fuses.
