REV.13
OPERATING INSTRUCTIONS
AQUAJOY PREMIER PLUS
AND
AQUAJOY JUNIOR PLUS
First point of contact is always as follows unless supplied by a
Local Authority or Dealer.
AQUAJOY by DRIVE
CONSETT BUSINESS PARK
CONSETT
COUNTY DURHAM
DH8 6BN
TEL: (0044) 01207 501555
FAX: (0044) 01207 599789
Email: info@aqua-joy.com
www.aqua-joy.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aquajoy Premier Plus and is the answer not in the manual?

Questions and answers

Summary of Contents for Drive Aquajoy Premier Plus

  • Page 1 REV.13 OPERATING INSTRUCTIONS AQUAJOY PREMIER PLUS AQUAJOY JUNIOR PLUS First point of contact is always as follows unless supplied by a Local Authority or Dealer. AQUAJOY by DRIVE CONSETT BUSINESS PARK CONSETT COUNTY DURHAM DH8 6BN TEL: (0044) 01207 501555 FAX: (0044) 01207 599789 Email: info@aqua-joy.com...
  • Page 2 REV.13 QUICK CHECK LIST CHARGING YOUR HANDCONTROL Before you first use your Bathlift, please charge your battery handcontrol for 12 hours. Please continue to charge your battery hand control after every bath or for at least 12 hours per week. You cannot overcharge your battery hand control. If the battery hand control indicator light flashes red it means you do not have sufficient charge to use your Bathlift.
  • Page 3 Thank you for purchasing your AquaJoy Premier Plus Bathlift. The AQUAJOY PREMIER PLUS BATHLIFT has been designed to help you bathe in comfort. The AQUAJOY PREMIER PLUS BATHLIFT can be used in the home, in multi user environments and by healthcare professionals.
  • Page 4 REV.13 Safety Instructions The AquaJoy Premier Plus Bathlift may only be used to assist one person getting in and out of a bath at a time. It should not be used for climbing in and out, up or down, as a support or lifting platform outside of the bath. Please note the bathlift is not a toy and children should not be allowed to play with the Bathlift.
  • Page 5: Battery And Charger

    After the first twelve hour charge, please charge your battery handcontrol continuously after every bath or for at least 12 hours per week. Only use the AquaJoy Premier Plus Bathlift with the AquaJoy Premier Plus battery hand control supplied. Only use the supplied AquaJoy Premier Plus battery charger to charge the...
  • Page 6 REV.13 Serial Number Label You will find all the main technical data on the AQUAJOY PREMIER PLUS serial number label Actuator label Seat label Battery hand control label Environmental Conditions for Use, Storage, and Transport Use: An ambient temperature range of 50 F° to 104F° (+10 C° to +40C°).
  • Page 7 REV.13 ASSEMBLY / INSTALLATION HOW TO INSTALL YOUR AQUAJOY PREMIER PLUS BATHLIFT PLEASE NOTE: PLEASE ENSURE WHEN INSTALLING YOUR AQUAJOY PREMIER PLUS BATHLIFT THAT YOU PLACE IT AT THE OPPOSITE END TO THE TAPS. PLEASE NOTE: WHEN CONNECTING THE BATHLIFT BACKREST TO THE...
  • Page 8 (See earlier point). • Simply lift the backrest up until it is in the fully reclined position. PLEASE NOTE: BEFORE YOU FIRST USE YOUR AQUAJOY PREMIER PLUS / JUNIOR PLUS BATHLIFT, PLEASE CHARGE YOUR BATTERY HAND CONTROL FOR TWELVE HOURS.
  • Page 9 REV.13 HOW TO CHARGE YOUR AQUAJOY PREMIER PLUS BATHLIFT If already connected, separate the cable of the battery hand control from the bathlift (backrest) cable. If not connected, simply remove your battery hand control from the packaging. For safety reasons, please ensure that you do not charge your battery hand control in your bathroom.
  • Page 10 BATHING WITH YOUR AQUAJOY PREMIER PLUS HOW TO BATHE WITH YOUR AQUAJOY PREMIER PLUS BATHLIFT After easily installing your AQUAJOY PREMIER PLUS BATHLIFT attach the connector of the fully charged battery hand control to the connector on the back of the backrest.
  • Page 11 REV.13 HOW TO REMOVE YOUR AQUAJOY PREMIER PLUS BATHLIFT FROM YOUR BATH TUB 27 Degrees Empty the water from the bath. Pressing the “down” button on the hand control, take the bathlift to its lowest position in the bath, continue to press the down button until the backrest reaches its’...
  • Page 12: Service And Maintenance

    REV.13 SERVICE AND MAINTENANCE The AQUAJOY PREMIER PLUS BATHLIFT requires minimal maintenance /servicing. Please check that everything is in good working order at regular intervals (at least once every month). The Bathlift actuator is tested to last 10,000 cycles if used and maintained correctly in the environment for which it has been designed.
  • Page 13 Please contact our Customer Services Department for further details (see front page for contact details). There are no user serviceable parts in the AquaJoy Premier Plus Bathlift and repairs or servicing must only be carried out by your supplier or other...
  • Page 14 Separate these / pull them apart and the hand control will detach. Now, attach the supplied black AquaJoy Premier Plus charger adaptor to the AquaJoy Premier Plus hand control in the same way and plug the three point plug into a mains socket.
  • Page 15 REV.13 3. CAN I / HOW DO I WASH MY COVERMATS? The AQUAJOY PREMIER PLUS BATHLIFT can be used with or without covers. The standard covermats can be easily removed and washed in your washing machine up to a maximum temperature of 60°. The covermats cannot be used in a tumble dryer, please hang them up to dry.
  • Page 16: Technical Data

    REV.13 TECHNICAL DATA Length of seat: 580 mm ( 22.8 inches) Width of seat with extended seat side flaps: 686 mm ( 27 inches) Width of seat with seat side flaps folded in: 390 mm ( 15.3 inches) Height of seat in its lowest position: 90 mm ( 3.5 inches) Height of seat in its highest position: 465 mm ( 18.3 inches) Depth of seat measured from Backrest to front seat edge: 490 mm ( 19.3 inches)
  • Page 17: Carrying Bag

    SWIVEL AND SLIDE UNIT The AquaJoy Premier Plus transfer disk will assist you to get on and off your bathlift easily and safely. It is ideal for people who have problems shuffling on and off the bathlift and allows them to slide and turn into the middle of the bathlift seat.
  • Page 18 REV.13 AQUAJOY JUNIOR PLUS BATHLIFT (FOR CHILDREN & YOUNG ADULTS) TO FIT THE POMMEL Place the pommel prongs into the seat (base) locating holes and push down. The pommel will now sit in place. If any holes are required to be punched into the AquaJoy Bathlift covers to accommodate the pommel or wedge, this will be completed on site by AquaJoy Prior to dispatch.
  • Page 19 REV.13 TO FIT THE CHEST & LAP HARNESS The chest harness fixing bracket should be attached to the back of the backrest. It is adjustable by sliding the bracket up and down the backrest so that the belt can be positioned at the most suitable height for the client. The harness is secured by screwing the knob into the fixing bracket as shown in the above diagram.
  • Page 20: Warranty

    REV.13 WARRANTY AquaJoy by Drive guarantees this product for three years on the frame, and actuator and 1 year on the battery hand control, charger and accessories from date of purchase (unless otherwise negotiated). For extended warranties and maintenance packages, please contact AquaJoy by Drive.

This manual is also suitable for:

Aquajoy junior plus
